DisplayPort KVM Switch

2-Port Professional USB,

DisplayPort KVM Switch with

Hotkey Control

SV231DPU

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction..................................................................... 1

Packaging Contents.....................................................................1

System Requirements .................................................................1

Installation....................................................................... 1

Hardware Installation...................................................................2

Driver Installation.........................................................................4

Operation......................................................................... 4

Front Panel ..................................................................................4

HotKey Control ............................................................................4

Alternative Hotkey Commands ....................................................7

Speciﬁcations.................................................................. 8

Technical Support........................................................... 9

Warranty Information...................................................... 9

Introduction

Packaging Contents

1 x SV231DPU KVM switch•

1 x Power Adapter•

1 x Rubber Feet•

1 x Instruction Manual•

System Requirements

DisplayPort enabled computer system•

USB enabled computer system•

Standard 104-key USB keyboard•

Standard 3-button USB mouse•

Installation

NOTE: Prior to the installation, please power off all devices that will be

connected to this system.

Ensure that all devices you will connect are properly grounded.

Place cables away from ﬂuorescent lights, air conditioners, and

machines that are likely to generate electrical noise.

If you experience any problems using a USB KVM switch, the

following BIOS setup changes may be necessary for PC users and not

necessary for Mac users:

Set HALT ON ERROR to ALL BUT KEYBOARD.•

In PNP AND PCI SETUP, set PNP OS INSTALLED to YES and set•

USB IRQ to ENABLED.

Different systems may use different naming, so contact your system

manufacturer for further assistance with these settings.

Hardware Installation

PC1 Link/

Selection

LED PC2 Link/

Selection

LED

Port

Selection

Button

PC1 Port

PC2 Port

USB Hub

port

USB

Keyboard

port

USB Mouse

port

Monitor

DisplayPort

port

External

power port

Front View

Rear View

*installation pictures are representations only

Plug a monitor into the Console’s DisplayPort connector; plug a USB1.

keyboard and a USB mouse into the dedicated USB keyboard and

mouse ports on the KVM switch.

Use a male-to-male DisplayPort video cable to connect the2.

DisplayPort connector on the computer’s video card, to one of the

KVM’s PC ports (ie. PC1)

Use a USB type A-B Cable to connect the KVM’s USB port (type B,3.

square connector) for the PC port used in Step 2, and the USB port

on the computer (type A, ﬂat connector).

Repeat for Steps 2 and 3 for each PC port on the KVM switch, or4.

each computer you wish to use on the KVM.

Driver Installation

No driver installation is required for the KVM switch, as the keyboard

and mouse uses native USB keyboard/mouse drivers that are already

installed on all operating system that fully support USB.

Operation

Front Panel

PC Link/Selection LED

The LED turns green when the connected computer is powered-on.

The corresponding LED will also illuminate red when that PC port is

currently selected.

Port Selection Button

Pushing the front panel “Select” button toggles between the PC ports

on the KVM switch.

HotKey Control

A Hotkey command is a short keyboard sequence for selecting a

computer, activating computer scan, etc. A hotkey sequence starts

with two left Ctrl keystrokes ( successively within 0.2 seconds )

followed by one or two more keystrokes. A built-in buzzer generates a

high-pitch beep for correct hotkey command; otherwise, one low-pitch

beep is generated for errors and the bad key sequence will not be

forwarded to the selected computer.

NOTE: Press and hold Left Shift and press Num Lock twice, then

release Shift followed by pressing left Ctrl once, which will enable /

disable the hotkey feature.

To select a computer:

Left Ctrl + Left Ctrl + 1

(Example: Selects the computer at port 1.)

Left Ctrl + Left Ctrl + 2

(Example: Selects the computer at port 2.)

NOTE: Do not use the keypad on the right-side of the keyboard.

Auto Scan

The KVM automatically scans through the powered-on computers in

sequence on a ﬁxed time interval (see Scan Time below).

Note: The keyboard and mouse are not operable during Auto Scan.

To start Auto Scan:

Left Ctrl + Left Ctrl + F1

To abort the Auto Scan mode, press the left Ctrl key twice. When

Auto Scan detects any keyboard or mouse activity, it suspends the

scanning till the activity stops; it then resumes with the next computer

in sequence. The length of the Auto Scan interval (Scan Rate) is

adjustable, see below.

Manual Scan allows users to manually switch back and forth between

power-on computers.

Left Ctrl + Left Ctrl + F2

To select the previous or the next computer, press <UP> or <DOWN>

arrow keys. To abort the Manual Scan, press any other key.

Scan Time

Four options are available for users to set the Scan Time duration, it

Includes 3, 8, 15 and 30 seconds.

Note: Scan Time is set to 3 seconds by default.

To adjust Scan Rate, set the scan time of duration before switching to

the next computer:

Left Ctrl + Left Ctrl + F3

The KVM Switch generates 1 to 4 beeps indicating a scan time

duration for 3, 8, 15 or 30 seconds respectively.

USB-Port Rule

There are two settings for USB-Port Rule: ON or OFF.

When set to ‘ON’, the USB Hub port follows computer selection.

When set to ‘OFF’, the USB Hub port stays on the currently selected

PC port.

USB 1: pressing the hotkey below to turn ON/OFF the USB-Port Rule:

Left Ctrl + Left Ctrl + F7

Enforce the USB following with the selected computer by pressing the

following hotkey:

Left Ctrl + Left Ctrl + U

NOTE: Please make sure that linking procedure of USB device has

been accomplished before switching to the next computer.

Alternative Hotkey Commands

In addition to the Left Ctrl + Left Ctrl hotkeys, there are two alternative

hotkey sequences available.

For the following operations, users may press Scroll Lock twice1.

instead of pressing Left Ctrl twice.

To select a computer:

Scroll Lock + Scroll Lock + 1

(Example: Select the computer at port 1.)

Scroll Lock + Scroll Lock + 2

(Example: Select the computer at port 2.)

NOTE: Do not use the keypad at the right of the keyboard.

For those keyboards that do not have or support Scroll Lock, please2.

press and HOLD the Left Shift and press Num Lock twice instead of

pressing Left Ctrl twice.

To select a computer:

Hold Left Shift + Press Num Lock + Press Num Lock then

release shift + Press 1

(Example: Select the computer at port 1.)

Hold Left Shift + Press Num Lock + Press Num Lock then

release shift + Press 2

(Example: Select the computer at port 2.)

NOTE: Do not use the keypad at the right of the keyboard.
