StarTech.com SAT2510BU32 Manual de usuario

Manual Revision: 10/26/2011

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

SAT2510BU32

USB 3.0 to 2.5” SATA Hard Drive Enclosure

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Hardware Installation .............................................................................................................................. 2

Driver Installation...................................................................................................................................... 2

Using the Storage Device......................................................................3

Specications..........................................................................................5

Technical Support ..................................................................................6

Warranty Information............................................................................6

Instruction Manual

Introduction

The SAT2510BU32 2.5in SuperSpeed USB 3.0 SATA Hard Drive Enclosure turns a normal

2.5in SATA hard drive (HDD) or solid state drive (SSD) into a portable, external hard

drive. Connecting over a USB interface with no external power required, this enclosure

supports the USB 3.0 standard which can provide up to 5 Gbps of bandwidth (which is

10x faster than the USB 2.0 standard). Made from a durable and lightweight aluminum

construction, this enclosure oers optimal heat dissipation along with easy portability.

Packaging Contents

• 1 x USB 3.0 to SATA Enclosure

• 1 x USB 3.0 Cable

• 1 x Protective Case

• 1 x Tool Kit

• 1 x Instruction Manual

System Requirements

• USB enabled computer system with available USB port

• Microsoft® Windows® XP/ Server 2003/ Vista/ Server 2008 R2/ 7 (32/64-bit), or

Apple® Mac OS® X, or Linux®

*If used with the Apple Mac OS operating system, this device will function in USB 2.0

mode only as USB 3.0 is not currently supported by Apple.

Instruction Manual

Installation

WARNING! Hard drives and storage enclosures require careful handling,

especially when being transported. If you are not careful with your hard disk,

lost data may result. Always handle your hard drive and storage device with

caution. Be sure that you are properly grounded by wearing an anti-static

strap when handling computer components or discharge yourself of any

static electricity build-up by touching a large grounded metal surface (such

as the computer case) for several seconds.

Hardware Installation

1. Remove the 4 small screws from the bottom of the enclosure. The two halves of the

enclosure should now pull apart.

2. Place the 2.5” SATA drive into the half that contains the SATA connector and slide the

drive onto the SATA connector.

3. Reassemble the enclosure by placing the two halves together and replacing the 4

small screws from the bottom.

4. Connect the USB cable from the enclosure to the host computer system.

Driver Installation

No driver or software installation is required for any operating system with USB

support. This enclosure, however will only operate at the speed level of the USB port it

is plugged into (i.e. USB 1.x/ 2.0/ 3.0).

Instruction Manual

Using the Storage Device

Windows 2000/XP/Vista/7

If you are using a brand new hard drive that does not contain any data, then you will

rst need to prepare the hard drive for use. From the main desktop, right-click on

“My Computer” (“Computer” in Vista/7), then select “Manage”. In the new “Computer

Management” window, select “Disk Management” from the left window panel.

Locate the Disk that says it is “Unallocated” (check hard drive capacity to conrm it’s the

correct hard drive) and then right-click in the section that says“Unallocated” and select

“New Partition”.

Instruction Manual

The “New Partition Wizard” will appear. Follow the instructions in the wizard to

complete setting up the drive. Once complete, the Disk should show up as “Healthy”

with a drive letter assigned (i.e. E:). This drive letter should now appear within “My

Computer”.

If you are installing a hard drive that already has data on it, then after plugging it in, the

drive should automatically show up with a drive letter assigned within “My Computer”.

Instruction Manual

Specications

Drive Bays 1

Host Interface USB 3.0

Chipset ID ASMedia ASM1051

External Connectors 1 x USB 3.0 type micro B female

LEDs 1 x Power/Activity

Maximum Data Transfer Rate USB 3.0: 5 Gbps

Compatible Hard Drives 2.5in SATA HDD/SSD, 9.5mm height

Power Adapter USB powered

Enclosure Material Aluminum

Operating Temperature 0°C ~ 60°C (32°F ~ 140°F)

Storage Temperature -20°C ~ 70°C (-4°F ~ 158°F)

Humidity 10% ~ 90% RH

Dimensions 123.0mm x 75.0mm x 12.5mm

Weight 77.7g

Compatible Operating Systems

Windows XP/ Server 2003/ Vista/

Server 2008 R2/ 7 (32/64-bit),

Mac OS X**, Linux

** If used with the Apple Mac OS operating system, this device will function in USB 2.0

mode only as Apple does not yet support USB 3.0

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
