For more information on this product visit www.swann.com

SECURE POINT-TO-POINT

ENCRYPTED SIGNAL

DIGITAL WIRELESS TRANSMISSION

UP TO 165FT/50M+

SET & FORGET WITH MOTION

TRIGGERED RECORDING

SEE & RECORD WHAT’S HAPPENING

ON THE 7” COLOR MONITOR

RECORD TO SD CARD (UP TO 32GB)*

CONVENIENTLY HEAR WHAT’S BEING

SAID UP TO 16FT/5M

DAY & NIGHT VISION OF 32FT/10M & ROBUST

CASING FOR INDOORS OR OUTDOORS

100% PRIVACY

%PRIV

WIRELESS

IRE

LES

NIGHT VISION

GHT VISI

MOTION DETECTION

ON DETE

LCD MONITOR

MONI

MICROPHONE

OPHO

UP TO 32GB*

Easy, affordable wireless

surveillance system

• See & hear everything via on a crystal clear 7” color monitor

• Zero interference from Wi-Fi, web routers, microwave ovens, cordless

phones & more

• Enjoy 100% privacy from a secure, encrypted point-to-point signal

• Set & forget with motion triggered recording onto SD card (takes up to

32GB*)

• Includes a weather resistant security camera with night vision up to

32ft/10m, with the ability to add 3 more cameras if needed

• Safeguard loved ones, protect property & deter crime with this affordable

wireless surveillance system

Digital Wireless

Security System

ADW-340™ Camera & Monitor with Motion Triggered Recording

SWADW-340KIT

Swann stands by its promise of

Lifetime Support to make advanced

security easy to use, install and maintain. Everything is in

the pack but if you need it Swann’s help desk is available

24 hours a day, 7 days a week for the life of the product.

For more information on this product visit

www.swann.com

Camera

Connect

wirelessly

Digital Monitor & Recorder

Power

Adapter

Power

Adapter

Antenna

Up/Down

Back/Forward

/OK Button

Esc

Record

Zoom

Alarm

What’s in the box

All installation accessories included

• ADW-340™ Wireless Camera

• Digital Monitor & Recorder

• Antennas x 2

• RCA AV Cable

• Power Adapters x 2

• Mounting Screws & Plugs

• Operating Instructions

• Theft Deterrent Stickers

Specifications

Digital Monitor & Recorder

Video

Video Format NTSC or PAL

Video Outputs AV x 1

Display Resolution VGA

Audio

Input Via Camera

Output AV x 1

Recording

Compression Format MPEG-4

Video Resolution VGA: Single Cam / Q VGA: Multiple Cams

Frame Rate Up to 20fps

Modes Schedule / Motion / Manual

Memory Type SD Card (up to 32GB*)

General

Operating Power DC 5V

Dimensions 7.8” x 4.8” x 1.0”/

200mm x 122mm x 26mm

Weight 13.9oz / 395g

Camera

Video

Image Sensor CMOS

Resolution VGA

Minimum Illumination 0 Lux (IR on)

Day/night Mode Color during day/

switches to B&W at night

Lens 3.6mm

Viewing Angle 60 degrees

Audio

Microphone Yes

Audio Range 16ft / 5m

Night Vision

Night Vision Distance Up to 32ft / 10m+

Number of Infra-RedLEDs 26

General

Operating Power DC 5V

Operating Temperature 14°F ~ 122°F / -10°C ~ 50°C

Body Construction Aluminum

Dimensions – Camera 5.1” x 2.4” x 2.6” / 130mm x 61mm x 67mm

Weight – Camera & Stand 21.6oz / 615g

Wireless

Digital or Analog Digital

Max. Transmission Range Up to 165ft / 50m+

Typical Range 65ft / 20m+

Frequency 2.4 GHz

Transmission Channels 4

Code

Swann Code SWADW-340KIT

+ Depends on local conditions

* SD card not included

Digital Wireless Security System

ADW-340™ Camera & Monitor with Motion Triggered Recording

Please note that the information contained within this document is subject to change without notification.

All trademarks remain properties of their respective owners.

Installation is easy

Do-it-Yourself

Installing this Swann product is simple. For instructions, tips

and videos see the operating instructions in this pack or visit

www.swann.com

Professional Installation

Need extra help?

We have an installer in your region!

For more visit www.swann.com
