USER’S MANUAL

Web Camera

IC-970

2

2

2

2

3

3

3

Congratulations on your purchase of the Sven web camera!

Please read this Operation Manual before using the unit and retain this

Operation Manual in a safe place for future reference.

COPYRIGHT

© 2013. SVEN PTE. LTD. Version 1.0 (V 1.0).

This Manual and information contained in it are copyrighted. All rights

reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this Manual more exact, some

discrepancies may occur. The information of this Manual is given on «as is»

terms. The author and the publisher do not bear any liability to a person or

an organization for loss or damage which has arisen from the information

contained in this Manual.

CONTENTS

1. SAFETY PRECAUTIONS .....................................

2. PACKAGE CONTENTS . .. ...................................

3. SPECIAL FEATURES ........................................

4. SYSTEM REQUIREMENTS ..................................

5. CONNECTION AND INSTALLATION . . . . . ....................

6. DESCRIPTION ..............................................

7. TECHNICAL SPECIFICATION ................................

1

Technical support: www.sven.ﬁ

User’s Manual

ENG

IC-970

2

ENG

Web Camera

1. SAFETY PRECAUSIONS

•Protect your web camera from high humidity, dust or high temperatures.

•Do not use gasoline, spirit or other dissolvents for cleaning. This may

cause damage of the surface. Clean the outside of the camera with soft

cloth.

•Do not attempt to disassemble or repair your device.

•Protect the device against powerful shocks and falls – they may damage

the internal electronics.

2. PACKAGE CONTENTS

•Web camera — 1 pc

•User’s Manual — 1 pc

•Warranty card — 1 pc

3. SPECIAL FEATURES

•Built-in microphone

•Manual focus

•LEDs (light emitting diodes) for work in dark environment

•Backlight On/Oﬀbutton (on the back side)

•Stand for camera ﬁxation

•Additional microphone for noise cancellation

4. SYSTEM REQUIREMENTS

•Windows XP/Vista/7/8

•Pentium P4 1.4GHz or AMD Athlon 1GHz

•128 MB RAM, 200 MB Free Hard Disk Space

•Video adapter 24-bit color

•Available USB 1.1 or 2.0 port (high-speed USB 2.0 port is required for

higher resolution)

a

b

c

e

f

d

7. TECHNICAL SPECIFICATION

Parameter, unit

Sensor type

Resolution, pix

Frame rate, frames/sec

Focus distance, mm

Cable length, m

Value

CMOS

1280 × 1024, maximum 3200 × 2400

(enhanced by software)

up to 30 fps for 640 × 480

8 to inﬁnity

1.25

Notes:

• Technical speciﬁcation given in this table is supplemental information

and can not give occasion to claims.

• Technical speciﬁcation is subject to change without notice due to improve-

ment of SVEN production.

5. CONNECTION AND INSTALLATION

•Connect the web camera to an

available USB port.

•This web camera supports Plug and

Play technology. Installation of the

device is automatic after its connection

to USB port.

6. DESCRIPTION

aBacklight On/Oﬀbutton (on the back

side)

bBuilt-in microphone

cLEDs (light emitting diodes)

dStand

eLenses

fFocus Fig. 1. Web camera

description

ENG

3

IC-970

User’s Manual

Модель: IC-970

Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,

РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии:

ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха

Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите

вгарантийном талоне или на сайте www.sven.ﬁ.

Гарантийный срок: 12 мес. Срок службы: 2 года.

Производитель: «СВЕН ПТЕ. Лимитед»,

176 Джу Чиат Роуд, №02-02, Сингапур, 427447.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,

№02-02, Singapore, 427447. Produced under the

control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,

Kotka, Finland, 48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
