Swiftech MCX370-A Manual de usuario

Rouchon Industries, Inc., dba Swiftech – 1703 E. 28th Street, Signal Hill, CA 90806 – Tel. 562-595-8009 – Fax 562-595-8769

E Mail: Swiftech @swiftnets.com – URL: http://www.swiftnets.com

Information subject to change without notice

Page 1

Packing list

Parts Qty Parts Qty

Heat Sink 1 Nylon spacers 2

Fan NO Long spring 1

6-32 x 2 ½ ” screws (for fan) 4 Short spring 1

6-32 x 1” screws (for HS) 2 Rubber washers 8

Clips 2 Thermal grease 1

Compatible with AMD® Duron™, Athlon™, MP, XP 2000 & higher, and Intel® Pentium™ III processors

II. Heat sink Installation

Thermal compound

here

• We recommend that you lay down your computer flat on a table.

• Lightly coat the processor core with the included thermal compound.

Only a paper thin coat is necessary. It should be applied using

preferably a razor blade, or a credit card, held between thumb and

index at a 45 degree angle. It is critical to ascertain that the entire core

is covered with a uniform coat of thermal compound. Thermal

performance will dramatically decrease if any portion of the core is not

covered by thermal compound.

I. Assembly schematic

6-32 x 2 1/2“ screw

Fan

6-32 x 1 1/2“

screw

Clip

Long

spring

Short

spring

Rubber washer

Fan air flow

direction

Step in heat sink base

Nylon spacer

To power supply

Heat sink

Rouchon Industries, Inc., dba Swiftech – 1703 E. 28th Street, Signal Hill, CA 90806 – Tel. 562-595-8009 – Fax 562-595-8769

E Mail: Swiftech @swiftnets.com – URL: http://www.swiftnets.com

Information subject to change without notice

Page 2

• The heat sink base features a step which should be placed over the

socket’s cam box as shown in schematic to the right.

• Place the heat sink fan assembly onto the CPU making sure that the clips

hook to the tabs on each side of the socket. Should the factory setting be a

little short, do not attempt to force the heat sink down by rocking it one side

or another. Simply screw clockwise until the clips hook onto the tabs.

• Then, turn both screws counter-clockwise until the head of the screw

clears the top of the clip by approximately 1/16” (1.5mm) as shown in the

picture below. As soon as the head of the screw is no longer touching the

top of the clip, the spring is under full tension.

• Note: Should you disassemble the mounting screws and compression

springs for any reason in the future, please note that the springs are of

unequal length. The short spring goes on the side of the heat sink that

features a step in the base, whereas the long spring goes to the opposite

side (see assy. schematic on page 1).

• Finally, connect the fan power cord to the power supply.

Step side

over socket

cam box

Turn screw driver

secure assy.

To CPU

counter clockwise

III. Final inspection

Now that the heat sink is installed, startup your computer, go into the BIOS and observe the CPU temperature. Under normal ambient

temperature conditions, the processor temperature should never exceed 60°C (140 °F). If it does, shut down the computer immediately, and

review your entire installation. Troubleshooting help is available on our web site at www.swiftnets.com, or by calling customer support at 562-

595-8009.

DISCLAIMER: Swiftech assumes no liability whatsoever, expressed or implied, for the use of these products.
