QUICK REFERENCE GUIDE

Revision 1.0a

X12SAE

X12SCA-F

ENGLISH

繁體中文

简体中文

日本語

(

한국어

X12SAE/X12SCA-F QUICK REFERENCE GUIDE Product Safety Information

Standardized Warning Statements

Motherboards

About Standardized Warning Statements

The following statements are industry standard warnings, provided to warn the user of situations which can potentially

cause a bodily injury. Should you have questions or experience di󰀩culty, contact Supermicro's Technical Support De-

partment for assistance. Only certied technicians should attempt to install or congure components.

Read this section in its entirety before installing or conguring components in the Supermicro chassis.

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

Battery Handling

Warning!

There is a danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or an equiva-

lent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions.

警告

電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有電池。請按照製造商的說明指示處理

廢棄舊電池。

警告

电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更换原有电池。请按制造商的说明处理

废旧电池。

電池の取り扱い

電池交換が正しく行われなかった場合、破裂の危険性があります。交換する電池はメーカーが推奨する型、または同等のもの

を使用下さい。使用済電池は製造元の指示に従って処分して下さい。

경고!

배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제조사에서 권장하는 동등한

종류의 배터리로만 교체해야 합니다. 제조사의 안내에 따라 사용된 배터리를 처리하여 주십시오.









Note: For complete product safety information, refer to http://www.supermicro.com/about/policies/safety_information.cfm.

X12SAE/X12SCA-F QUICK REFERENCE GUIDE 限用物質含有情況標示聲明書

限

用

物

質

含

有

情

況

標

示

聲

明

書

設備名稱：主機板 /

Motherboard

型號（型式）：X12SAE,X12SCA-F

單元Ｕnit

限用物質及其化學符號

鉛Lead

(Pb) 汞Mercury

(Hg) 鎘Cadmium

(Cd)

六價鉻

Hexavalent

chromium

(Cr+6)

多溴聯苯

Polybrominated

biphenyls

(PBB)

多溴二苯醚

Polybrominated

diphenyl ethers

(PBDE)

主機板

(Motherboard)

－○○○○○

備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準

值。

備考2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。

備考3.〝－〞係指該項限用物質為排除項目。

Equipment name

Type designation (Type)

Restricted substances and its chemical symbols

Declaration of the Presence Condition of the Restricted Substances Marking

Note 1

：

“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the

reference percentage value of presence condition.

Note 2

：

“○” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence.

Note 3

：

The “−” indicates that the restricted substance corresponds to the exemption.

X12SAE/X12SCA-F QUICK REFERENCE GUIDE BIOS POST Codes

AMI BIOS POST Codes

About AMI BIOS POST Codes

The table below lists some of AMI BIOS POST codes for X12SAE/X12SCA-F. For more information, refer to https://

www.supermicro.com/manuals/other/AMI_AptioV_BIOS_POST_Codes_for_SM_Motherboards.pdf.

Code Description

0x32 CPU post-memory initialization is started

0x55 No Memory detected or memory failed

0x63 CPU DXE initialization is started

0x69 North Bridge DXE initialization is started

0x70 South Bridge DXE initialization is started

0x92 PCI Bus initialization is started

0x99 Super IO Initialization

0x9A USB initialization is started

0xA0 IDE initialization is started

0xA9 Boot into BIOS setup menu

0xAE Legacy Boot event

0xB2 Legacy Option ROM Initialization

0xB4 USB hot plug

0xD6 No console output devices are found

0xD7 No console input devices are found

0xF2 Recovery process started

0xF9 Recovery capsule is not found

X12SAE/X12SCA-F QUICK REFERENCE GUIDE M.2 Device Installation Instructions

M.2 Device Installation Instructions

M.2 Device Installation

MAC CODE

DIMMA1

DIMMA2

DIMMB1

DIMMB2

PCI-E_M.2-M1

2280

22110

Type 22110

Type 2280

X12SAE/X12SCA-F

Quick RefeRence Guide Rev. 1.0a

SUPERMICR R

Motherboard Layout and Features

=mounting hole

=X12SAE only

=X12SCA-F only

IPMI CODE

X12SCA-F

REV:1.01

MAC CODE

MAC CODE BAR CODE

DESIGNED IN USA

BIOS LICENSE

JD1

JPW2

JBT1

CPU_FAN2

CPU_FAN1

SYS_FAN1

SYS_FAN2

BMC_HB_LED

JSD1

JF1

JTPM1

JPW1

SP1

JPI2C1

JL1

COM1

LED4

CATERR_LED

PWR_LED

JPL1

JPAC1

JPG1

JPL2

JWD1

JPME2

SYS_FAN3

PCH

BMC

USB3.2Gen2

USB10

USB3.2 Gen2

12V_PUMP_PWR1

HDMI

DIMMA1

DIMMA2

DIMMB1

DIMMB2

VGA

DVI

USB3.2Gen2

LAN1

USB6/7

LAN2

USB2/3

IPMI_LAN

USB8/9

AUDIO

USB3.2 Gen1

UID

USB4/5

CPU SLOT6 PCI-E 3.0 X16

CPU SLOT4 PCI-E 3.0 X8 (IN X16)

I-SATA0

I-SATA1

I-SATA2

I-SATA3

PCH SLOT2 PCI-E 3.0 X4

JSTBY1

SLOT1 PCI 33MHZ

JLED1

AUDIO FP

USB0/1

PCI-E_M.2-M1

PCI-E_M.2-M2

PCH SLOT3 PCI-E 3.0 X1

USB3.2Gen1

I/O BACK PANEL

Package contents

• One (1) Supermicro Motherboard

• Four (4) SATA Cables

• One (1) I/O Shield

• One (1) Quick Reference Guide

Jumpers and Connectors

Jumpers

Jumper Description Default

JBT1 Clear CMOS (onboard) Short Pads to Clear CMOS

JD1 Speaker

Buzzer

Pins 1-4: External Speaker

Pins 3-4: Buzzer

JPAC1 Audio Enable Pins 1-2 (Enabled)

JPG1 VGA Enable (for X12SCA-F only) Pins 1-2 (Enabled)

JPL1/2 LAN1/LAN2 Enable/Disable Pins 1-2 (Enabled)

JPME2 Intel Manufacturing Mode Pins 1-2 (Normal)

JWD1 Watch Dog Function Enable Pins 1-2 (RST)

Connectors

Connector Description

12V_PUMP_PWR1 12V 4-pin Power Connector for CPU Liquid Cooling Pump

AUDIO High Denition Audio Ports (Back Panel)

AUDIO FP Front Panel Audio Header

B3 Onboard Battery

COM1 COM Header

CPU_FAN 1 ~ CPU_FAN 2 CPU Fan Headers

CPU SLOT4 PCI-E 3.0 x8 (INx16) PCIe 3.0 x16 Slot (PCIe 3.0 x8 link)

CPU SLOT6 PCI-E 3.0 x16 PCIe 3.0 x16 Slot (PCIe 3.0 x16 link) or PCIe 3.0 x8 (when CPU Slot4 is

Populated)

DP/HDMI DisplayPort Connector/High Denition Multimedia Interface (HDMI)

DVI Digital Video Interface (DVI-D)

I-SATA0~3 Intel Serial ATA (SATA 3.0) Ports 0~3 (6Gb/sec)

IPMI_LAN Dedicated IPMI LAN Port (for X12SCA-F only)

JF1 Front Control Panel Header

JL1 Chassis Intrusion Header

JLED1 3-pin Power LED Header

JPI2C1 Power Supply SMBus I2C Header

JPW1 24-pin ATX Main Power Connector (Required)

JPW2 +12V 8-pin CPU Power Connector (Required)

JSD1 SATA DOM (Disk On Module) Power Connector

JSTBY1 Standby Power Header (5V Standby Header)

JTPM1 Trusted Platform Module (TPM) Header (Supports TPM 2.0 only)

LAN1/2 LAN1: 1Gb/LAN2: 2.5Gb

PCH SLOT2 PCI-E 3.0 x4 PCIe 3.0 x4 Slot

PCH SLOT3 PCI-E 3.0 x1 PCIe 3.0 x1 Slot (for X12SAE only)

PCI-E_M.2-M1, M2 PCIe M.2 Connectors 1 and 2 (PCIe 3.0 x4 link), Small Form Factor

Devices and Other Portable Devices for High Speed NVMe SSDs

SLOT1 PCI 33MHz PCI Slot, 32 Bit/33MHz with 5V Single Voltage

SP1 Internal Speaker/Buzzer

SYS_FAN1 ~ SYS_FAN3 System Fan Headers

UID Unit Identier (UID) Switch (for X12SCA-F only)

USB0/1 Front Access USB 2.0 Header

USB2/3 Back Panel USB 3.2 Gen 1 Ports (Type A)

USB4/5 Front Access USB 3.2 Gen 1 Header

USB6/7 Back Panel USB 3.2 Gen 2 Ports (USB6: Type C, USB7: Type A)

USB8/9 Back Panel USB 3.2 Gen 2 Ports (Type A)

USB10 Front Panel Accessible USB 3.2 Gen 2 20-pin Connector

VGA VGA Port (for X12SCA-F, IPMI only)

ContaCt InformatIon

• www.supermicro.com (Email: [email protected])

• Manuals: http://www.supermicro.com/support/manuals

• Drivers & Utilities: https://www.supermicro.com/wftp/driver/

• Safety: http://www.supermicro.com/about/policies/safety_information.cfm

LED Indicators

LED Description Color/State

BMC_HB_LED X12SCA-F: BMC Heartbeat LED

X12SAE: Standby Power LED

X12SCA-F: Green Blinking (Normal)

12SAE: Solid Green (Standby Power On)

CATERR_LED Catastrophic Error LED Solid Orange: System CATERR

LED4 UID LED (for X12SCA-F, IPMI only) Blue on: Unit Identied

PWR_LED Onboard Power LED Green on: Power on

The X12SAE/X12SCA-F motherboard supports a single Intel® Xeon® W-1200 series, 10th Gen CoreTM i9/i7/i5/

i3 series processor, up to 128GB of Unbu󰀨ered (UDIMM) ECC/non-ECC memory, with speeds of up to 2933MHz

(2DPC) in four 288-pin memory slots. Populating these DIMM slots with a pair of memory modules of the same type

and same size will result in interleaved memory, which will improve memory performance.

Notes: 1) For memory optimization, use only DIMM modules that have been validated by Supermicro. For the latest memory updates,

please refer to our website at http://www.supermicro.com/products/motherboard.

2) Always connect the power cord last, and always remove it before adding, removing, or changing any hardware components.

3) The 10th Gen Core-i series processor supported by this motherboard is limited. For more detailed information, please refer to

Supermicro and Intel websites.

4) The Intel W-1200 series processor supports IGFX (Intel Graphics) via UEFI GOP driver, not via Legacy VBIOS.

DIMM Memory Installation

Towards the CPU

DIMMA1 (Black Slot)

DIMMA2 (Gray Slot)

DIMMB1 (Black Slot)

DIMMB2 (Gray Slot)

Memory Population Guidelines

When installing memory modules, the DIMM slots should be populated in the following order: DIMMA2, DIMMB2,

then DIMMA1, DIMMB1.

• Always use DDR4 DIMM modules of the same size, type, and speed.

• Mixed DIMM speeds can be installed. However, all DIMMs will run at the speed of the slowest DIMM.

Recommended Population (Balanced)

DIMMA1 DIMMB1 DIMMA2 DIMMB2 Total System Memory

2GB DIMM 2GB DIMM 4GB

2GB DIMM 2GB DIMM 2GB DIMM 2GB DIMM 8GB

4GB DIMM 4GB DIMM 8GB

4GB DIMM 4GB DIMM 4GB DIMM 4GB DIMM 16GB

8GB DIMM 8GB DIMM 16GB

8GB DIMM 8GB DIMM 8GB DIMM 8GB DIMM 32GB

16GB DIMM 16GB DIMM 32GB

16GB DIMM 16GB DIMM 16GB DIMM 16GB DIMM 64GB

32GB DIMM 32GB DIMM 64GB

32GB DIMM 32GB DIMM 32GB DIMM 32GB DIMM 128GB

CPU & Memory Support

Notes

• Graphics shown in this quick reference guide are for illustration only. Your components

may or may not look exactly the same as drawings shown in this guide.

• Refer to Chapter 2 of the User Manual for detailed information on jumpers, connectors,

LED indicators, memory support and CPU/motherboard installation instructions.

MNL-2263-QRG-10a

micro's written consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing;

however, it is not guaranteed.

A. DisplayPort 1.4 F. USB3: USB 3.2 Gen1 (Type A) K. 2.5Gb LAN Port 2

B. HDMI Port 2.0a G. USB2: USB 3.2 Gen1 (Type A) L. USB9: USB 3.2 Gen2 (Type A)

C. VGA Port (for IPMI, X12SCA-F only) H. 1Gb LAN Port 1 M. USB8: USB 3.2 Gen2 (Type A)

D. Digital Video Interface (DVI-D) I. USB7: USB 3.2 Gen2 (Type A) N. Center/LFE Out

E. Dedicated IPMI LAN Port

(X12SCA-F only)

J. USB6: USB 3.2 Gen2 (Type C) O. Surround Out

P. S/PDIF Out

Q. Line In

R. Line Out

S. Mic In

T. UID Switch (X12SCA-F only)

X12SCA-F

Power Button

OH/Fan Fail LED

NIC1 LED

Reset Button

Power Fail LED

HDD LED

Power LED

#3~4

#1~2

Vcc

Ground

1920

Vcc

Ground NMI

Vcc

NIC2 LED

Front Control Panel (JF1)

CPU Installation Heatsink Installation

Back Panel I/O Connectors

A C

E H K N Q

B D F

O R T

P S

Pin 1

Push down

Lock Unlock

美超微電腦股份有限公司

X12SAE/X12SCA-F

快速參考指南版本 1.0a

SUPERMICR R

主機板元件配置圖

=裝機孔

=僅限X12SAE

=僅限X12SCA-F

IPMI CODE

X12SCA-F

REV:1.01

MAC CODE

MAC CODE BAR CODE

DESIGNED IN USA

BIOS LICENSE

JD1

JPW2

JBT1

CPU_FAN2

CPU_FAN1

SYS_FAN1

SYS_FAN2

BMC_HB_LED

JSD1

JF1

JTPM1

JPW1

SP1

JPI2C1

JL1

COM1

LED4

CATERR_LED

PWR_LED

JPL1

JPAC1

JPG1

JPL2

JWD1

JPME2

SYS_FAN3

PCH

BMC

USB3.2Gen2

USB10

USB3.2 Gen2

12V_PUMP_PWR1

HDMI

DIMMA1

DIMMA2

DIMMB1

DIMMB2

VGA

DVI

USB3.2Gen2

LAN1

USB6/7

LAN2

USB2/3

IPMI_LAN

USB8/9

AUDIO

USB3.2 Gen1

UID

USB4/5

CPU SLOT6 PCI-E 3.0 X16

CPU SLOT4 PCI-E 3.0 X8 (IN X16)

I-SATA0

I-SATA1

I-SATA2

I-SATA3

PCH SLOT2 PCI-E 3.0 X4

JSTBY1

SLOT1 PCI 33MHZ

JLED1

AUDIO FP

USB0/1

PCI-E_M.2-M1

PCI-E_M.2-M2

PCH SLOT3 PCI-E 3.0 X1

USB3.2Gen1

I/O BACK PANEL

Otros manuales para X12SAE

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Placa madre de Supermicro

Supermicro

Supermicro SUPERO X8DTG-QF Manual de usuario

Supermicro

Supermicro P4DPR-iG2 Manual de usuario

Supermicro

Supermicro X13SCL-IF Manual de usuario

Supermicro

Supermicro Intel X12 Manual de usuario

Supermicro

Supermicro SUPER P6DGH Manual de usuario

Supermicro

Supermicro P3TDE6 Manual de usuario

Supermicro

Supermicro X11SCV-Q Manual de usuario

Supermicro

Supermicro X10DRS-2U Manual de usuario

Supermicro

Supermicro X11DGQ Manual de usuario

Supermicro

Supermicro X12DAi-N6 Manual de usuario

Supermicro

Supermicro SuperServer 6028U-TR4+ Manual de usuario

Supermicro

Supermicro C9Z490-PG Manual de usuario

Supermicro

Supermicro Supero H8SME-F Manual de usuario

Supermicro

Supermicro M11SDV-4C-LN4F Manual de usuario

Supermicro

Supermicro X6DA3-G2 Manual de usuario

Supermicro

Supermicro Supero X8DAE Manual de usuario

Supermicro

Supermicro X11DPL-i Manual de usuario

Supermicro

Supermicro X9DRL-3F Manual de usuario

Supermicro

Supermicro X11DPU Manual de usuario

Supermicro

Supermicro X10SDE-DF Manual de usuario

Supermicro

Supermicro C7Z170-OCE Manual de usuario

Supermicro

Supermicro X10SDV-TLN4F/F Series Manual de usuario

Supermicro

Supermicro P4SCi Manual de usuario

Supermicro

Supermicro X8OBN-F Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
