ST STEVAL-BFA001V1B Manual de usuario

Getting started Guide

STEVAL-BFA001V1B

Predictive maintenance kit with sensors and IO-Link capability

System Research and Applications

July 2018

Contents 2

Setup and programming

STEVAL-BFA001V1B Kit Overview

Data Monitoring/Logging

How to enable Predictive Maintenance

STEVAL-BFA001V1B Kit Overview

STEVAL-BFA001V1B Kit

What is inside

The STEVAL-BFA001V1B includes:

1. STEVAL-IDP005V1- industrial sensor board

2. STEVAL-UKI001V1 - Adapter board for ST-LINK/V2-1

3. 0.050” 10-pin flat cable

4. 4-pole cable mount connector plug, with male contacts

5. M12 female connector with 2m cable

Designed for:

•Condition Monitoring (CM)

•Predictive Maintenance (PdM)

The STEVAL-BFA001V1B is based on 3D digital accelerometer, environmental and acoustic MEMS sensors

What is inside?

STEVAL-IDP005V1

Hardware Overview 5

Main supply voltage: 18..32V

Main components:

•32-bitARM® Cortex®-M4 core for signal processing and analysis

(STM32F469AI)

•Sensors:

•iNEMO 6DoF (ISM330DLC- accelerometer and gyroscope)

•Absolute Digital Pressure (LPS22HB)

•Relative Humidity and temperature sensors (HTS221)

•Digital Microphone sensor (MP34DT05-A)

•IO-Link PHY Device (L6362A)

•EEPROM (M95M01-DF) for data Storage

•Step-down switching regulator and LDO regulator (L6984 and LDK220)

•M12 industrial connector

•SWD connector for debugging and programming capability

•Reset button

•Expansion connector with GPIO, ADC, I2C bus

The STEVAL-BFA001V1B kit is designed around the STEVAL-IDP005V1

STEVAL-IDP005V1

Software Overview 6

Hardware

STEVAL –IDP005V1

ISM330DLC, HTS221, LPS22HB, MP34DT05-A, M95M01-DF

Vibration

Signal Processing Audio LibMiddleware

STM32Cube Hardware

Abstraction Layer (HAL)

Hardware

Abstraction

Board Support

Package

Condition

Monitoring

Demonstrations

Predictive

Maintenance

Acoustic

Analysis

Applications

Environmental

monitoring

Vibration

Analysis

Software Description

Set of firmware examples for CM and PdM based on 3D digital

accelerometer (only accelerometer is supported in fw package),

environmental and acoustic MEMS sensors.

Key features

•Developed for STM32F469AI with easy portability across different

MCU families

•Middleware including algorithms for advanced time and frequency

domain signal processing for vibration analysis:

•Programmable FFT size (256, 512, 1024, 2048 points)

•Programmable FFT overlapping

•Programmable acquisition time window

•FFT averaging during acquisition time

•Programmable windowing (Flat Top, Hanning, Hamming)

•Speed RMS moving average, acceleration max peak.

•Middleware integrating microphone algorithms for:

•PDM to PCM

•Sound pressure

•Audio FFT

•Environmental, acoustic and vibration data monitoring through freely available

terminal emulator.

•Example firmware to communicate with STEVAL-IDP004V1 (IO-Link master

capable, multi-port evaluation board) and dedicated PC GUI.

STSW-BFA001V1 architecture

STSW-BFA001V1 is the software package for the STEVAL-IDP005V1

Setup and Programming

What do you need more? –not included in the kit –

STEVAL-IDP005V1 STEVAL-UKI001V1 M12 female connector

with 2m cable

10-pin flat cable

4-pole male connector

12345

Generic power supply

(range 18..32V)

Any STM32 nucleo-64 to program

debug and interface with PC USB cable Type-A to Mini B STEVAL-IDP004V1 Master board and

generic RS-485/422 USB adapter

(required only to use the GUI)

Laptop

Unpack the STEVAL-BFA001V1B ...

Setup

Hardware prerequisities

STEVAL-IDP005V1 Demo Setup

Software prerequisities 9

•STSW-LINK009

ST-LINK/V2-1 USB driver

•STSW-LINK007

ST-LINK/V2-1 firmware upgrade

•Common freely Serial line terminal (i.e. TeraTerm)

•ST IDP005V1-GUI (setup included in .\STSW-BFA001V1\Utilities folder)

•Microsoft.net version 4.5 or higher (this is only to run the GUI)

•RS-485/USB adapter driver (this only to use STEVAL-IDP005V1 connected to IO-Link

master capable multi port board)

STEVAL-IDP005V1

Power-on 10

Plug the M12 cable onto the STEVAL-IDP005V1

and connect the other end to a power supply

18..32V

If available, use the STEVAL-IDP004V1 to supply

the STEVAL-IDP005V1 through the M12 cable

The STEVAL-IDP005V1 can be powered in two ways

STEVAL-IDP005V1

STEVAL-IDP004V1

Supply voltage

18..32 V

Supply

voltage

9..32 V

STEVAL-IDP005V1
