USB 2.0 KVM Switch

SV231USB

SV431USB Instruction Manual

Actual product may vary from photo

2 Port StarView USB KVM Switch Kit with Cables

4 Port StarView USB KVM Switch

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

PC BIOS Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Console Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Computer Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Auto Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Rackmount Kit for SV431USB (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Instruction Manual

The StarView SV231USB and SV431USB, fully compatible with USB 2.0 specifications,

are a combination of USB 2.0 KVM (Keyboard/Video/Mouse) switches and USB 2.0

peripherals sharing devices.

With the SV231USB and SV431USB, you can easily operate up to 2 or 4 PCs, G3/G4

Macs, or iMacs respectively from the 1 USB keyboard, 1 USB mouse, and 1 monitor

saving you space, time, equipment and money. Its peripheral sharing function enables

you to share more USB 2.0 peripherals among all computers. Installation is easy as

connecting USB A-B cables to the computers and to the StarView switch.

IInnttrroodduuccttiioonn

Features

BBeeffoorreeYYoouuBBeeggiinn

•Front panel push buttons for easy computer selection

•No drivers needed for keyboard and mouse operation

•Supports keyboard and mouse plug-n-play

•High VGA resolution: 1920 x 1440

•Buzzer sounds for computer switching confirmation

•Front button Auto Scan activation

•Selectable Scan Time interval

•1x StarView USB KVM Switch

Package Contents

•1 x Instruction Guide

•1 x Power Adapter (only SV231USB)

•2 x 2-in-1 USB/Monitor cables (only SV231USB)

This package should contain:

•One VGA, SVGA or Multisync monitor

System Requirements

•One USB 2.0 keyboard

•One USB 2.0 mouse

Console side

Instruction Manual

System Requirements Cont’d

Computer side

•One HDB15 male-to-female VGA cable or monitor

•One USB 2.0 A-B cable with Type-A and Type-B plug for USB devices

Each USB 2.0 enabled computer must be connected to the StarView switch by:

•HDB-15 to DB-15 VGA adapter is required for Mac computer VGA ports

SVUSB2N1_6

6 ft. USB + VGA 2-in-1 KVM Switch Cable

SVUSB2N1_10

10 ft. USB + VGA 2-in-1 KVM Switch Cable

AAcccceessssoorryyPPrroodduuccttssffrroommSSttaarrTTeecchh..ccoomm

Contact your local StarTech.com dealer or visit www.startech.com for cables or other

accessories that will help you get the best performance out of your new product.

SVUSB2N1_15

15 ft. USB+VGA 2-in-1 KVM Switch Cable

SVUSBPOWER

SV231USB & SV431USB Power Adapter DC5V

Instruction Manual

IInnssttaallllaattiioonn

The following BIOS setup changes are necessary for PC users and not necessary

for Mac users:

1. In STANDARD CMOS, set HALT ON ERROR to ALL BUT KEYBOARD

2. In PNP and PCI SETUP, set PNP OS INSTALLED to YES and set USB IRQ to

ENABLED Note: The StarView switch is applicable for USB 2.0 keyboard and mouse

switching from one computer to the other. If you plan to share other peripherals such

as a CCD camera, printer or scanner, it is necessary to shut down the driver of the

computer before switching to another computer. Because port switching is equivalent

to unplugging the USB cable from one computer and plugging it into another one,

some USB drivers check attached USB peripherals all the time and do not accept

plug-n-play functions.

Before installation, make sure all devices and computers to be connected to the StarView

switch have been turned off. Plug a monitor to the Console’s VGA port; plug a USB 2.0

keyboard and a USB 2.0 mouse Console’s USB ports as shown in figure 2. For

SV431USB only

: As an option, the Master StarView is either SV431 or SV431D to be

linked to the SV431USB with a mini-DIN8 male-to-male cable. The SV431USB can

operate as USB 2.0 peripheral sharing devices

PC BIOS Notice

Console Connection

SV231USB

SV431USB

123

USB Keyboard

USB Mouse

USB Device

Instruction Manual

Computer Connection

Use a HDB15 male-to-female cable to connect from a computer’s VGA port to the

StarView’s VGA port of the PC side, as shown below.

Use a USB 2.0 A-B cable to connect from the StarView’s USB 2.0 port on the

corresponding computer (A connector is the flat connector) as shown below.

Female to Male HDDB15

for VGA

One USB Patch Cable for

both Keyboard and Mouse

Female to Male HDDB15

for VGA

One USB Patch Cable for

both Keyboard and Mouse

Instruction Manual

OOppeerraattiioonn

Front Panel

1. On-line LED and Selected LED:

When the LED turns green, the connected computer is powered-on. When a computer

is selected its corresponding red LED illuminates.

2. Push buttons:

Each computer has a button associated with it on the front panel for selection.

Auto Scan

Auto Scan automatically scans through computers one by one in a fixed interval (see

Scan Time below). Note: keyboard or mouse is not operable during Auto Scan.

For SV231USB

It sets the scan interval for Auto Scan. The Scan Time options are 3, 8, 15 and 30

seconds. Note: Scan Time is automatically set to the default of 3 seconds when the KAG

switch loses power.

For SV431USB

To activate Auto Scan, press down front panel push buttons “3” and “4” simultaneously.

The port LED flashes during Auto Scan. Auto Scan is effective for powered-on

computers only. To exit the Auto Scan mode, just tap any one of the pushbuttons.

To change the Scan Time interval, press both front panel buttons “1” and “2”

simultaneously. The Sv431USB beeps 1, 2, 3 or 4 times for Scan Time of 3, 8, 15 or 30

seconds respectively.

Instruction Manual

Rack Mount Kit for SV431USB (optional)

The figure below shows how to attach optional mounting brackets and cable support to

the SV431USB for standard 19-inch rack cabinet.

To the Rack Cabinet

back post

Keyboard, Mouse,

Monitor cables to the

StarView KVM Switch

Two screws secure

the cable support

Keyboard, Mouse,

Monitor cables to

the computer

To the Rack Cabinet

back post

Instruction Manual

SSppeecciiffiiccaattiioonnss

TTrroouubblleesshhoooottiinngg

Symptom Causes Solutions

Keyboard or

mouse does not

work

In Auto Scan, keyboard and mouse are

not operable. Too many keyboard or

mouse drivers installed.

Press any front button to select a computer, then use

the keyboard and mouse. Remove ALL unnecessary

keyboard and mouse drivers.

Newly installed

USB device does

not work.

Improper device driver. Device consumes

too much power. Device consumes too

much power instantaneously.

Improper device initialization. When

StarView switch works under self-power,

i.e., no power supply added, it supports

max of 100mA as per USB spec.

Re-install device driver. The device should be self-

powered, add a power adapter to the device. If the

device does not provide power jack, add a power

adapter of less than 1A current rating to the StarView

switch Be sure the USB cable is well seated to

ensure communication. Remove all power sources

to the StarView by unplugging all USB A-B cables

and the power adapter; then start all over again.

Select the computer by pushbutton, restart the

computer and try again.

Computer hangs

up while

switching

computers.

Device initialization takes too much time.

Wait at least 5 seconds before computer switching to

ensure proper USB communication. Turn off device

driver (not keyboard or mouse) before computer

switching.

Auto Scan does

not switch PC

automatically

and StarView

beeps.

All PCs are off or only one PC is turned

on. Scan mode works for power-on

computers only.

Turn computers on.

Otros manuales para StarView SV231USB

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de StarTech.com

StarTech.com

StarTech.com SV431DPDDUA2 Manual de usuario

StarTech.com

StarTech.com SV231DPUA Manual de usuario

StarTech.com

StarTech.com ICUSB23216FD Manual de usuario

StarTech.com

StarTech.com StarView SV221DVIDD Manual

StarTech.com

StarTech.com C2-H46-UAC-CBL-KVM Manual de usuario

StarTech.com

StarTech.com HB31C3A1CDPPD3 Manual de usuario

StarTech.com

StarTech.com SV231DPUCA Manual de usuario

StarTech.com

StarTech.com ST12MHDDCRP Manual de usuario

StarTech.com

StarTech.com 8STSV431DPDDUA2 Manual de usuario

StarTech.com

StarTech.com MSTCDP122HD Manual de usuario

StarTech.com

StarTech.com SV231DDVDUA Manual de usuario

StarTech.com

StarTech.com IES81GPOEW Manual de usuario

StarTech.com

StarTech.com IES51000 Manual de usuario

StarTech.com

StarTech.com SV1115IPEXT Manual de usuario

StarTech.com

StarTech.com SV231MDPU2 Manual de usuario

StarTech.com

StarTech.com IES61002POE Manual de usuario

StarTech.com

StarTech.com StarView SV231USBGB Manual de usuario

StarTech.com

StarTech.com SV431HU34K6 Manual de usuario

StarTech.com

StarTech.com IESC1G80UP Manual de usuario

StarTech.com

StarTech.com ST4300USBM Manual de usuario

StarTech.com

StarTech.com CPNT410IR Manual de usuario

StarTech.com

StarTech.com V231DVIUDDM Manual de usuario

StarTech.com

StarTech.com ICUSB2322I Manual de usuario

StarTech.com

StarTech.com ST4200USB Manual

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
