IC-725
USER’S MANUAL
Web Camera with Microphone
2
2
2
2
3
3
3
Congratulations on your purchase of the Sven web camera!
Please read this Operation Manual before using the unit and retain this Ope-
ration Manual in a safe place for future reference.
COPYRIGHT
© 2013. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some
discrepancies may occur. The information of this Manual is given on «as is»
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. SAFETY PRECAUTIONS ................................................
2. PACKAGE CONTENTS ..................................................
3. SPECIAL FEATURES .....................................................
4. SYSTEM REQUIREMENTS .............................................
5. CONNECTION AND INSTALLATION ..................................
6. DESCRIPTION ............................................................
7. TECHNICAL SPECIFICATION ..........................................
Technical support: www.sven.fi
ENG
1
IC-725
User’s Manual
1. SAFETY PRECAUSIONS
•Protect your web camera from high humidity, dust or high temperatures.
•Do not use gasoline, spirit or other dissolvents for cleaning. This may
cause damage of the surface. Clean the outside of the camera with soft
cloth.
•Do not attempt to disassemble or repair your device.
•Protect the device against powerful shocks and falls – they may damage
the internal electronics.
2. PACKAGE CONTENTS
•Web camera — 1 pc
•User’s Manual — 1 pc
•Warranty card — 1 pc
3. SPECIAL FEATURES
•Built-in microphone
•Manual focus
•Sensor ring for selection of LED color
•Comfortable mounting clip for camera fixation
•Hinge for camera rotation
4. SYSTEM REQUIREMENTS
•Windows XP/Vista/7/8
•Pentium P4 1.4GHz or AMD Athlon 1GHz
•128 MB RAM, 200 MB Free Hard Disk Space
•Video adapter 24-bit color.
•Available USB 1.1 or 2.0 port (high-speed USB 2.0 port is required for
higher resolution)
ENG
2
Web Camera with Microphone
a
b
c
d
e
f
7. TECHNICAL SPECIFICATION
5. CONNECTION AND INSTALLATION
•Connect web camera to an available
USB port.
•This web camera supports Plug and Play
technology. Installation of the device is
automatic after its connection to USB
port.
6. DESCRIPTION
aLenses
bFocus
cSensor ring for selection of LED color
dBuilt-in microphone
eHinge
fMounting clip
Parameter, unit
Sensor type
Resolution, pix
Frame rate, frames/sec
Focus distance, mm
Cable length, m
Value
CMOS
640 × 480, maximum 3200 × 2400
(enhanced by software)
up to 30 fps for 640 × 480
4.8 to infinity
1.25
Notes:
• Technical specification given in this table is supplemental infor-
mation and can not give occasion to claims.
• Technical specification is subject to change without notice due to im-
provement of SVEN production.
Fig. 1. Web camera
description
ENG
3
IC-725
User’s Manual
Модель: IC-725
Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
