StarTech.com S2510PESAT Manual de usuario

SATA Hard Drive Enclosure

2.5” Silver Power eSATA to SATA

Hard Drive Enclosure

with One Touch Backup

S2510PESAT

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction..................................................................... 1

Packaging Contents.....................................................................1

System Requirements .................................................................1

Installation....................................................................... 2

Hardware Installation...................................................................2

Driver Installation.........................................................................2

Using the Enclosure ....................................................... 3

Speciﬁcations.................................................................. 5

Technical Support........................................................... 6

Warranty Information...................................................... 6

Introduction

The S2510PESAT External Hard Drive Enclosure can be connected

through Power eSATA (also known as eSATA + USB 2.0, USB/eSATA

combo), which uses a single, combined eSATA data connection and 5v

power connection (over a built-in USB connection) making it a fast and

easy to use portable storage solution.

Packaging Contents

1 x S2510PESAT enclosure•

1 x USB “Y” split cable•

1 x Soft Carrying Case•

1 x Software Installation CD•

1 x Instruction Manual•

System Requirements

eSATA or Power eSATA or USB enabled computer system•

Microsoft Windows• ®2000/XP/Vista/7, or Apple Mac OS®X, or Linux®

Installation

Hardware Installation

WARNING: Hard drives require careful handling, especially when

being transported. If you are not careful with your hard disk, lost data

may result. Always handle your hard drive and storage device with

caution.

Press on the small tabs on either side of the enclosure to release1.

the latch that holds the top and bottom covers of the enclosure and

slide the enclosure top cover towards the front.

Place the 2.5” SATA hard drive into the enclosure and then slide the2.

hard drive connector into the SATA connector inside the enclosure.

Slide the top cover of the enclosure back onto the frame of the3.

enclosure until it clicks and locks in place.

If using Power eSATA, connect a Power eSATA cable from the4.

enclosure into a Power eSATA port on the computer.

If using regular eSATA, connect an eSATA cable from the enclosure

to an eSATA port on the computer, and then connect the USB cable

from the enclosure to the computer to provide power.

If using USB, then connect the USB cable from the mini-B connector

on the enclosure to the computer, using the provided USB “Y” split

cable. Make sure the ﬁrst USB connector on the cable is plugged

in ﬁrst. If additional power is required, connect the second USB

connector on the cable to the computer system.

Driver Installation

Windows 2000/XP/Vista/7, Mac OS X, Linux

No driver installation is required for these operating systems, as this

enclosure is natively supported, so the drivers are already installed.

Using the Storage Device

Windows 2000/XP/Vista/7

If you are using a brand new hard drive that does not contain any data,

then you will ﬁrst need to prepare the hard drive for use. From the

main desktop, right-click on “My Computer” (“Computer” in Vista/7),

then select Manage. In the new Computer Management window, select

Disk Management from the left window panel.

Locate the Disk that says it is “Unallocated” (check hard drive capacity

to conﬁrm it’s the correct hard drive) and then right-click in the section

that says “Unallocated” and select “New Partition”.

The New Partition Wizard will appear. Follow the instructions in the

wizard to complete setting up the drive. Once complete, the Disk

should show up as “Healthy” with a drive letter assigned (ie. E:). This

drive letter should now appear within My Computer.

If you are installing a hard drive that already has data on it, then after

plugging it in, the drive should automatically show up with a drive letter

assigned within My Computer.

Specications

Bus Interface SATA 3.0Gb/s

USB 2.0

Connectors 1 x Power eSATA connector

1 x USB mini-B

Chipset ID Sunplus SPIF303

LEDs 1 x Power/Activity

Hard Drive Support 2.5” SATA 1.5/3.0Gbps, 9.5mm

height, up to 500GB capacity

Dimensions 130.0mm x 60.0mm x 17.0mm

Weight 93.5g

Compatible Operating

Systems

Windows 2000/XP/Vista/7,

Mac OS X, Linux

Technical Support

StarTech.com’s lifetime technical support is an integral part of our

commitment to provide industry-leading solutions. If you ever need

help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a one year warranty.

In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial

date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion.

The warranty covers parts and labor costs only. StarTech.com does

not warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy” since 1985,

providing high quality solutions to a diverse IT and A/V customer

base that spans many channels, including government, education

and industrial facilities to name just a few. We offer an unmatched

selection of computer parts, cables, A/V products, KVM and Server

Management solutions, serving a worldwide market through our

locations in the United States, Canada, the United Kingdom and

Taiwan.

Visit www.startech.com today for complete information about all

our products and to access exclusive interactive tools such as the

Cable Finder, Parts Finder and the KVM Reference Guide.
