StarTech.com 25SAT22MSAT Manual de usuario

Manual Revision: 10/28/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

25SAT22MSAT

Dual mSATA SSD to 2.5in SATA SSD

Converter with RAID

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View .................................................................................................................................................... 1

Back View ..................................................................................................................................................... 2

Introduction............................................................................................2

Packaging Contents ................................................................................................................................. 2

System Requirements.............................................................................................................................. 2

mSATA SSD Installation.........................................................................3

Congure RAID .......................................................................................5

RAID Lock/Unlock Jumper Pins............................................................................................................ 5

RAID Mode Setting Jumper Pins.......................................................................................................... 5

Set RAID Conguration........................................................................................................................... 6

Hard Drive Initialization........................................................................6

LED Activity and Drive Failure Indicators...........................................8

Technical Support ..................................................................................9

Warranty Information............................................................................9

Instruction Manual

Product Diagram

Front View

1. RAID lock/unlock jumper pins

2. Drive Activity/Fail LEDs

3. Drive #1 mSATA connector

4. Drive #2 mSATA connector

5. Drive #1 mounting bracket

6. Drive #2 mounting bracket

7. Top mounting holes

Instruction Manual

Back View

Introduction

Packaging Contents

• 1 x Dual mSATA to 2.5in SATA Adapter

• 1 x Mounting screw kit

• 1 x Installation Manual

System Requirements

• 2 x mSATA Drives

• SATA Host Device

1. DATA & Power Combo (7+15 pin)

2. RAID setting jumper pins

3. Side mounting holes

Instruction Manual

mSATA SSD Installation

WARNING! SSD Drives and storage adapters require careful handling. If you are

not careful with your SSD Drive, lost data may result. Always handle your drive with

caution. Be sure that you are properly grounded by wearing an anti-static strap when

handling computer components or discharge yourself of any static electricity build-up

by touching a large grounded metal surface (such as the computer case) for several

seconds.

1. Slide the mSATA connector on one of your SSDs into the Drive #1 mSATA receprical

connector on the 25SAT22MSAT.

2. Press the drive down toward the Drive #1 mounting bracket, until the drive clicks

into place.

Instruction Manual

3. Slide the mSATA connector on your other SSD into the Drive #2 mSATA receprical

connector on the 25SAT22MSAT.

4. Press the drive down toward the Drive #2 mounting bracket, until the drive clicks

into place.

5. The SSDs have now been installed.

Note: To remove drives #1 and #2, pull upward on two the tabs located on the top of

either drive, then slide the drives out one at a time.

Instruction Manual

Congure RAID

WARNING! Setting or changing your RAID modes will erase the data or metadata on

your existing SSD drives.

RAID Lock/Unlock Jumper Pins

The RAID lock/unlock jumper pins, located above the drive mounting brackets

enable you to lock your RAID conguration so it cannot be changed. Or unlock your

conguration so it can be changed.

Use the included jumper and the table below, to short the pins and set the mode for

your desired conguration.

Mode Description Jumper Pins

Unlocked Enables you to change your RAID

conguration mode. SET-GND

Locked Does not allow you to change your RAID

conguration mode. N.C-SET

Instruction Manual

Use the included jumpers and the table below, to short the pins and set your desired

RAID mode.

RAID Mode Description Short Pins

RAID 0 Striping - Improves system performance 1-2, 4-5

RAID 1 Mirror – Creates a redundant drive on the

second drive for security 2-3, 4-5

BIG Spanning – Creates a large single drive

volume consisting of both drives. 1-2, 5-6

JBOD

Just a Bunch of Disks – Allows access to both

drives individually

(Note: A port multiplier compatible SATA

controller is required for this mode)

2-3, 5-6

Set RAID Conguration

Note: Your RAID conguration must be set to JBOD before the device can be

recongured to RAID 0, RAID 1, or BIG. If you have set a dierent RAID conguration

and now wish to recongure your RAID, please set the device back to JBOD before

changing the conguration again.

1. Set the RAID Lock/Unlock Jumper Pins to the unlock position.

RAID Mode Setting Jumper Pins

The RAID setting jumper pins, located next to the SATA connector enable you to set

your desired RAID conguration between RAID 0, RAID 1, JBOD, and RAID initial Mode.

456

123

RAID Setting

Jumper Pins

SATA Connector

Instruction Manual

2. Using the RAID Mode setting jumper pins to your desired Mode.

3. Connect the SSD RAID card to your SATA host device.

Note: Refer to the manual for your SATA host device for installation instructions. The

top or side mounting holes and included screw kit may, or may not be required to

assist in your installation.

4. Power on the SATA host device.

5. Your RAID array has now been installed.

6. (Optional) If you would prefer to lock your RAID array so it cannot be altered by the

RAID mode setting jumper pins, power down your SATA host device, and set the

RAID Lock/Unlock Jumper Pins to the lock position.

1. From the main Windows desktop, right-click on “My Computer” (“Computer” in Vista/

7 / 8), then select Manage. In the new Computer Management window, select Disk

Management from the left window panel.

2. A dialog window should automatically appear, asking you to initialize the drive.

Depending on the version of Windows, it will give you the option of either creating

an “MBR” or“GPT” disk. GPT (GUID partition) is not compatible with some older

operating systems, while MBR is supported by newer and older operating systems.

3. Once initialized, locate the Disk that says it is “Unallocated” (check the listed hard

drive capacity to conrm it’s the correct hard drive) and then right-click in the

section that says “Unallocated” and select “New Partition”.

Hard Drive Initialization

If the mSATA SSD RAID Array is new or otherwise blank, it may need to be initialized

and formatted before use. Follow the steps below in a Windows interface to initialize

the drive.
