Swann DVR8-4200 Manual de usuario

Advanced Security Made Easy

960H

PROSERIES

For more information on this product visit www.swann.com

WEATHERPROOF IP67 CAMERA WITH CABLE

THREADED THROUGH STAND

EASILY BACKUP INCIDENT VIDEO TO

USB OR NETWORK

30 DAYS+ CONTINUOUS RECORDING

TO 1TB HDD

EASY DO-IT-YOURSELF INSTALLATION WITH

CABLES & CONNECTORS INCLUDED

POWERFUL DAY & NIGHT VISION

UP TO 82FT/25M

CONNECT TO HDTV, LCD & PLASMA TVs

INCLUDES 4 X CLEAR RESOLUTION

700TVL CAMERAS

REAL TIME, WIDE SCREEN

HIGH RES RECORDING

WEATHER PROOF

ATHER PRO

DAY/NIGHT VISION

CRYSTAL CLEAR

700TVL

DVDQUALITYDVD

UALIT

960H

HDTV VIEWING

HDMI

30 DAYS RECORDING+

AYS RECORDI

1TB

EASY INSTALLATION

EASY BACKUP

Cutting-edge protection for your

home or business 24/7

• Swann’s TruBlue™ blue-lit 960H DVR with real time, widescreen high resolution live

video viewing & playback, perfect for 16:9 monitors

• Includes 4 x clear resolution 700TVL cameras with powerful night vision to 82ft/25m

& IP67 weatherproof rating for indoor/outdoor use. Expand with 4 cameras of your

choice for full 8 channel monitoring

• Set & forget by recording continuously from 8 channels for 30 days+ onto a 1TB hard

drive, even longer with motion detection for extra capacity connect external hard drive

to eSATA port

• Save time & have peace of mind by easily locating incident video, then transfer to

external storage via USB or network

• View live or playback in high resolution on your HDTV, LCD or plasma TV using HDMI

connection or on LCD screen via VGA port

• Setting up remote viewing has never been easier with Swann’s ‘My DVR’ customizable

network configuration & DDNS service

• Surveillance in the palm of your hand with live viewing on 3G/4G-enabled Smartphone

& tablets including, iPhone, iPad, Android devices, BlackBerry devices and more* using

the free SwannView app

• A cutting-edge solution for any home or business wanting high resolution

video monitoring

Professional

Security System

DVR8-4200™ 8 Channel 960H Digital Video Recorder

& 4 x PRO-642™ Cameras

SWDVK-842004

8CHANNELS

Swann stands by its promise of

Lifetime Support to make advanced

security easy to use, install and maintain. Everything is in

the pack but if you need it Swann’s help desk is available

24 hours a day, 7 days a week for the life of the product.

Installation is easy

Do-it-Yourself

Installing this Swann product is simple. For instructions, tips and videos

see the operating instructions in this pack or visit www.swann.com

Professional Installation

Need extra help?

We have an installer in your region!

For more visit www.swann.com

SwannView App

Free Download

* Monitor and mobile phones not included

* Requires broadband internet & 3G/4G Smartphone

COMPATIBLE WITH

Android

Devices

ALERTS

Stream Live Video

Footage From

Anywhere In The World

One of the great features of this product is its remote

viewing capabilities. You can view your home or

business from anywhere in the world via broadband

Internet connection on computer (PC or Mac) or on

your Smartphone* via the SwannView app.

Be notified on the move

ALERTS

Be notified on the move

ALERTS

For more information on this product visit

www.swann.com

What’s in the box

All installation accessories included

• DVR8-4200™

• 1TB HDD (installed)

• PRO-642™ Cameras x 4

• BNC Cables 60ft/18m x 4

• HDMI Cable

• Ethernet Cable

• Mouse

• Remote Control

• Software CD

• Power Adapter & Splitter

• Mounting Screws & Plugs

• Operating Instructions

• Theft Deterrent Stickers x 4

Specifications

DVR8-4200™ Digital Video Recorder

Video

Video Signal Type NTSC or PAL

Video Inputs 960H 8 Channels BNC

Video Outputs VGA and HDMI Output

Display Resolution Up to 1080p

Display Frame Rate NTSC: 30fps per channel / PAL: 25fps per channel

Audio

Audio Input 4 RCA Inputs

Audio Output 1 RCA Output

Recording

Compression Format H.264

Recording Resolution NTSC: 960H (960 x 480)

PAL: 960H (960 x 576)

Recording Frame Rate Real Time: NTSC: Global 240fps / 30fps per Channel /

PAL: Global 200fps / 25fps per Channel

Recording Modes Manual / Motion / Schedule

HDD Interface / Type 1TB SATA2 HDD (installed)

Hard Drive Support Up to 2TB SATA2 HDD

Network

LAN Connection One RJ45 Port

Network Protocol TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP

Dynamic DNS Yes (swanndvr.net, DYNDNS)

Remote Operation IE, MyDVR, CMS, SwannView

General

Operating Power DC 12V

Dimensions 10.23” x 8.46” x 1.97” / 260mm x 215mm x 50mm

Weight 3.1lbs / 1.4kg

Backup Method External storage via USB or network

Mouse Support Yes

Remote Control Yes (uses 2 x AAA batteries, included)

PRO-642™ Camera

Video

Image Sensor CCD

Video Quality 700 TV Lines

Resolution NTSC: 976 x 494, PAL: 976 x 582

Minimum Illumination 0.1 Lux (IR off), 0 Lux (IR on)

Day/Night Mode Color during day / switches to B&W at night

White Balance Automatic

Signal/Noise Ratio 50dB

Gain Control Automatic

Backlight Compensation Yes

Lens 4.8mm

Viewing Angle 57 degrees

Night Vision

Night Vision Distance 82ft/25m

IR cut Filter No

Number of Infra-Red LEDs 36

Infra-Red Wavelength 850nm

Infra-Red LED Life (average) 10,000 hours

General

Indoor / Outdoor Indoor or outdoor, IP67 rated

Operating Power DC 12V

Operating Temperature -4° F ~ 140° F / -20° C ~ 60° C

Body Construction Aluminum

Dimensions – Camera 3.7”x 2.0” x 3.4” / 96mm x 53mm x 85mm

Weight – Camera 0.67lbs / 305g

Code

Swann Code SWDVK-842004

Professional Security System

DVR8-4200™ 8 Channel 960H Digital Video Recorder

& 4 x PRO-642™ Cameras

Please note that the information contained within this document is subject to change without notification.

All trademarks remain properties of their respective owners.

+ 30 days recording achieved using lower settings, default settings give 6 days recording * Mobile phones not included, check the website for the latest models Not all handset models supported

**Applies to modems that have UPnP function
