Starkey Livio RIC R Manual de usuario

PRODUCT GUIDE

Receiver-In-Canal

Rechargeable (RIC R) With Earbud

Your new hearing aids offer Starkey’s most advanced

technology with supreme sound quality and features.

They are customizable to fit your unique hearing

needs, helping you to stay connected to the people

and things you love most.

Hearing Aid Parts

1. Hearing Aid

2. Cable

3. Receiver

4. Microphone

5. Rocker Switch User Control

6. Comfort Bud Earbud

7. Charging Contacts

8. Retention Lock

Insertion and Removal

To insert the hearing aid:

1. Gently wrap the hearing aid over your ear

until it rests securely behind your ear.

2. Insert the earbud into your ear canal.

3. Place the lock into the bowl of your ear.

4. The earbud should not be visible and the

cable should be snug against the head.

To remove the hearing aid:

1. Gently grasp the cable at the opening of

the ear canal with your thumb and forefinger.

2. Gently pull the earbud out of your ear canal.

3. Remove the hearing aid from behind your ear.

How-to Video

Receiver-In-Canal Rechargeable (RIC R) PRODUCT GUIDE

Charging Your Hearing Aids

Your hearing aid uses a rechargeable battery

as its power source. To charge the battery:

1. Plug your charger into an outlet.

2. Place your hearing aids in the charging ports

with the earbuds resting inside the case.

3. Your hearing aids will turn off automatically and begin to charge.

• The front of the charger is equipped with two LED indicators

to provide information about hearing aid charging. The front

LED indicators will glow green to indicate successful charging.

• When the hearing aids are fully charged (approx 3.5 hrs

charge time), the front LED indicators will be solid green.

• Your hearing aids will automatically power on when removed from the charger.

Battery Indicator

You will hear an indicator

through your hearing aid

when battery voltage

is low and the battery

needs charging.

How-to Video

Hearing Aid Charger Parts

1. Desiccant Puck Holder

2. Cleaning Brush

3. Charging Ports

4. Hearing Aid Charging LEDs

5. On-board Battery LEDs

6. Power Cord Port

Desiccant Puck

The desiccant puck will be effective for 3–6 months depending on moisture in the hearing

aids and humidity. The color will fade from blue to white, indicating a need for replacement.

On-board Battery

• The back of the charger is equipped with four LED indicators to provide information about

the status of the on-board battery. The on-board battery allows charging of the hearing

aids up to three times while the charger is away from a power source.

• When away from a power source, the back LED indicators will be solid green indicating

the amount of charge available for the on-board battery. The LED indicators will turn off

after 10 seconds to preserve power.

Receiver-In-Canal Rechargeable (RIC R) PRODUCT GUIDE

On-board Battery (Continued)

• One blinking LED on the back of the charger indicates that the on-board battery

is low and the charger should be connected to a power source.

• When plugged into a power source, the back LED indicators will glow green to indicate

successful on-board battery charging.

Hearing Aid Care

Cleaning Your Hearing Aids

• Use the cleaning brush or soft cloth to clean debris from around the user control,

microphone, charging contacts, receiver and earbud.

• Replace the earbud if it becomes misshapen or no longer fits comfortably in your ear.

• Never use water, solvents, cleaning fluids or oil to clean your hearing aid.

Cleaning Your Charger

• Use the provided cleaning brush to keep the charging ports clear of debris.

• Do not use water, solvents or cleaning fluids to clean the charging ports.

• Keep lid closed as much as possible to avoid dust and debris build up.

• Store your charger in a clean and dry location, such as a dresser or shelf

rather than the bathroom or kitchen.

To ensure the longest life of your rechargeable hearing aid batteries

and the batteries in the charger:

• Fully charge hearing aid batteries every night.

• Do not expose to excess heat such as a window sill or in a hot car.

Changing Hear Clear Wax Guards

1. Hold onto the cable where it enters the receiver. With the other hand, pull firmly

on the earbud until it separates from the receiver.

2. Insert the empty end of the application stick straight into the used wax guard in the receiver.

3. Pull the stick straight out to remove the used wax guard (do not twist).

Receiver-In-Canal Rechargeable (RIC R) PRODUCT GUIDE

Changing Hear Clear Wax Guards (Continued)

4. Use the opposite end of the stick to firmly insert the clean wax guard straight into the receiver.

5. Pull the stick straight out (do not twist) and discard the stick.

6. To attach the earbud, place the end of the receiver into the cylinder-shaped opening in the middle

of the earbud. Push firmly to ensure the earbud is secure. The earbud should be pushed on far

enough so that the threaded portion of the receiver is inside of the earbud.

How-to Video

For more help, visit Starkey.com/Support

The Starkey logo and Starkey are registered trademarks of Starkey Laboratories, Inc.
