Starkey QuickTIPS Manual de usuario

GOVERNMENT SERVICES

QuickTIPS

SURFLINK ACCESSORY SYNCING TO MUSE iQ LITHIUM-ION RECHARGEABLE HEARING AIDS

PRODUCT AVAILABILITY: Muse iQ Lithium-Ion Rechargeable Devices

The SurfLink Mobile 2 is designed to

interface with your wireless hearing

aids in multiple ways:

1. As a remote control to make

hearing aids setting adjustments

2. As a cell phone streaming device

3. As an audio streaming device from

Bluetooth devices, line-in input via

the micro-USB jack, and built-in

omni and directional microphones

SURFLINK MOBILE 2

Launch Inspire, then connect and detect hearing devices. Refer to the

Initial Fitting Protocol QuickTIP for additional information.

SETUP IN INSPIRE

The back of the Synergy Charger is equipped with four LED indicators to

provide information about the charging of the battery onboard the Synergy

Charger. The onboard battery allows charging of the hearing aids to occur,

while the Synergy Charger is away from a power source.

1. In Inspire, select the Accessories tab from the left navigation bar.

2. Select the check box next to Mobile.

3. Select the desired Favorite Button Configuration from the

dropdown menu. Options include:

a. None

b. Start/Stop Audio Stream (default)

c. Noise Control Boost

d. Tinnitus On/Off

4. Select Hearing Aid Microphone Setting While Streaming.

5. After programming is complete, close out of the Inspire software.

SYNCING MUSE iQ LITHIUM-ION RECHARGEABLE HEARING

AIDS TO SURFLINK MOBILE 2

1. After closing out of the Inspire software, power on the SurfLink

Mobile 2 by holding the button at the top right of the device.

2. Select the Settings icon on the bottom right of the SurfLink Mobile

2, then Advanced Setup, then Hearing Devices.

3. Select Sync New. A message will appear “If Inspire fitting session

is open, please close it now.”

4. Insert the hearing aids into the Synergy Charger to power the

hearing aids down. Once the syncing process begins, remove

the hearing aids from the charger to power them on. The serial

numbers will highlight in blue on the SurfLink Mobile 2 screen.

5. Select Sync, then OK to complete the syncing process. Synced

hearing aids are now synced for Streaming and Remote Control

functionality.

NOTE: Up to two hearing aids (one right and one left) may be

synced to the SurfLink Mobile 2 at one time.

For additional information about the SurfLink Mobile 2, refer to the

SurfLink Mobile 2 QuickTIP.

SurfLink Mobile 2

Setup in Inspire

The SurfLink Remote Microphone

2 is a compact device designed to

wirelessly stream speech and other

audio from a distance directly to the

hearing aids.

SURFLINK MOBILE 2

Launch Inspire, then connect and detect hearing devices. Refer to the

Initial Fitting Protocol QuickTIP for additional information.

SETUP IN INSPIRE

Setup in Inspire is not necessary for syncing; however, it does allow for

configuration of the StreamBoost memory and microphone offsets while

streaming.

1. Launch Inspire, then connect and detect hearing devices. Refer to

the Initial Fitting Protocol QuickTIP for additional information.

2. In Inspire, select the Accessories tab from the left navigation bar.

3. Select the check box next to Remote Microphone.

4. Mute or attenuate the hearing aid microphones during Remote

Microphone streaming, if desired.

NOTE: By default, hearing aid microphones turn off during

streaming for an open fit. Hearing aid microphones are

attenuated by -6 dB during streaming for an occluded fit.

5. After programming is complete, close out of the Inspire software.

SYNCING MUSE iQ LITHIUM-ION RECHARGEABLE HEARING

AIDS TO THE SURFLINK REMOTE MICROPHONE 2

Once synced, hearing aids will automatically connect to the remote

microphone when powered on and within wireless operating range

(approximately 20 feet). A maximum of two hearing aids can be synced to

one Remote Microphone. Two or more Remote Microphones can be synced

to the same set of hearing aids (i.e. to use one Remote Microphone while

the other is charging), but only one Remote Microphone can be actively

streaming to a set of hearing aids at a time.

1. Ensure Remote Microphone battery is charged. To charge,

connect the microUSB end of the recharging cable to the Remote

Microphone and the USB end to a female USB jack (i.e. a computer

USB port).

2. Power on Remote Microphone by sliding the power on/off slider up.

NOTE: a visible white dot indicates the power is off.

3. Place the Muse iQ Lithium-Ion Rechargeable hearing aids into the

Synergy Charger to power them off.

4. Press and hold the sync icon on the slider button for five seconds

until the blue LED begins to blink rapidly.

5. Remove one hearing aid from the Synergy Charger to power it on.

A green LED will blink on the Remote Microphone to confirm a

successful sync.

6. Remove the other hearing aid from the Synergy Charger to power

it on. Another green LED will blink on the Remote Microphone to

confirm a successful sync.

NOTE: If only syncing one hearing aid, wait 20 seconds after sync

until a red LED blinks.

Setup in Inspire

SurfLink Remote Microphone 2

7. Hearing aids will automatically begin streaming audio from

Remote Microphone after successful syncing.

For additional information about the SurfLink Remote Microphone 2, refer

to the SurfLink Mobile 2 QuickTIP.

NOTE: All other SurfLink accessories are compatible with the

Muse iQ Lithium-Ion Rechargeable hearing aids, but do

not require additional syncing instructions. For additional

information about the SurfLink accessories, refer to the

SurfLink Accessories QuickTIPs.
