Sun-Tech ST240 Manual de usuario

ST240

User Manual

Suntech International Ltd.

ST240 User Manual

ST240 Installation Guide

1. Decide the location of ST240 and GPS Antenna, and check the cable ways.

-Check whether the location of ST 240 is far away from other electric equipment.

-GPS Antenna must have a sky-view and must be far away from other antenna.

2. Insert SIM card

Steps :

-Open the battery cover, pick out the battery pack.

-Insert SIM into holder and lock it

-Plug the battery connector as shown

ST240 User Manual

-Tighten the six screws

3. Connect Event lines with relevant lines of vehicle.

Event Cable Color pin Description

Red: VCC (8 - 30V)

-Connect the red line to 12 VDC /24 VDC Constant power of vehicle

Black: Ground

-Connect the black line to Ground of vehicle

-Blue: Ignition (8V - 30V) Connect the blue line to an ignition wire of vehicle

Caution : Never connect the red & blue lines together to a constant power source

ST240 User Manual

Yellow, Green, White “lines of event cable”

Orange, Brown “lines of event cable”

-Output line For siren or buzzer

-Immobilizer

4. Check GPS/GPRS operation and operation with LEDs.

It takes 3~10 minutes for GPS connected.

Green LED- indicates GPS status

RED LED- indicates GPRS status

Caution: Direction of ST240 is very important when installed in the vehicle. Make sure that

top side of ST240

ST240 User Manual

5. Trouble Shooting (LED Indicator)

- Blue LED: Indicates GPRS status.

GPRS Blink Count Remarks

Normal 1

Server Com. Error 2

1. Server or network parameter is wrong.

2. Server is closed.

3. Temporary network barrier

GPRS Com. Error 3

1. Network parameter is wrong.

2. SIM is blocked about GPRS using.

3. Temporary network barrier

4. Weak GPRS signal

5. GPRS antenna connection is not firm.

No Network 4

1. GPRS antenna is disconnected.

2. GPRS antenna or socket of GPRS antenna is broken.

3. Device is broken.

SIM PIN Locked 5

1. SIM PIN is enabled.

Cannot Attach

1. Weak GPRS signal.

2. GPRS antenna connection is not firm.

No SIM 7

1. There is no SIM or SIM is not inserted properly.

2. SIM or SIM socket is broken.

ST240 User Manual

- RED LED: Indicates GPS status.

GPS Blink Count Remarks

Normal 1

No Fix 2

1. If power on, GPS chipset is trying to find position during

some minutes.

2. GPS antenna lays on weak or no GPS signal position

3. GPS antenna connection is not firm.

GPS Chipset Error

GPS Antenna Error

1. GPS antenna is disconnected.

2. GPS antenna or socket of GPS antenna is broken.

3. Unit is broken.

The device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interface in a residential installation.

Cautions

Modifications not expressly approved by the party responsible for compliance could void

the user’s authority to operate the equipment.

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with minimum distance

20cm between the radiator & your body.

This transmitter must not be co-located or operating in conjunction with any other

antenna or transmitter.

NOTE : This equipment has been tested and found to comply with the limits for a Class B digital

ST240 User Manual

device, pursuant to Part 15 of the FCC Rules. These limits are frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular

installation.

If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

-- Consult the dealer or an experienced radio/TV technician for help.
