StarTech.com SV431HDU3A Manual de usuario

Manual Revision: 03/31/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

SV231HDU3A / SV431HDU3A

2/4 Port SuperSpeed USB 3.0 HDMI® KVM

Switch with Audio and Cables

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View - SV231HDU3A..................................................................................................................... 1

Rear View ..................................................................................................................................................... 1

Front View - SV431HDU3A..................................................................................................................... 2

Rear View ..................................................................................................................................................... 2

Introduction............................................................................................3

Packaging Contents ................................................................................................................................. 3

System Requirements.............................................................................................................................. 3

Installation ..............................................................................................4

Hardware Installation .............................................................................................................................. 4

Driver Installation...................................................................................................................................... 4

Operation ................................................................................................5

Front Panel................................................................................................................................................... 5

Hotkey Control........................................................................................................................................... 5

Specications..........................................................................................8

Technical Support ..................................................................................9

Warranty Information............................................................................9

Instruction Manual

Product Diagram

Front View - SV231HDU3A

Rear View

USB Hub

Selection LED

Port Selection

Button / LED

PC1

connectors

USB Keyboard/

Mouse

Connectors

Console HDMI

Connector

(output)

DC Power

Connector

USB 3.0 HUB

connectors

3.5mm Audio

Speaker/Mic

Instruction Manual

Front View - SV431HDU3A

Rear View

USB Hub

Selection LED

Port Selection

Button / LED

PC1

connectors

USB Keyboard/

Mouse

Connectors

DC Power

Connector

USB 3.0 HUB

connectors

3.5mm Audio

Speaker/Mic

Console HDMI

Connector (output)

Instruction Manual

Introduction

Packaging Contents

SV231HDU3A

• 1 x 2 Port USB 3.0 KVM Switch

• 2 x HDMI M/M Cables

• 2 x USB 3.0 A-B Cables

• 2 x 3.5mm Audio/Mic Cables

• 1 x Universal Power Adapter (NA/ UK/ EU)

• 1 x Instruction Manual

SV431HDU3A

• 1 x 4 Port USB 3.0 KVM Switch

• 4 x HDMI M/M Cables

• 4 x USB 3.0 A-B Cables

• 4 x 3.5mm Audio/Mic Cables

• 1 x Universal Power Adapter (NA/ UK/ EU)

• 1 x Instruction Manual

System Requirements

• One HDMI display device (i.e. monitor, projector, TV, etc.)

• An HDMI output for each computer

• USB enabled computer system with available USB port

• Standard 104-key keyboard

• Standard 3-button mouse

Instruction Manual

Installation

Hardware Installation

1. Connect an HDMI monitor into the Console’s HDMI connector; plug a USB keyboard

and a USB mouse into the dedicated USB keyboard and mouse ports on the KVM

switch. If using audio, also connect speakers with 3.5mm mini-jack plugs.

2. Use a male-to-male HDMI video cable to connect the HDMI connector on the

computer’s video card, to the HDMI ports for one of the KVM’s PC ports (i.e. PC1).

3. Use a USB type A-B Cable to connect the KVM’s USB port (type B, square connector)

for the PC port used in Step 2, and the USB port on the computer (type A, at

connector). If using audio, connect 3.5mm mini-jack cables from the PC port to the

sound card.

4. Repeat Steps 2 and 3 for each PC port on the KVM switch, or each computer you

wish to use on the KVM.

5. OPTIONAL: Connect any other USB peripherals you wish to share between the

connected computers/devices to the extra USB Hub port on the Console side.

6. Connect the external power adapter from a wall outlet to the power connector on

the rear panel of the KVM switch.

7. Power up the rst computer/device and wait for it to fully boot and test keyboard/

mouse functionality.

8. Once operation has been successfully conrmed, switch to the next port and power

up that computer/device and conrm.

9. Once completed for all computers/devices connected to the KVM switch, you

should be able to switch between ports freely.

Driver Installation

No driver installation is required for the KVM switch, as the keyboard/mouse use USB

drivers that are already installed on any operating system that fully supports USB.

Instruction Manual

Operation

Front Panel

The front-panel Smart Touch button allows you a direct control over KVM switching

operation. Simply press the button to switch to the respective PC port. For more

operation about Smart Touch button, please refer to “Quick Reference Sheet”.

Hotkey Control

A Hotkey command is a short keyboard sequence for selecting a computer, activating

computer scan, etc. A hotkey sequence starts with two left <ScrLk> keystrokes

(successively within 2 seconds) followed by one or two more keystrokes. A built-in

tone generator creates a high-pitch beep for correct hotkey command; otherwise, one

low-pitch beep is generated for errors and the bad key sequence will not be forwarded

to the selected computer.

Please refer to the “Quick Reference Sheet” for available commands

Quick Reference Sheet

Command Hotkeys

Front-Panel

Smart Touch

Button

Description

Select PC Port

(Jointly select

PC port/ hub

port control/

audio&mic,

if binding is

enabled)

ScrLk + ScrLk +

(1~2/1~4)

Touch the

corresponding

button to select

the active PC port.

Select the PC port

Instruction Manual

Quick Reference Sheet

Command Hotkeys

Front-Panel

Smart Touch

Button

Description

Select Audio&Mic

Port (Jointly

select PC port

and audio&mic,

if binding is

enabled)

ScrLk + ScrLk +

F5~F6/F5~F8 -- Move audio&mic

port

Bind PC and

Audio&Mic

Switching

ScrLk + ScrLk + Q -- Bind PC Port with

audio&mic Port

Unbind PC and

Audio&Mic

Switching

ScrLk + ScrLk + W --

Unbind PC port

with audio&mic

Port

Previous PC port

(Jointly select PC/

hub port control)

ScrLk + ScrLk + Up

Arrow -- Next lower PC Port

Next PC port

(Jointly select PC/

hub port control)

ScrLk + ScrLk +

Down Arrow -- Next higher PC

Port

Instruction Manual

Quick Reference Sheet

Command Hotkeys

Front-Panel

Smart Touch

Button

Description

Previous active PC

port

ScrLk + ScrLk +

[Backspace] -- Previous active

PC Port

Beeper ScrLk + ScrLk + B -- Toggle Beeper

On/O

Dene Hotkey

Preceding

Sequence

ScrLk + ScrLk +

H+ [ScrLk/CapsLk/

Esc/F12/ NumLk/

left Ctrl/ right Ctrl]

Press and hold

down last button

(Button 2/

Button 4) till two

beeps. Release

the button, and

press desired

hotkey preceding

sequence.

Select Hotkey

Header [ScrLk/

CapsLk/ Esc/ F12/

NumLk/ left Ctrl/

right Ctrl]

Autoscan ScrLk + ScrLk + S -- Start Autoscan

Autoscan with

Programmable

Delay Time

ScrLk + ScrLk + S

+ (1~6)

1 10s ; 2 20s ;

3 30s ;

4 40s ; 5 50s ;

6 60s

Autoscan duration

adjust to (10~60

seconds)

Stop Autoscan [Any key] Touch any button Stop Autoscan

during scan mode
