SplashDrone 4

User Manual

Visit support.swellpro.com for the latest version of this manual and firmware updates

for your drone and accessories.

v2.3 –June 2022

Thank You

Thank you for purchasing the SplashDrone 4. We have designed and manufactured the

SplashDrone 4 to the highest quality standards.

Like any marine equipment, long-life and trouble-free operation rely on correct care and

maintenance. With proper care and maintenance, you should enjoy your drone for many

years. After flying in salt or contaminated water, always thoroughly rinse your

SplashDrone 4 in freshwater immediately after use or before salt and sediment can dry

inside moving parts.

It is important to familiarize yourself with the features of this unique drone by carefully

studying this manual and particularly the priority sections indicated in the Table of

Contents.

Visit www.swellpro.com for the latest manuals, software, and tips. Refer to the Version

Information section at the end of this manual, which details additions and corrections

to this manual.

Using this Manual

This document is designed to be printed or viewed on a computer or mobile device. If

used electronically, you can search directly for terms like "Propeller" to find references.

Additionally, you can click on any topic in the Table of Contents to navigate directly to

that topic.

FAQ

The user manual is the best companion while using the product. For the

specific problem using the product, the FAQ can be another great

resource for you to look at. Go to the SwellPro website, look for

support >product support > the product > FAQ to find the FAQ page.

support.swellpro.com

Video Tutorials

Visit and subscribe to the SwellPro YouTube channel for tutorial videos and product

information. Scan this QR code with your camera phone to go to our channel.

SwellPro Community

Join our exclusive SwellPro Community to post feedbacks and share your experience

with SwellPro products to other users like you.

https://support.swellpro.com/hc/en-us/community/topics

Social Media

Join our Facebook page to meet other people who share their adventures with

SwellPro. www.facebook.com/SwellPro/

Please register your product on SwellPro website as soon as possible to ensure

warranty coverage.

Download the SDFly App

Get the most from your SplashDrone 4 by flying with the SDFly App. This new, powerful

mobile App enhances and optimizes the operation of the SplashDrone 4. Connected

wirelessly to the SplashDrone 4 remote controller, the App allows logging, planning,

recording of missions as well as the control and parameter setting of cameras and

other modules in flight.

Running the SDFly App when you fly adds advanced functionality like mapping, routing,

and intelligent modes to the standard flight modes in the remote controller.

For Apple devices, the iOS version is available for download on the AppStore. The

Android version is available for download on the Google Play Store or directly from the

SwellPro website: support.swellpro.com


 ©2022 SwellPro All Rights Reserved 4
Contents
Thank You 2
Using this Manual 2
FAQ 2
Video Tutorials 2
SwellPro Community 3
Social Media 3
Register Product Warranty 3
Download the SDFly App 3
Contents 4
Product Overview 8
Aircraft Diagram 9
Remote Controller Diagram 10
Remote Controller Screen 11
Install the Aircraft 12
Install Propellers 12
Install the Intelligent Battery 13
Install the Camera/Accessories 14
Aircraft 15
Aircraft Status Indicator 15
Intelligent Battery 16
️Battery Warning 18
Low Battery Warning 19
Aircraft Antenna 20
Antenna Position 20
Antenna Blind Spot 20
Strobe Light 22
Waterproof Barometric Membrane 22
Remote Controller 24
Using the Remote Controller 24


 ©2022 SwellPro All Rights Reserved 5
Power ON/OFF 24
Flight Mode Switch 24
Joystick Controls 24
Camera Control 25
Gimbal Control 25
Follow Me 26
Return to Home (RTH) 26
Smooth+ Controls 26
BOAT Button 27
Gimbal Button 27
Payload Button (Left) 28
Payload Button (Right) / Slow Mode 28
Remote Control Antenna 28
Optimal Signal Transmission 28
Patch Antenna 28
Attach Mobile Devices 30
Charging the Remote Controller 30
Pairing the Remote Controller 30
About Pairing 30
Identify SN Number 31
For SN number ending with V01 32
For SN number ending since V02 (V02, V03, V04 ... etc) 33
Remote Controller Rear Ports 34
Flight 35
Flight Safety and Environment 35
Flight Restrictions 36
Pre-Flight Checklist 36
Compass Calibration 37
Gyroscope Calibration 38
IMU Calibration 39
Basic Flight Steps 40
Starting/Stopping Motors (Arming the Drone) 41


 ©2022 SwellPro All Rights Reserved 6
Water Takeoff and Landing 42
Boat Takeoff and Landing 42
Power Flip 43
Flight Modes 43
Intelligent Follow 46
Smooth+ 47
Dynamic Return to Home (RTH) 47
Low Battery Auto Return to Home 48
Low Battery Auto Payload Release 49
SDFly App 50
Download SDFly 50
Connect SDFly 50
Use Mobile Data 50
Home Screen 51
Main Interface 52
Map Interface 53
Set the Wi-Fi Password 54
Set the Wi-Fi Password 54
Reset the Wi-Fi Password 54
Appendix 56
Specifications 56
Firmware Update 58
Flying Guide 58
Joystick Calibration 59
Warranty Information 60
Battery Care and Maintenance 60
Precautions for low-temperature use 61
Battery Charging 61
Battery Storage and Transportation 61
Battery Disposal 62
Maintenance 62

Disclaimer and Warning 62

Version Information 63

Product Overview

SplashDrone 4 is our 5th and the latest generation of waterproof drones, representing

SwellPro's 7 years of knowledge and understanding of drone waterproofing technology.

SplashDrone 4 is the all-new waterproof flight & float platform designed for

multipurpose operation in any harsh environment. With its modular payload system

design and our variety of payload choices, the SwellPro SD4 can quickly adapt to

different tasks in the field.

Aircraft Diagram

[01] Strobe Light

[02] CW (clockwise) Propeller

[03] Waterproof Motor

[04] Rear Arm Light

[05] CCW (Counter-clockwise) Propeller

[06] Landing Gear

[07] Antennas

[08] Battery Status Indicator

[09] Gimbal Camera Port

[10] Payload Release Port

[11] SDK Port

[12] USB Port and Pairing Button

[13] Power Button

[14] Battery Hatch

[15] Battery Hatch Lock

[16] Front Arm Light

[17] Compass Sensor

[18] GPS Cover

Remote Controller Diagram

[01] Automatic Landing Gear Toggle (Not

Applicable)

[02] Video Button

[03] Gimbal Pan/Tilt Roller

[04] Left Joystick (Throttle/Yaw)

[05] Follow Me Button

[06] Smooth+ Yaw Switch Button

[07] Smooth+ Yaw Knob

[08] Boat Mode Switch Button

[09] Left Payload Release Button

[10] Display Screen

[11] Charging Indicator

[12] Right Payload Release Button

Slow Mode1

[13] Gimbal Mode Switch Button

[14] Smooth+ Roll Knob

[15] Smooth+ Roll Switch Button

[16] RTH Return Home Button

[17] Power Button

[18] Right Joystick (Pitch/Roll)

[19] Flight Mode Toggle

[20] Photo Button

[21] Gimbal Pitch Roller

[22] Antennas

[23] Phone/Tablet Mount Adjustment Knob

[24] Phone/Tablet Mount

For the SplashDrone 4 came out later in 2022, the Payload (Right) print changes to Slow Mode. Button

function stays the same. Check Remote Controller section for the button function.
