Super Circuits SYRF04 Manual de usuario

1www.supercircuits.com SYRF04_WebDemo_Q

6. Click OK, then click YES in the Warning window.

7. In the Internet Options window, click Apply, then click OK to close the window.

8. In the Internet Options window, click Apply, then click OK to close the window.

NOTE

If your computer operating system is Windows Vista or Windows 7, User Account Control can

interfere with the normal operation of the DVR user interface. To disable UAC, open the Control

Panel > User Account > User Account window, clear the Use User Account Control (UAC) to

help protect your computer check box, then click OK. A computer restart may be required.

9. In the IE URL eld, enter the IP address assigned to your DVR. For the Web Demo system, enter:

70.132.198.196

Continue ➥

Supercircuits SYRF04 System

Web Demo Quick Guide

You can access a Supercircuits model SYRF04 system, or DMR80U, DMR81U, or DMR82U DVR (and others)

with the Microsoft® Internet Explorer® (IE) browser. Before you can connect to it, however, you may need to

modify the security settings in your browser to load an ActiveX control.

To access a demo system, do the following:

1. At your Microsoft Windows® PC, open IE.

2. Open the IE Tools pull-down menu and

select Internet Options.

3. Click the Security tab.

4. Click the Custom Level... button. In the

Settings list.

5. In the list of Settings, change the following from Disable to Prompt:

Download unsigned ActiveX controls

Initialize and script ActiveX controls not marked as safe for scripting

11. After login, the DVR web display will appear. To see images from the cameras connected to your DVR, click

the Open All button in the lower left corner of the screen.

Logout

Open

All

NOTE

When viewing the DVR network browser interface, if the webpage appears normal but the camera

images are scrambled, check your computer’s video adapter settings, or call Supercircuits Support at

1.800.335.9777 for assistance.

12. To close the your connection to the DVR, click Logout (above the CH 1 window).

For specic instructions for using the DVR network browser interface, refer to the DVR User manual.

If a message appears to load an ActiveX control, right-click on the message, then click Run Add-on in

the popup window. Follow the prompts to Install the program, even if a warning message appears that the

publisher cannot be veried.

10. When the Login screen opens in the browser, enter the User Name and Pass Word, then click Login. For

the Web Demo system, he User Name is “demo”, and Pass Word is “1111”. Click Login. (Do not change

the Command Port entry (5050)).
