USER’S MANUAL

Web Camera with Headset

IC-H3300

User’s Manual

ENG

Congratulations on your purchase of the Sven web camera!

Please read this Operation Manual before using the unit and retain this

Operation Manual in a safe place for future reference.

This Manual and information contained in it are copyrighted. All rights

reserved.

TRADEMARKS

All trademarks are the property of their legalholders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this Manual more exact, some

discrepancies may occur. The information of this Manual is given on “as is”

terms. The author and the publisher do not bear any liability to a person or

an organization for loss or damage which has arisen from the information

contained in this Manual.

CONTENTS

1. SAFETY PRECAUTIONS ..............................................

2. PACKAGE CONTENTS ................................................

3. SPECIAL FEATURES ...................................................

4. SYSTEM REQUIREMENTS ...........................................

5. CONNECTION AND INSTALLATION ................................

6. DESCRIPTION ..........................................................

7. TECHNICAL SPECIFICATIONS ......................................

Technical support: www.sven.ﬁ

IC-H3300

1. SAFETY PRECAUTIONS

•Protect your web camera from high humidity, dust or high temperatures.

•Do not use gasoline, spirit or other dissolvents for cleaning. This may

cause damage to the surface. Clean the outside of the camera with dry soft

cloth.

•Avoid causing mechanical damage to the device.

•Do not attempt to disassemble or repair your device yourself.

2. PACKAGE CONTENTS

•Web camera – 1 pc

•Headset – 1 pc

•User’s Manual – 1 pc

•Warranty card – 1 pc

3. SPECIAL FEATURES

•Adjustable focal distance

•Comfortable mounting clip for camera ﬁ xation on a desktop, laptop, LCD

monitor

•Ball-type hinge for camera rotation

•Plug&Play

•Adjustable headband

•Flexible microphone holder

•Comfortable embouchures

4. SYSTEM REQUIREMENTS

•Windows XP/Vista/7/8/10

•Pentium P4 1.4GHz or AMD Athlon 1GHz

•128 MB RAM

•Video adapter 24-bit color

•Available USB port

ENG

Web Camera with Headset

5. CONNECTION AND INSTALLATION

•Connect the web camera to an avail-

able USB port.

•This web camera supports Plug and

Play technology. Installation of the de-

vice is automatic after its connection to

the USB port.

•Connect stereo headset to PC as

follows: plug headphones cable mini-

jack (k, green) into PC headphones

socket, and microphone cable mini-

jack (l, orange) connect to PC micro-

phone input.

6. WEB CAMERA WITH HEADSET

DESCRIPTION

aFocus

bLenses

cBall-type hinge

dHinge

eMounting clip

fAdjustable headband

gМicrophone

hFlexible microphone holder

iEmbouchures

jVolume control knob

kHeadphones cable mini-jack

lMicrophone cable mini-jack

Fig. 1. Web Camera

Fig. 2. Headset

ENG

User’s Manual IC-H3300

Notes:

• Technical speciﬁcations given in this table are supplemental information

and can not give occasion to claims.

• Technical speciﬁcations are subject to change without notice due to imp-

rovement of SVEN production.

7. TECHNICAL SPECIFICATIONS

Parameter, unit

Sensor type

Resolution, pix

Frame rate, frames/sec

Focus distance, mm

Weight, g

Impedance, Ω

Sensitivity, dB/1 kHz

Frequency response, Hz

Max. output power, mW

Jack type, mm

Module dimensions, mm

Directional selectivity

Response level of microphone, dB

Frequency response of mic-phone, Hz

Cable length, m

Weight, g

Value

CMOS

640 × 480

up to 30 fps for 640 × 480

8 to inﬁnity

105

20 – 20,000

100

Ø 3.5 mini-jack

9 × 7

omnidirectional (360°)

–58 ± 3

30 – 16,000

Web Camera

Headset

ENG

Web Camera with Headset

Model: IC-H3300

Импортер вРоссии: ООО «РЕГАРД», 109052,

РФ, г. Москва, ул. Нижегородская, д. 86, корп. Б.

Уполномоченная организация вРоссии:

ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха

Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите

вгарантийном талоне или на сайте www.sven.ﬁ.

Гарантийный срок: 12 мес. Срок службы: 2 года.

Производитель: «СВЕН ПТЕ. Лимитед»,

176 Джу Чиат Роуд, №02-02, Сингапур, 427447.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,

№02-02, Singapore, 427447. Produced under the

control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,

Kotka, Finland, 48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.

IC-H3300

Web Camera with Headset
