StarTech.com StarView SV211KA Manual

StarView KVM with Audio

SV211KA

SV411KA Instruction Guide

The Professionals’ Source For Hard-to-Find Computer Parts

KKVVMMSSWWIITTCCHH

* Actual product may vary from photo

* SV411KA shown

FCC COMPLIANCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Using Your KVM Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Introduction

Thank you for purchasing a StarTech.com two or four port StarView KVM switch with

audio. You can now connect your computers to a single keyboard, mouse, monitor,

microphone, and speakers, sparing you the clutter of extra consoles or peripherals. The

switch is up and running with only a few simple cable connections, and switching

between computers is as easy as a push button or hot-key combination.

Features

•Supports most microphones and speakers

•Supports hot-plugging of PS/2 keyboards or mice

•Works with M/S Intellimouse (Pro), Explorer, optical mice

•Performs sequential auto-scan of all computers

•Saves and restores keyboard states when switching computers

•Acts independently of operating system

•Supports high VGA resolution of 1920x1440 (DDC2B compatible)

•Backed by StarTech.com's one year warranty

Before You Begin

To ensure a quick and easy switch installation, please read through this section carefully

before attempting to install the switch.

System Requirements

•IBM compatible computers

•One monitor (must be capable of synchronizing with each computer's video signal.

Check your monitor's user manual for more information)

•One PS/2 keyboard and mouse

•One set of speakers

•One microphone

Contents

This package should contain:

•1x KVM switch

•SV211KA: 2 x 6 ft (1.8m) 3-in-1 cable set, 4 x 6 ft (1.8m) custom audio cable set

•SV411KA: 4 x 6 ft (1.8m) 3-in-1 cable set, 8 x 6 ft (1.8m) custom audio cable set

Installation

This section will guide you through the installation of your KVM switch. Please read

through the instructions carefully and complete each step in the order listed.

NOTE: Make sure that all devices are turned off before beginning installation.

Connecting the switch

1. Plug your monitor into the labeled HDB-15 port on the left side of the back of the

switch.

2. Plug your PS/2 keyboard and mouse into the labeled mini-DIN-6 ports on the right

side of the switch.

3. Plug your speakers and microphone into the labeled ports on the left side of the back

of the switch.

Back

Monitor

Speaker Microphone PC Speaker

Cable PC Microphone

Cable

PC Monitor

Cable

Side

Mouse Keyboard Power Supply

(Optional)

Connecting the computers

1. Connect the single end of the 3-in-1 cable into an open HDB-15 port on the back of

the switch.

2. Plug the blue monitor, purple keyboard, and green mouse cables into the ports on the

back of the computer.

3. Plug one end of the pink microphone cord into the mic port on the switch and the

other end into the mic port on your computer.

4. Plug one end of the green speaker cord into the speaker port on the switch and the

other end into the speaker port on your computer.

Repeat steps 1-4 for any other computers you want to connect to the switch. Your KVM

switch is now ready for use.

Using Your KVM Switch

NOTE: Only the LEFT Control key works for hot-key sequences.

Switching Computers

The LEDs on the front panel of the switch indicate which computer is active. To switch

between computers, either use the push-button on the front of the switch to scroll

through the computers, or hit the left Control key twice followed by the port number (for

example, to select the computer plugged into port 2, type left Ctrl + left Ctrl + 2).

Using Auto Scan

When auto scan mode is started, the switch will automatically scan through the attached

computers at user-defined intervals. Any keyboard or mouse activity will suspend the

auto scan, but once the activity ceases, auto scan will begin again.

•To start auto scan, type left Ctrl + left Ctrl + F1.

• To end auto scan, type left Ctrl + left Ctrl.

•To adjust the scan rate, type left Ctrl + left Ctrl + F3 and choose between 3 (default),

8, 15, or 30 seconds.

Manual Scan

To manually scan back and forth between computers, type left Ctrl + left Ctrl + F2. Use

the up and down arrow keys to select the previous or next computer. Pressing any other

key will abort the manual scan.

Keyboard Rates

To adjust the keyboard typematic rate, type left Ctrl + left Ctrl + F4 and select from 10

(default), 15, 20, or 30 characters/second.

NOTE: This will override the typematic rate set in your BIOS or operating system.

Troubleshooting

If you encounter any problems, first make sure all cables are firmly seated at both ends

and connected to their proper ports.

Problem: Keyboard or mouse doesn't work.

Cause: Improper power-up sequence. Keyboard or mouse has not initialized properly.

Solution: Press and hold the push-button for 3 seconds. This switch will reinitialize the

device. If the problem persists, unplug the device, wait a few seconds, and plug it

back in. Also remember that the switch does not support serial mice.

Problem: Keyboard error while booting up.

Cause: Loose keyboard connection.

Solution: Make sure keyboard cables are well-seated and in its proper ports.

Problem: Keyboard strokes are shifted.

Cause: The computer was in a shifted state when last switched.

Solution: Press both Shift keys.

Problem: The switch occasionally fails to function.

Cause: Computers are not supplying enough power.

Solution: Connect a DC 9V 500mA power adapter (not included) to output jack.

Problem: Scan or Typematic rate has changed.

Cause: All connecting computers were turned off and the switch has reset to default

settings.

Solution: Manually set the rates again and keep at least one computer on at all times.

Product Specifications

SV211KA SV411KA

Console ports 1 1

Computer ports 2 4

Port selection button 1 1

Hot plug-and-play Yes Yes

Hot-key control Yes Yes

VGA 1920 x 1440, DDC2B 1920 x 1440, DDC2B

Computer connector HDB-15 x 2, Stereo jack x 4 HDB-15 x 4, Stereo jack x 8

Console connector Keyboard: PS/2 Keyboard: PS/2

Mouse: PS/2 Mouse: PS/2

Monitor: HDB15 Monitor: HDB15

Speaker/Mic: Stereo jack x 2 Speaker/Mic: Stereo jack x 2

Auto scan interval 3, 8, 15, 30 seconds 3, 8, 15, 30 seconds

KVM cable length 6 ft (1.8m) 6 ft (1.8m)

Audio cable length 6 ft (1.8m) 6 ft (1.8m)

Power free operation Yes Yes

Technical Support

The following technical resources are available for this StarTech.com product:

On-line help:

We are constantly adding new information to the Tech Support section of our web site. To

access this page, click the Tech Support link on our homepage, www.startech.com. In the

tech support section there are a number of options that can provide assistance with this

card.

Knowledge Base - This tool allows you to search for answers to common issues using

key words that describe the product and your issue.

FAQ - This tool provides quick answers to the top questions asked by our customers.

Downloads - This selection takes you to our driver download page where you can

find the latest drivers for this product.

Call StarTech.com tech support for help: 1-519-455-4931

Support hours: Monday to Friday 9:00AM to 5:00PM EST (except holidays)

Warranty Information

This product is backed by a one-year warranty. In addition StarTech.com warrants its

products against defects in materials and workmanship for the periods noted below,

following the initial date of purchase. During this period, the products may be

returned for repair, or replacement with equivalent products at our discretion. The

warranty covers parts and labor costs only. StarTech.com does not warrant its products

from defects or damages arising from misuse, abuse, alteration, or normal wear and

tear.

Limitation of Liability

In no event shall the liability to StarTech.com Ltd. (or its officers, directors, employees or

agents) for any damages (whether direct or indirect, special, punitive incidental,

consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss,

arising out of related to the use of the product exceed the actual price paid for

the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Revised: June 9, 2003
