DVR4-1100™ Recording Kit

4 Channel DVR & 4 Security Cameras

Easy to install monitoring & recording kit for home or business

www.swannsecurity.com

Product Code: SW244-PO4 Monitoring Kits & Recording

• Easily monitor & record 4 cameras simultaneously

• Catch every movement with motion detection

• Daily scheduling - records when you want

• Record video to pre-installed hard drive and back-up events via USB port

• Lockable hard drive tray makes it easy to upgrade or back-up when you choose

• 4 indoor/outdoor, day & night OutdoorCams™

• Perfect home or business security starter kit for your peace of mind

MONITORING

Warranty

month

Plugs into your TV

160GB

Hard Drive

Records Longer

Color

60ft (18m)

cable

when Sheltered

Weather Resistant

250GB

Hard Drive

Records Longer

Sees in the Dark

up to 25ft (8m)

www.swannsecurity.com

Please note that the information

contained within this document is

subject to change without notification.

MONITORING

Technical Specifications

Digital Video Recorder

Operating System: Embedded RTOS

Video Input: NTSC/PAL

Video Input Channel: 4CH Composite

Video Output Channel: 1CH Composite

Display Frame Rate: NTSC: 120 fps (4 x 30 fps)

PAL: 100 fps (4 x 25 fps)

Recording Frame Rate (QUAD): NTSC: Max. 30 fps PAL: Max. 25 fps

Recording Frame Rate (EACH): NTSC: Max. 7.5 fps (30 fps/4)

PAL: Max. 6.25 fps (25 fps/4)

Recording Modes: Motion, Continuous or Schedule

Display Resolution: NTSC: 720 x 480 PAL: 720 x 576

Recording Resolution: NTSC: 640 x 224 PAL: 640 x 272

Compression Format: Advanced MJPEG:

Low: 12K Bytes / Frame

Normal: 15K Bytes / Frame

High: 20K Bytes / Frame

Maximum supported HDD: 400GB x 1 (160GB installed)

Search Modes: Time / Date / Event

Full screen: Yes

Motion Detect: Yes

Loss Detect: Yes

Buzzer Output: Yes

Brightness Adjust: Yes

Contrast Adjust: Yes

USB Output: Yes

USB Connectivity: PC only, external hard drives & memory

sticks not supported

System monitor: Auto restore record mode on power recovery

Power supply: DC 12V

Dimension (W x D x H): 82/3” x 111/3” x 2” (220mm x 288mm x 50mm)

Weight: 3.3pounds (1.5Kg)

OutdoorCam™

Camera Sensor: 1/3” / 8.5mm CMOS

TV System: PAL (AU, UK) or NTSC (USA) -

Country Dependant

Effective Element: PAL: 628 (H) x 582 (V)

NTSC: 510 (H) x 492 (V)

Definition: 380 TV Lines

Scanning Frequency: PAL: 50HZ; NTSC: 60HZ

Minimum Illumination: 3 Lux (Colour) / 0 Lux (B&W)

Signal Noise Ratio: >+40dB

Electronic Shutter: 1/60 ~ 1/15000 second

Power Supply: 8V ~ 12V DC

Infra-red range: Up to 25ft / 8m

View Angle: 40°

IR Power Control: CDS Light Sensor

Power Consumption: 1.5 Watts

Window: 2mm Heat-Resisting Glass

Construction: Aluminum

Operation Temperture: -4°F - 140°F / -20°C - 60°C

Package Contents

• DVR4-1100TM with accessories

• OutdoorCamTM x 4

• Power Adapters

• RCA Cables x 4

• BNC to RCA Video Cable 3ft (1m)

• Instruction Manual

• Bonus Security Stickers x 4

DVR4-1100™ Recording Kit

4 Channel DVR & 4 Security Cameras

Easy to install monitoring & recording kit for home or business
