StarTech.com DVI2HDMI Manual de usuario

DVI2HDMI

DVI and Digital Audio to

HDMI Converter

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide rea-

sonable protection against harmful interference in a residential installation. This equip-

ment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio com-

munications. However, there is no guarantee that interference will not occur in a particu-

lar installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an en-

dorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this doc-

ument, StarTech.com hereby acknowledges that all trademarks, registered trademarks,

service marks, and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

Instruction Manual

Table of Contents

Introduction .................................................................... 1

Package Contents .......................................................................1

Operating Controls & Functions.................................... 2

Speciﬁcations.................................................................. 3

Pin Conﬁguration............................................................ 4

Connection and Installation ........................................... 6

Technical Support........................................................... 7

Warranty Information...................................................... 7

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com DVI2HDMI DVI and Digital

Audio to HDMI Converter. Offering convenient conversion of digital video

(DVI) and digital audio (digital coaxial) to HDMI, this device eliminates

cable clutter, while providing top quality digital content.

Features

Provides signal ampliﬁcation and equalization for incoming TMDS data•

to ensure optimal signal quality

Supports resolutions up to 1920x1200 or 1080p input and output•

Supports two channel stereo, dolby digital 5.1, and DTS 5.1 sound•

input and output

Package Contents

1 x DVI to HDMI Converter•

1 x Instruction Manual•

1 x Power Adapter•

Instruction Manual

Operating Controls & Functions

DVI Input:1. Connects to the DVI output connector of your source

equipment.

Digital Audio (SPDIF) input:2. Connects to the digital audio output of

your source equipment.

HDMI Output:3. Connects to the HDMI input connector of your HDMI

Display or Switcher.

Power Input:4. Plug the supplied 5V DC Power Supply into the unit, the

LED will illuminate when the power is connected.

Instruction Manual

Specications

Digital Video Input DVI-I Connector (DVI-D input signal only)

Digital Audio Input Coaxial (SPDIF)

HDMI Output 19-pin HDMI Connector

HDCP Version HDCP 1.1, 1.0

Operation Frequency Up to 165 Mhz

Frequency Bandwidth 1.65Gbps (single-link)

Input/Output

Resolutions

VGA@60/72/75/85Hz

SVGA@60/72/75/85Hz

XGA@60/70/75/85/87Hz

SXGA@60/75/85Hz

UXGA@60Hz, 1152@70/75/85Hz

HDTV

480p@60Hz

576@50Hz

720p@50/60Hz

1080i@50/60Hz

1080p@24/25/30/50/60Hz

Dimensions 105(W) x 76(D) x 30(H)mm

22 x 3 x 1.18”

DVI Compliance DVI 1.0

HDCP Compliant HDCP 1.1

HDMI Compliant HDMI 1.2

Input Connectors

1 x DVI-I (only supports DVI-D signal)

1 x Digital Coaxial RCA Female (supports two channel

stereo, dolby digital 5.1, and DTS 5.1)

Output Connector 1 x HDMI

Bandwidth 1.65Gbps (single link)

Frequency 165 MHz

Power 5V 1A Center Positive

Instruction Manual

Pin Conguration

DVI-D Input Pin Assignment

DVI-Digital: Supports digital-only connections between the host computer

and display. This interface is designed for a 12 or 24-pin connection to

enable single or dual-link mode activation

Digital Only Connector Pin Assignments

Pin Signal

Assignment Pin Signal

Assignment

1T.M.D.S Data 2- 9T.M.D.S Data 1- 17 T.M.D.S Data 0-

2T.M.D.S Data 2+ 10 T.M.D.S Data 1+ 18 T.M.D.S Data 0+

3T.M.D.S Data 2

Shield 11 T.M.D.S Data 1

Shield 19 T.M.D.S Data 0

Shield

4N.C. 12 N.C. 20 N.C.

5N.C. 13 N.C. 21 N.C.

6DDC Clock 14 +5V Power 22 T.M.D.S Clock

Shield

7DDC Data 15 Ground (for +5V) 23 T.M.D.S Clock+

8N.C. 16 Hot Plug Detect 24 T.M.D.S Clock-

C1 N.C. C2 N.C. C3 N.C.

C4 N.C. C5 N.C.

Instruction Manual

HDMI Output Pin Assignment

Digital Only Connector Pin Assignments

Pin Function

Assignment Pin Function

Assignment

1T.M.D.S Data 2+ 2T.M.D.S Data 2 Shield

3T.M.D.S Data 2- 4T.M.D.S Data 1+

5T.M.D.S Data 1 Shield 6T.M.D.S Data 1-

7T.M.D.S Data 0+ 8T.M.D.S Data 0 Shield

9T.M.D.S Data 0- 10 T.M.D.S Clock+

11 T.M.D.S Clock Shield 12 T.M.D.S Clock-

13 CEC 14 Reserved (N.C. on device)

15 SCL 16 SDA

17 DDC/CEC Ground 18 +5V Power

19 Hot Plug Detect

Instruction Manual

Connection and Installation

The following images depict typical installation of the DVI2HDMI unit:

Straight Connection to Display

1 - Source Device (e.g. DVD Player, Computer)

2 - DVI Cable (from source to DVI2HDMI DVI IN port)

3 - SPDIF Cable (from source to DVI2HDMI Digital Audio In port)

4 - HDMI Cable (from DVI2HDMI HDMI OUT port) to Display

5 - HDTV/Display

Connection Using an HDMI Switch

1 - Source Device (e.g. DVD Player, Computer)

2 - DVI Cable (from source to DVI2HDMI DVI IN port)

3 - SPDIF Cable (from source to DVI2HDMI Digital Audio In port)

4 - HDMI Cable (from DVI2HDMI HDMI OUT port) to Display

5 - HDTV/Display

6 - HDMI Cable

7 - HDTV/Display

DVI2HDMI

1 2

456

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commit-

ment to provide industry-leading solutions. If you ever need help with your

product, visit www.startech.com/support and access our comprehensive

selection of online tools, documentation, and downloads.

Warranty Information

This product is backed by a one year warranty.

In addition, StarTech.com warrants its products against defects in materi-

als and workmanship for the periods noted, following the initial date of

purchase. During this period, the products may be returned for repair,

or replacement with equivalent products at our discretion. The warranty

covers parts and labor costs only. StarTech.com does not warrant its

products from defects or damages arising from misuse, abuse, alteration,

or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or

exclusions contained in this statement may not apply to you.
