Sven IC-545 Manual de usuario
www.sven.fi
USER’S MANUAL
Web Camera with Microphone
IC-545
2
2
2
2
3
3
3
Congratulations on your purchase of the Sven web camera!
Please read this Operation Manual before using the unit and retain this
Operation Manual in a safe place for future reference.
COPYRIGHT
© 2016. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
TRADEMARKS
All trademarks are the property of their legalholders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some
discrepancies may occur. The information of this Manual is given on “as is”
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. SAFETY PRECAUTIONS ............ . ........................
2. PACKAGE CONTENTS .. . ...................................
3. SPECIAL FEATURES .. ......................................
4. SYSTEM REQUIREMENTS .. ..... . ..........................
5. CONNECTION AND INSTALLATION . . . . . . . ..................
6. DESCRIPTION ................................... . . . ...... . .
7. TECHNICAL SPECIFICATION ................................
Technical support: www.sven.fi
ENG
1
IC-545
User’s Manual
1. SAFETY PRECAUTIONS
•Protect your web camera from high humidity, dust or high temperatures.
•Do not use gasoline, spirit or other dissolvents for cleaning. This may cause
damage to the surface. Cleanthe outside of the camera with soft cloth.
•Do not attempt to disassemble or repair your device.
•Protect the device against powerful shocks and falls – they may damage
the internal electronics.
2. PACKAGE CONTENTS
•Web camera — 1 pc
•User’s Manual — 1 pc
•Warranty card — 1 pc
3. SPECIAL FEATURES
•High-quality CMOS sensor and 5-lens system
•Built-in microphone
•Manual focus
•Power LED
•1.3 Mpix sensor resolution
•Comfortable mounting clip for camera xation
•Hinge for camera rotation
•Plug&Play
4. SYSTEM REQUIREMENTS
•Windows XP/Vista/7/8/10
•Pentium P4 1.4GHz or AMD Athlon 1GHz
•128 MB RAM
•24-bit color video adapter
•Available USB port
ENG
2
Web Camera with Microphone
c
d
b
a
e
f
Fig. 1. Web camera description
5. CONNECTION AND INSTALLATION
•Connect the web camera to an
available USB port.
•This web camera supports Plug
and Play technology. Installation of
the device is automatic after its
connection to the USB port.
6. DESCRIPTION
aFocus
bLenses
cHinge
dBuilt-in microphone
eLED
fMounting clip
ENG
3
IC-545
User’s Manual
7. TECHNICAL SPECIFICATIONS
Parameter, measurement unit
Sensor type
Resolution, pix
Frame rate, frames/sec
Focus distance, mm
Cable length, m
Value
CMOS
1280 × 1024
30 fps for 640 × 480
4.8 to infinity
1.45
Notes:
•Technical specifications given in this table are supplemental information
and cannot give occasion to claims.
•Technical specifications are subject to change without notice due to im-
provement of SVEN production.
Model: IC-545
ИмпортервРоссии: ООО«РЕГАРД», 109052,
РФ, г. Москва, ул. Нижегородская, д. 86, корп. Б.
Уполномоченная организация вРоссии:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy SvenScandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
IC-545
Web Camera with Microphone
