StarTech.com SDOCK2U33V Manual de usuario

Manual Revision: 05/02/2017

For the latest information, technical specications, and support for

this product, please visit www.StarTech.com/SDOCK2U33V.

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

SDOCK2U33V

Dual-Bay Drive Docking Station for

2.5/3.5” SATA SSDs/HDDs - USB 3.0

*actual product may vary from photos

Instruction manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction manual

Table of Contents

Product diagram ....................................................................................1

Package contents ...................................................................................2

Requirements .........................................................................................2

About USB 3.1 Gen 1..............................................................................2

Connect the drive docking station......................................................2

Insert a drive...........................................................................................3

Prepare a drive for use ..........................................................................3

Windows® OS.............................................................................................................................................. 3

macOS........................................................................................................................................................... 4

About the LED indicators......................................................................5

Disconnect a drive .................................................................................5

Windows OS................................................................................................................................................ 5

macOS........................................................................................................................................................... 5

Technical support...................................................................................6

Warranty information............................................................................6

123

Instruction manual

Product diagram

Power LED

Drive A activity LED

Drive B activity LED

Drive B slot

5Drive A slot

678

6USB 3.0 Micro-B port

DC power port

Power button

Instruction manual

Package contents

• 1 x drive docking station

• 1 x USB 3.0 cable

• 1 x universal power adapter (NA/JP, UK, EU, ANZ)

• 1 x quick-start guide

Requirements

• Computer system with USB 3.1 Gen 1 port

• Up to two 2.5” or 3.5” SATA HDDs or SSDs

This drive docking station is OS independent and doesn’t require any additional drivers

or software.

System requirements are subject to change. For the latest requirements, please visit

www.StarTech.com/SDOCK2U33V.

About USB 3.1 Gen 1

USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard supports speeds of

up to 5Gbps.

Connect the drive docking station

1. Connect the universal power adapter to the DC power port on the drive docking

station and a power outlet.

2. Connect the USB 3.0 cable to the USB 3.0 Micro-B port on the drive docking station

and a USB port on your computer.

Instruction manual

Insert a drive

Warning! You should handle your drives carefully, especially when you’re transporting

them. If you’re not careful with your drives, you may lose data as a result. Always

handle storage devices with caution. Make sure that you’re properly grounded

by wearing an anti-static strap. If an anti-static strap isn’t available, touch a large,

grounded metal surface for several seconds to discharge any built-up static electricity.

Caution! When you insert a second drive into the drive docking station, it resets. If

you’re accessing a drive in the docking station, wait for the drive activity LED to stop

blinking before you insert the second drive.

1. Align the SATA power and data connectors on a 2.5” or 3.5” SATA drive with the

connectors in drive slot A or drive slot B, and insert the drive into the slot.

2. If necessary, repeat step 1 to install a second drive.

3. Press the power button on the drive docking station.

When the drive docking station is turned on, the computer should automatically

recognize the drive and it should be accessible as though the drive were installed in

the system internally. If your computer fails to automatically recognize the drive, you

may need to initialize the drive. For more information, see the“Prepare a drive for use”

section.

Prepare a drive for use

Windows® OS

If you install a drive that already has data on it, after you connect the drive docking

station to your computer, the drive appears under My Computer or Computer with a

drive letter assigned to it. If you install a brand-new drive that doesn’t contain any data,

you must prepare the drive for use.

Warning! When you complete the following steps, all of the data on your drive will be

deleted. If your drive has data on it that you require, you should create a backup le or

use a dierent drive.

Instruction manual

1. Depending on the version of Windows OS that you’re running, do one of the

following:

• On your desktop, right-click My Computer and click Manage.

• On your desktop, right-click Computer and click Manage.

• Click the Start button or Windows icon. Enter compmgmt.msc and press

Enter.

2. On the Computer Management screen, click Disk Management.

3. A dialog window appears and asks you to initialize the drive. Depending on the

version of Windows OS that you’re running, you have the option to create either an

MBR or a GPT disk.

Note: GPT (GUID partition) is required for drives that are larger than 2 TB, but GPT isn’t

compatible with some earlier versions of operating systems. MBR is supported by both

earlier and later versions of operating systems.

4. Locate the disk that is labeled Unallocated. To conrm that the drive is the correct

one, check the drive capacity.

5. Right-click the section of the window that says Unallocated and click New

Partition.

6. To initialize the drive in the format of your choice, complete the on-screen

instructions.

When the drive is successfully installed, it appears under My Computer or Computer

with a drive letter assigned to it.

macOS

If you install a brand-new drive that doesn’t contain any data, you must prepare the

drive for use.

Warning! When you complete the following steps, you create a partition that uses the

entire drive space.

1. Do one of the following:

• In Spotlight, enter Disk Utility.

• Open Finder. Navigate to Applications and click Utilities. Open Disk Utility.

2. Select the drive and click the Partition tab.

3. Enter a name for the partition.

4. Click Apply.

The drive should now appear on your desktop and be accessible in Finder.

Instruction manual

About the LED indicators

LED Behavior Signicance

Power Illuminated green Docking station is receiving power

Drive A activity Blinking yellow The drive is being accessed

Drive B activity Blinking yellow The drive is being accessed

Disconnect a drive

Caution! When you remove a drive from the drive docking station, it resets. If you’re

accessing a drive in the docking station, wait for the drive activity LED to stop blinking

before you remove the second drive.

Windows OS

1. Click the Safely remove Hardware and Eject Media icon in the task bar.

2. Select the drive in the list of storage devices.

3. When a message appears saying it is safe to remove the drive, pull the drive from

the drive slot.

Warning! If you remove the drive before the message saying it is safe to do so appears,

you could experience lost or corrupted data.

macOS

1. Close any open windows that list the contents of the drive.

2. On the desktop, drag the USB storage icon onto the trash can icon.

3. Wait 15 seconds and pull the drive from the drive slot.

Instruction manual

Technical support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty information

This product is backed by a two-year warranty.

StarTech.com warrants its products against defects in materials and workmanship

for the periods noted, following the initial date of purchase. During this period,

the products may be returned for repair, or replacement with equivalent

products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Estación de acoplamiento de StarTech.com

StarTech.com

StarTech.com SATDOCK22RE Manual de usuario

StarTech.com

StarTech.com 116N-USBC-DOCK Manual de usuario

StarTech.com

StarTech.com SATADOCK525 Manual del sistema

StarTech.com

StarTech.com DK30CHDDPPD Manual de usuario

StarTech.com

StarTech.com DKT31CHDVCM Manual de usuario

StarTech.com

StarTech.com SATDOCKU3S Manual de usuario

StarTech.com

StarTech.com DKT31CHDVCM Manual de usuario

StarTech.com

StarTech.com USB3DOCKHDPC Manual de usuario

StarTech.com

StarTech.com DKM31C3HVCPD Manual de usuario

StarTech.com

StarTech.com DK31C4DPPD Manual de usuario

StarTech.com

StarTech.com Thunderbolt 3 Series Manual de usuario

StarTech.com

StarTech.com USB3VDOCKD Manual de usuario

StarTech.com

StarTech.com USB3SDOCKHDV Manual de usuario

StarTech.com

StarTech.com DK30C2DPEP Manual de usuario

StarTech.com

StarTech.com SATDOCK25U Manual de usuario

StarTech.com

StarTech.com Thunderbolt TB3CDOCKDP Manual de usuario

StarTech.com

StarTech.com USB3VDOCKH Manual de usuario

StarTech.com

StarTech.com SATDOCK4U2E Manual de usuario

StarTech.com

StarTech.com SDOCK4U33E Manual de usuario

StarTech.com

StarTech.com USB3SMDOCKV Manual de usuario

StarTech.com

StarTech.com USB6N1DOCK Manual de usuario

StarTech.com

StarTech.com SDOCK2U33HFB Manual de usuario

StarTech.com

StarTech.com SATDOCK22RU3 Manual de usuario

StarTech.com

StarTech.com SDOCK2U33EB Manual de usuario

Manuales populares de Estación de acoplamiento de otras marcas

Sony

Sony Dream Machine XDR-DS12iP Manual de usuario

Acer

Acer USB Type-C Dock II Manual de usuario

ATEN

ATEN UC-2000 Manual de usuario

Xcellon

Xcellon HDD-202 Manual de usuario

Dok

Dok CR09 Manual de usuario

Philips

Philips BTM630/12 Manual de usuario

IOGear

IOGear Travel Pro GUD3C09 Manual de usuario

RKI

RKI SDM-E2 Manual de usuario

iHome

iHome iP15 Manual de usuario

VITURE ONE

VITURE ONE MOBILE DOCK Manual de usuario

Lindy

Lindy 42984 Manual de usuario

CipherLab

CipherLab 8001 Manual de usuario

Pyle

Pyle PIPDSP2 Manual de usuario

Avol

Avol AS2350 Manual de usuario

Datalogic

Datalogic JoyaTouch Manual de usuario

Philips

Philips DC190/79 Manual de usuario

Targus

Targus DOCK315EUZ Manual de usuario

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manual de usuario
