StarTech.com SDOCK2U313R Manual de usuario
USB 3.1 (10Gbps) Standalone Duplicator Dock for 2.5" & 3.5" SATA SSD/HDD Drives - with
Fast-Speed Duplication up to 28GB/min
Product ID: SDOCK2U313R
Duplicate drives quickly, at rates of up to 28GB per minute for SSDs, without having to connect to your computer.
This duplicator dock offers standalone drive cloning that makes it easy to back up your data and make exact images
of your drives. You can also connect the dock to your computer through USB 3.1 (10Gbps), to dock and swap your
drives as part of a scalable storage solution.
Duplicating a hard drive or solid-state drive is an effective way to migrate your operating system and data from one
drive to another, or create an exact copy for safeguarding your important data. This drive duplicator lets you create a
sector-by-sector clone of your drive, including partitions and boot sector information, to ensure data integrity and
consistency for sensitive operations such as data recovery.
The duplicator dock saves you valuable time with SSD duplication speeds of up to 28GB per minute. You can
duplicate a 2.5” or 3.5” SATA SSD or HDD easily, without having to connect the duplicator to a host computer.
The duplicator dock also provides an external storage solution, letting you dock your drives through USB 3.1 Gen 2
with UASP support, enabling fast data transfer rates of up to 10Gbps. Each drive slot individually supports a
high-capacity hard drive or solid-state drive, tested up to 6 TB.
The duplicator dock comes with two USB cables for flexible use with the latest laptops and tablets equipped with a
USB-C port, as well as legacy devices. It includes both USB-C to B and USB-A to B cables. The duplicator dock is
also compatible with a Thunderbolt 3 USB-C port.
The dock features a top-loading, toaster-style design that makes it easy to insert your drives. It also features drive
doors to help stabilize drives that are inserted into the slot and prevent foreign objects from getting into the drive
slots.
Both tool-less and tray-less, the duplicator dock helps to ensure quick and hassle-free drive insertions. LED indicators
let you know, at a glance, the current state of the duplication process, including the specific duplication mode, the
HDD status and clone progress. The HDD ejection button enables fast and simple drive removal.
For added compatibility with different drive types in duplication and docking applications, the SDOCK2U33RE
supports the use of various drive adapters. The below list of StarTech.com adapters have been specifically tested, to
ensure compatibility with this drive duplicator:
SATA to 2.5in or 3.5in IDE Drive Adapter - SAT2IDEADP
2.5in SATA to Mini SATA SSD Adapter - SAT2MSAT25
M.2 SSD to 2.5in SATA Adapter - SAT32M225
The SDOCK2U313R is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Certifications, Reports and Compatibility
Applications
• Duplicate a 2.5 in. or 3.5 in. SSD/HDD to create an exact replica of a source drive onto a different drive
• Create identical backups for system builds that require the same drive image
• Quickly access or swap bare hard drives and solid-state drives for easy data backup/recovery
Features
• Duplicate hard drives quickly, without a host computer, at fast speeds of up to 28GB per minute for SSDs
• Works with both USB-C and USB-A enabled devices, with two cables included
• Compatible with Thunderbolt 3 USB-C port
• Transfer files at high speed between a docked hard drive and a host computer
• Supports 3.5in and 2.5in SATA SSDs/HDDs
• USB 3.1 (10Gbps) with UASP support for high speed data transfers and backup
• Provides TRIM support
• Supports SATA I/II/III (up to 6Gbps)
• Dual-bay, top slot-loading design (toaster-style) with drive doors and HDD ejection button
• Tool-less and tray-less design
• Compatible with SAT2IDEADP for additional IDE drive support
• Multi-function LED indicators
• Backward compatible
Hardware
Warranty
2 Years
Fan(s)
No
Interface
USB 3.1 Gen 2
Bus Type
USB 3.1 Gen 2
Number of Drives
2
Drive Size
2.5in & 3.5in
Compatible Drive Types
SATA
Drive Installation
Removable
Chipset ID
ASMedia - ASM1352R
Performance
Maximum Data Transfer
Rate
10Gbps
Type and Rate
USB 3.1 Gen 2 - 10 Gbit/s
UASP Support
Yes
TRIM Support
Yes
4Kn Support
Yes
Type and Rate
SATA III (6 Gbps)
Port Multiplier
No
Hardware Raid Supported
No
Duplication Modes
Sector by Sector (Whole Drive)
Duplication Speed
28GBpm
Max Drive Capacity
Tested with up to 6TB drives
Hot Swap Capability
Yes
Connector(s)
Drive Connectors
SATA Data & Power Combo (7+15 pin)
Host Connectors
USB 3.1 USB Type-B (9 pin, Gen 2, 10 Gbps)
Software
OS Compatibility
OS independent; No software or drivers required
Special Notes /
Requirements
Note
Windows 7 and earlier Windows versions do not support TRIM
with USB to SATA devices.
Indicators
LED Indicators
Power
Mode
HDD Status
Clone
Power
Power Source
AC Adapter Included
Input Voltage
100 - 240 AC
Input Current
1.5A
Output Voltage
12V DC
Output Current
3000 mA
Center Tip Polarity
Positive
Plug Type
M
Power Consumption (In
Watts)
36
Environmental
Operating Temperature
5C - 35C (41C to 95C)
Storage Temperature
-20C - 50C (-4C to 122C)
Humidity
20%RH ~ 80%RH
Physical
Characteristics
Color
Black
Material
Plastic
Max Drive Height
1.0 in [25.4 mm]
Product Length
5.6 in [14.2 cm]
Product Width
5.2 in [13.2 cm]
Product Height
2.8 in [70 mm]
Weight of Product
17.9 oz [508 g]
Packaging
Information
Package Length
6.5 in [16.6 cm]
Package Width
11.8 in [30 cm]
Package Height
3.5 in [88 mm]
Shipping (Package)
Weight
35.0 oz [992 g]
What's in the Box
Included in Package
USB 3.1 duplicator docking station
USB-C to B cable - 40 inches
USB 3.0 A to B cable - 40.75 inches
universal power adapter (NA/EU/UK/AU) - 40.75 inches (cable)
quick start guide
*Product appearance and specifications are subject to change without notice.
