User Manual

Gaming Mouse

RX-G830

ENG

Gaming Mouse

Congratulations on your purchase of the Sven mouse!

This Manual and information contained in it are copyrighted. All rights

reserved.

TRADEMARKS

All trademarks are the property of their legal holders. The information of this

Manual is given on “as is” terms. The author and the publisher do not bear any

liability to a person or an organization for loss or damages which have arisen

from the information contained in the given Manual.

BUYER RECOMMENDATIONS

• Shipping and transportation equipment is permitted only in the original

container.

• Does not require special conditions for realization.

• Dispose of in accordance with regulations for the disposal of household and

computer equipment.

APPOINTMENT

RX-G830 gaming mouse is an input device. It is designed for entering

(entering) information into the computer, as well as controlling the operation

of the computer.

PACKAGE CONTENTS

• Gaming mouse — 1 pc

• User Manual — 1 pc

• Warranty card — 1 pc

SYSTEM REQUIREMENTS

• ОS Windows

• Free USB port

Technical support is on www.sven.ﬁ.

ENG

Rx-G830

User Manual

PREPARATION TO WORK

• Connect the gaming mouse to an available USB connector on the PC.

• After connecting to the USB port, the PC will automatically recognize the

device.

• To use the adjust the buttons and backlight, you need to install the

software (downloaded from the website www.sven.ﬁ). Run the previously

downloadedﬁle to install the driver, follow the installer’s advice.

• After installation, the program will automatically detect the presence of the

mouse. You can call up the control window using the icon in the taskbar or in

the Windows system tray.

KEY ASSIGNMENTS AND MOUSE SETTINGS

“Proﬁle 1” and “Proﬁle 2” are used to adjust the basic functions of the

mouse, for maximum convenience in the game. Initially, all mouse buttons

have default settings (as shown below). However, the user can change the

functions of these keys.

You can reassign mouse buttons by clicking in the box to the left of menu

items, thereby causing a context menu where you can override keys, assign

a macro (pre-conﬁgured keyboard shortcuts), assign a multimedia key to a

function (volume control, volume control, mute volume control).

Warning!

The row under number 1 (Left Key) can be reassigned to another function only

if the function (Left Key) is assigned to another key, otherwise the software

will produce an error message.

ENG

Gaming Mouse

Save and reset settings

The “RESET” button resets the settings. The “APPLY” button saves the

settings.

Switching between Proﬁle 1/Proﬁle 2

This mouse has the ability to switch between modes A and B. For example,

in “Proﬁle 1”, standard mouse buttons are assigned, and in “Proﬁle 2” you

can assign multimedia commands.

Default button assignments

1. Left Click – left mouse button

2. Right Click – right mouse button

3. Wheel Click – mouse wheel button

4. Forward – next browser page

5. Backward – previous browser page

6. DPI Loop – DPI increase

7. LED Switch – DPI reduction

Changing key functions

Button functions can be changed to a diﬀerent value.

The numbering of the mouse keys corresponds to the

list numbers on the left. By clicking on menu items, you

can call up a menu with reassignable features.

• Button – standard mouse key.

• Advance – special mouse functions.

•DPI – DPI resolution changes.

•Fire Key – to emulate left-clicking with

advanced settings.

•AIM – long press this button to set the

minimum DPI resolution, it is convenient for

precise aiming in games.

•LED Switch – changing backlight.

•LED ON/OFF – turning on/oﬀ the back-

light.

•Proﬁle Switch – switches between

“Proﬁle 1” and “Proﬁle 2”, modes,

provided that in “Proﬁle 2”, the command

“Proﬁle 1” is assigned to the same button.

ENG

Rx-G830

User Manual

•Disable – key oﬀ.

• Media – media player functions.

•Play/Pause – Play/Pause.

•Stop – stop.

•Previous Track – previous track.

•Next Track – next track.

•Volume + – volume increase.

•Volume - – volume decrease.

•Mute – mute.

• Website – browser functions.

•Home – home page.

•Search – search.

•Backward – previous browser page.

•Forward – next browser page.

•Stop – stop download.

•Refresh – refresh.

•Favorites – favorites.

• PC – PC functions.

•My Computer – My Computer.

•Calculator – calculator.

•Desktop – desktop.

• Customise – user key, you can set any key or combination from the keyboard

“Ctrl”, “Shift”, “Alt”, “Win” and any button.

• Macro – setting up macro commands.

Tab “Advanced”

ENG

Gaming Mouse

• Fire Key Setting – “Fire Key” button settings. “Repeat” speciﬁes the

number of repetitions when you press a key. “Firing Interval” – click interval.

• Moving Speed – cursor speed control. A tick is installed “Enhance pointer

precision” increases the accuracy of the mouse pointer.

• Double click speed – double click speed.

• Rolling Speed – rolling speed. A tick is installed “Scroll one screen at a

time” scrolls the page at once.

• DPI Setting – DPI setting. Clicking on the image “Torch”, you can select the

DPI mode illumination color.

Tab “Light”

• LED Status –turning on/oﬀﬀ the backlight.

• LED Brightness –backlight brightness full/half.

• LED Mode –mouse backlight modes.

• Breathing Speed –speed control for changing modes.

Macro editor

A macro is a sequence of events, consisting of pressing and releasing the

keyboard keys, mouse buttons, and the time intervals between them.

Macro editor is split into two parts. In tht “Macro List” area there is a list of

macros and in tht “Content”, area a list of commands of the selected macro

is displayed.

ENG

Rx-G830

User Manual

• Creating a macro name

Hover your mouse over the “Macro List”,right-click, select “New Macro”.

In the “Macro Name”, window, enter macro name and click “OK”. The

macro name will appear in list.

Macro recording

Click on the macro name “Macro List” –row with the name under it glows in

blue. Press “Record”, key, then you can type a sequence of characters from

the keyboard, if necessary, you can also emulate the click of a mouse button.

“Stop” button stops recording commands.

• More options for macros

In the lower right corner, there are options for latency and macro responses

to pressing macro button.

•Record Delay –delay between commands will be generated by the duration

of pressing a key at the command recording stage.

•Delay Setting – delay is entered in ms (milliseconds).

•No Delay – no delay between commands.

•Stop until the key release – entering macro will continue until the macro

button is pressed.

•Stop after the macro is over – stop will only occur after the macro command

is fully entered.

ENG

Gaming Mouse

TECHNICAL SPECIFICATIONS

Parameter, measurement unit Value

Q-ty of buttons 6 + 1 (scroll wheel)

OS required Windows

Interface USB

Resolution, DPI 500-6400

Сable length, m 1.8

Dimensions, mm 123*67*44

Weight, g 138

Notes. Technical speciﬁcations given in this table are supplemental

information and cannot give occasion to claims. Technical speciﬁcations

and package contents are subject to change without notice due to the

improvement of SVEN production.

Gaming Mouse

RX-G830

Model: RX-G830

Импортер в России: OOO «Регард», 105082,

г. Москва, ул. Фридриха Энгельса, д.75, стр. 5.

Уполномоченная организация в России:

ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха

Энгельса, д. 56, стр. 1. Условия гарантийно-

го обслуживания смотрите в гарантийном

талоне или на сайте www.sven.ﬁ. Гарантий-

ный срок: 12 мес. Срок службы: 5 лет.

Производитель: «СВЕН ПТЕ. Лимитед», 176

Джу Чиат Роуд, № 02-02, Сингапур, 427447.

Произведено под контролем «Свен Сканди-

навия Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано в Китае.

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat

Road, № 02-02, Singapore, 427447.

Produced under the control of Oy Sven Scan-

dinavia Ltd. 15, Kotolahdentie, Kotka, Finland,

48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
