StarTech.com EC1U2F Manual de usuario

Manual Revision: 12/15/2011

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

EC1U2F

1 Port USB 2.0 & 2 Port FireWire

ExpressCard/34 Adapter Card

*actual product may vary from photos

Instruction Manual

Table of Contents

Introduction ...........................................................................................1

Features ........................................................................................................................................................ 1

Package Contents ..................................................................................................................................... 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Connecting FireWire and USB devices to the ExpressCard........................................................ 2

Basic troubleshooting ...........................................................................2

Specications..........................................................................................3

Technical Support ..................................................................................4

Warranty Information............................................................................4

Instruction Manual

Introduction

Thank for purchasing a StarTech.com 2 Port Firewire and 1 Port USB 2.0 ExpressCard

adapter. Providing a versatile connectivity solution, this device oers data transfer

rates of up to 480Mbps (when used with high-speed USB peripherals), and 400Mbps

(FireWire), providing the ideal platform for connecting any FireWire or USB peripheral.

Features

• USB 2.0 and IEEE-1394a compliant

• Supports USB transfer rates up to 480 Mbps and USB 1.1 transfer rates up to 12

Mbps

• Supports FireWire 100/200/400 Mbps transfer rates

• Compliant with ExpressCard/34 Type II standard

Package Contents

• 1 x ExpressCard Adapter

• 1 x Instruction Manual

System Requirements

• One available ExpressCard Slot

• Windows 2000/ XP/ Vista/ 7

Instruction Manual

Installation

1. Insert the ExpressCard into an available ExpressCard/54 or 34mm slot. Since this

card is hot-pluggable, this can be performed while the computer is on or o. Once

the card has been inserted, ensure the computer is powered, to proceed with

installation.

2. Windows will detect that the card has been inserted, and will prompt for driver

installation. To install the necessary software, follow the on-screen instructions.

Once the driver has been installed, the operating system will notify you that your

new hardware is ready for use.

Connecting FireWire and USB devices to the ExpressCard

To begin using your FireWire and USB peripherals with EC1U2F, simply insert the

FireWire or USB connector provided by the peripheral or attached cable as appropriate

into one of the ports provided by the ExpressCard.

Once USB and/or FireWire devices are connected to the ExpressCard, Windows will

request the required drivers for each device respectively. For further information

regarding the attached peripheral drivers, please consult the documentation that

accompanied the purchase of the peripheral device(s).

Please note: For peripherals requiring lower voltages, EC1U2F oers built-in power

capability. If more power is required, an external 5VDC power adapter (not included

with EC1U2F) can be connected to the power port on the ExpressCard.

Basic troubleshooting

If you nd that the peripherals connected to EC1U2F (in the powered state) are not

functioning, or are not being detected, please ensure the following:

1. The drivers have been installed.

2. Any previous driver installations (if this product has been previously installed) have

been removed.

3. There are no conicts with other device drivers. To determine this:

a. Browse to the Device Manager, by right-clicking on My Computer, and selecting

Manage. In the left pane, click on Device Manager.

b. Look for any exclamation marks (!) or question marks (?) listed next to the

FireWire controller card, in the right pane.

Instruction Manual

Specications

Bus Type ExpressCard 1.0a

Form Factor ExpressCard/34 (34mm)

Chipset ID TI XIO2200

Connectors 1 x USB 2.0 Type A

2 x FireWire 6-pin

Power Adapter Optional: 5V DC, 1A (not included)

Maximum Data Transfer Rate USB 2.0: 480Mbps

FireWire400: 400Mbps

OS Support Windows 2000/ XP/ Vista/ 7

Regulatory Certications CE, ROHS, FCC

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.
