Digital Dual Video Satellite Receiver SRT 6158
User Manual
picture simulated
2
PART 1 l English
3
PART 1 l English
Thank you for choosing this Strong satellite receiver. This receiver is of our latest development and it is
designed to be capable of safely install your receiver and to achieve its optimum performance.
1.0 Usage
This user manual is applicable for Strong Digital Dual Video Satellite Receiver SRT 6158. We recommend
both first-time- and experienced users to read this manual in order to safely install the receiver. Strong
has supplied this product with the most recent innovations of software and hardware. Strong reserves
the Right to make changes in production to the software used by your satellite receiver without prior
notification. In order to maintain and ensure that your receiver is compatible and updated with the most
recent software technology, we recommend that you visit our website to check for the latest software.
4
PART 1 l English
Table of Contents
1.0 Usage 3
Table of Contents 4
1.1 Safety Instructions Warning 5
1.2 Features & Accessories 6
1.3 Safety Precautions 7
1.4 Storage 8
1.5 Equipment Set-up 8
2.0 Your Receiver 8
2.1 Front Panel 8
2.2 Rear Panel 9
3.0 Connections 10
3.1 Connecting to your TV & VCR 10
3.1.1 Basic connection with Scart cable
3.1.2 Basic connection with Scart cable and connection to digital audio
amplifier with S/PDIF 10
3.1.3 Connection with Audio Cable RCA Connectors 11
3.1.4 Connecting a serial cable for downloading software 11
3.2 Connecting to a satellite dish 12
3.2.1 Connecting a fixed satellite dish to your receiver 12
3.2.2 Connecting multiple fixed dishes to your receiver using a DiSEqC1.0 switch 12
4.0 Starting up 13
4.1 Starting up for the First Time 13
4.2 Dish aimed at other satellites 13
5.0 Basic settings 13
5.1 Main Menu 14
5.1.1 Channel Organizer Menu 14
5.1.2 Favourite Organizer Menu 17
5.1.3 The Timer Menu 17
5.1.4 The Installation Menu 18
5.1.5 Games 25
6.0 Recording to external device via VCR scart 26
6.1 How to record program to VCR scart 26
6.1.1 Manually Setup 26
6.1.2 Setup Recording by timer/EPG 27
6.2 VCR status 27
6.3 Stop Recording 27
6.4 Further information to recording function 28
7.0 Basic functions – Remote control 28
A.1 Trouble Shooting 31
A.2 Glossary of terms 33
5
PART 1 l English
1.1 Safety Instructions Warning:
DO NOT INSTALL YOUR RECEIVER:
n In a closed or poorly ventilated cabinet
n Directly on top of or under any another equipment
n On a surface which might obstruct the ventilation slots
DO NOT EXPOSE THE RECEIVER OR ITS ACCESSORIES:
n To direct sunlight or near any other equipment that generates heat
n To rain or intense moisture
n To any shock which may cause permanent damage to your receiver
n To any magnetic objects, such as loudspeakers, transformers, etc.
n To intense vibration
n Never open the cover. It is dangerous to touch the inside of the receiver due to high voltage
currents and possible electrical hazards. Your warranty will be void if the receiver has
been opened
n When the receiver is not used for a long period of time, you should unplug the power cord
from the wall socket
n Do not use a damaged power cord. It may cause fire or an electrical shock
n Do not touch a power cord with wet hands. It may cause an electric shock
n Place the receiver in a well-ventilated environment and make sure that the ventilation slots at
the sides and top of the unit remain uncovered at all times
n When you are connecting the cables, be sure that the receiver is disconnected from the mains
supply voltage
n Do not use your receiver in humid environment
Make sure you read this user manual before installing your receiver.
This manual provides complete instructions for installing and using this receiver.
The following symbols will be used as follows:
Bold Characters: Represents a button on the remote control or the receiver.
Italic Characters: Represents a menu item within the On Screen Display (OSD) Menu.
6
PART 1 l English
1.2 Features & Accessories
Digital Dual Video Satellite Receiver SRT 6158
n For all Free To Air digital TV - and Radio programmes
n Two separate integrated tuner which allow to watch one channel on TV output and to record
one separate channel to external device (VCR, DVD Recorder)
n TV-and Radio programmes can be automatically displayed or recorded to external device on
daily or weekly basis by using the timer function
n The easy to use Electronic Programme Guide (EPG) with Picture In Graphics (PIG) provides
you detailed programme information
n Easy timer programming by EPG, up to 7 days in advance
n User friendly menu, available in various languages ; English, German, French, Italian, Spanish,
Dutch, Russian, Turkish, Swedish, Slovaks, Hungarian, Czech, Bulgarian, Rumanian, Danish,
Finnish and Polish
n Support of DiSEqC 1.0
n Over 4000 channels memory capacity, Astra and Hot Bird pre-programmed
n Memory for Multi-satellite reception (up to 64)
n Four Favourite lists, for both TV and Radio
n Automatic channel search system with selectable search options
n Edit functions for TV- and Radio channel names
n Password protected access to menu and/or selectable programmes
n Digital Coaxial (S/PDIF) audio output
n Teletext via OSD or via TV (VBI)
n 7 Segment LED display in front panel showing programme number, time or status function.
n Future proof, supports software downloading via satellite (O.T.A.)
n 2 SCART connectors for two tuners
n 3 RCA connectors (Video- and Audio out)
n S-VHS output
n RS-232 connector for connection to PC (update and service functions)
Accessories:
n User’s Manual
n Remote control unit
n 2x Batteries (AAA type)
Note: The batteries should not be recharged, disassembled, electrically short-circuited or be mixed or
used with other types of batteries
7
PART 1 l English
1.3 Safety Precautions
To maintain your receiver’s optimum performance, you are advised to apply the following safety precautions:
n Read this manual carefully and make sure you fully understand the instructions given
n Refer all maintenance or servicing to suitably qualified personnel
n If you wish, you may clean your receiver with a soft lint-free cloth slightly made damp with a
mild soap solution, only after disconnecting from the mains voltage supply
n Do not use alcohol or ammonia based liquids to clean the receiver
n Do not open the receiver cover, as you will be exposed to a shock hazard
n Do not open the receiver cover this will void your warranty
n Do not place any objects on top of the receiver because this might prevent proper cooling of
the components inside
n Make sure no foreign objects fall through the ventilation slots because this could cause fire or
an electric shock
n Wait a few seconds after switching off the receiver before you move the receiver or disconnect
any equipment
n Please ensure that the electrical power supply corresponds with the voltage on the electrical
identification plate at the back of the receiver
n It is a necessity that you only use an approved extension and compatible wiring that is suitable
for the electrical power consumption of the installed equipment
n If the receiver does not operate normally even after strictly following the instructions in this
user manual, it is recommended to consult your dealer
1.4 Storage
Your receiver and its accessories are stored and delivered in a well protective packaging against electric
shocks and moisture. When unpacking it, make sure that all the parts are included and keep packaging
away from children. When transporting the receiver from one place to another or if you are returning it
under warranty make sure to store the receiver in its original packaging with its accessories. Failing to
comply with such packaging procedures could void your warranty.
8
PART 1 l English
1.5 Equipment Set-up
We recommend you to consult a professional installer to set up your equipment. Otherwise, please
follow the following instructions:
n Refer to the user manual of your TV and dish
n Make sure that the SCART cable is in a good condition
n Make sure that the SCART cable connections are well shielded
n Make sure that the outdoor components of the dish are in good condition
n Make sure that the dish is aimed at the satellite of your choice
n Make sure that the dish is connected with the correct R.F. coaxial cable (75 Ohm) and is in
good condition
2.0 Your Receiver
2.1 Front Panel
(Please see inside cover Figure 1)
1. Power Button
Turns the receiver ON/Standby.
2. Stand-BY/ ON, TV SIGNAL and VCR SIGNAL (3 LEDs)
The ON/Std.By LED indicates if box is in Standby-mode (red light) or powered on (green light). The
orange (VCR signal) and red LED (TV signal) are lights up once you correctly receive a satellite signal on
both LNB inputs (signal locked).
3. UP/DOWN Buttons
Move the cursor UP/DOWN in Menu state. Changes the channels UP/DOWN in no menu state.
4. LED Display
This 4-digit LED panel indicates the time, programme number or function mode.
9
PART 1 l English
2.2 Rear Panel
(Please see inside cover Figure 2)
1. LNB IN 1 = SAT IN 1 (for TV tuner)
Connect one digital signal from your LNB of your satellite dish to this connector.
2. LNB IN 2 = SAT IN 2 (for VCR tuner)
Connect one digital signal from your LNB of your satellite dish to this connector.
3. AUDIO Right (Red RCA) and Left (White RCA)
These connectors give you the possibility to connect the audio signal to an external amplifier or to the
audio input of your TV.
4. VIDEO (YELLOW RCA)
This connector has a constant video signal for additional device.
5. TV Scart Connector
Use this connector to connect your receiver to your TV using a scart cable.
6. VCR Scart Connector
Use this connector to connect second tuner of receiver to alternate device (TV/VCR/DVD Recorder) using
a scart cable.
7. RS-232 Serial Port
This serial port can be used to connect your PC to your receiver, and enables you to download new
versions of software into your receiver. Detailed information about downloading software into your
receiver can be found on our website (www.strongsat.com).
Note: It is recommended to ONLY use the original software provided via our website. Loading other
versions of software not adapted to your model number can cause severe damage to your
receiver, and will not be covered by the warranty.
8. S/PDIF
Use coaxial or optical output to connect your receiver to the input of your digital audio amplifier.
10
PART 1 l English
9. S-Video Output (SVHS)
Analogue video output for connection to Home cinema systems with similar input connectors.
10. Power Cord
Your receiver requires a mains voltage supply of 90 ~ 240 V AC (Auto-selectable), 50 ~ 60 Hz +/- 5 %.
Make sure to check the power specification of the wall outlet before connecting your receiver to the
main power.
Direct entry of numerical functions in the menus or in channels selection
3.0 Connections
3.1 Connecting to your TV & VCR
Warning:
If you are not sure how to connect your receiver, do not take the risk of doing it yourself. Ask your Strong
dealer to do it for you.
They are specially trained by our technicians and can get the best performance out of your receiver.
Although there are enthusiasts who can do the installation of a satellite receiver unit themselves, it
usually needs good knowledge of the reception technologies and requires specialised equipment. Do not
hesitate to ask any questions you have to your Strong dealer about installing your receiver. It is possible
to connect the receiver through the use of SCART cables, and/or so called Audio/Video cables with RCA
connectors.
Note: It is recommended to connect two signal cable from same satellite directly to both LNB input.
3.1.1 Basic connection with Scart cable
(Please see inside cover Figure 4)
n Connect two satellite signals from LNB to the LNB IN 1 and LNB IN 2 connector.
n Connect the TV scart connector at the back of the receiver to the scart-in connector on your TV set.
n Connect the VCR scart connector at the back of the receiver to the scart-in connector of second
device (further TV, VCR or DVD recorder).
Tabla de contenidos
Otros manuales de Receptor de Strong
Strong
Strong SRT 7030 Manual de usuario
Strong
Strong SRT 8527 Manual de usuario
Strong
Strong SRT 4620 Manual de usuario
Strong
Strong SRT 8410 Manual de usuario
Strong
Strong SRT 7006 Instrucciones de funcionamiento
Strong
Strong Srt Ant 10 Eco Manual de usuario
Strong
Strong SRT 2221 Manual de usuario
Strong
Strong SRT 4663XII Manual de usuario
Strong
Strong PRIMA V Manual de usuario
Strong
Strong SRT 7815 Manual de usuario
Strong
Strong SRT 630WS Manual de usuario
Strong
Strong SRT 6500 CI Manual de usuario
Strong
Strong SRT 5002 ECO Manual de usuario
Strong
Strong SRT 51 Manual de usuario
Strong
Strong SRT 5202 Manual de usuario
Strong
Strong PRIMA II Guía de configuración
Strong
Strong SRT 6201 Manual de usuario
Strong
Strong PrimaSat II Manual de usuario
Strong
Strong PrimaSat II Manual de usuario
Strong
Strong SRT 4300 Manual de usuario
