SPIKECAM Z11 Manual de usuario

USER MANUAL

Model: Z11

https://www.spikecam.com

SPIKECAM Body Camera

SPIKECAM

We sincerely appreciate your decision to select our product. The Z11 is an

innovative portable camera created by SPIKECAM, offering exceptional audio

and video quality, motion detection, and photography capabilities.

Furthermore, it provides up to 8 hours of uninterrupted, high-definition video

recording time. You can effortlessly review your recorded videos using the 1.5-

inch LCD screen on the rear of the camera. To ensure you make the most of this

product, we kindly urge you to thoroughly read the user manual and retain it for

future reference.

Warm regards,

Once again, thank you for choosing SPIKECAM.

Dear Valued Customer,

For your convenience, we have prepared brief video tutorials lasting only a few

minutes. You can access these tutorials by visiting

https://www.spikecam.com/z11 or by scanning the QR code provided below.

Should you have any inquiries or require assistance, please do not hesitate to

reach out to our dedicated customer service team at , and info@spikecam.com

we assure you a response within 24 hours.

The SPIKECAM Team

Scan to watch training video

https://www.spikecam.com/z11

Diagram

01 Video Slider

02 Power Button/Confirm Button

03 Up Button

04 Down Button

05 Flip Button

06 Photo Button/Night Mode

07 Camera Lens

08 Magnetic Block

09 Back Clip

10 Microphone

11 Audio Slider

12 Menu Button/Return Button

13 Playback Button

14 Reset Hole

15 TF Card Slot

16 Charging LED

17 Status LED

18 LCD Screen

19 Type C Port

08 09

SPIKECAM

RECORDING

Video Resolution 1080P/ 720P

Video Format .AVI

Recording Angle 140 degrees

Audio High Quality Built-in Microphone.

Recording Indicator LED Indicator

Water Mark Time and Date Stamp Embedded into Video.

Frame Rate 30fps

Video Length 3/5/10/15 Mins

Activation prompt LED Indicators/Beep Prompts

PHOTOGRAPH

Photo Size 3/2/1Megapixels

Camera Format JPEG

Type Built-in 1000mAH Lithium (LiCoO2)

Charging Time 180 minutes

Battery Life About 8 hours at 1080P(Night Vision Off)

OTHERS

Storage Capacity 32/64/128GB(Depending on your version)

IR LED Lights 4PCS 850nm Infrared LED

Night Vision Manual

Waterproof Ip65

Dimensions 95 mm *40 mm *15mm

59 gram

Working Temperature

Support

Storage temperature -20C° ~ 65C°

ACCESSORIES

Standard Accessories

Weight

USB Cable, Bicycle Mount, TF Card Reader, Manual,

OTG Adapter

Specification

-20C° ~ 65C°

Loop Recording Support

Screen Protection

SPIKECAM

2. How to use?

2.1 Power On

2.2 Power Oﬀ

To power on the camera and prepare it for use, please follow these steps:

1)Long Press the Power Button (No.2). As a result, the Satus LED (No.17) will

ﬂash blue once, accompanied by a power-on sound. The LCD screen will

display a welcome message.

2)The camera system will enter the recording standby mode.

3)The LCD screen will display the preview image, indicating that your body

camera is ready to be used.

Note: If you have set the screen protection to activate after a certain period of

inactivity, such as 3 minutes, 5 minutes, or 10 minutes, the camera's LCD

screen will automatically turn oﬀ if there is no interaction with the body camera.

1. Long press the Power Button for at least 3 seconds.

2. The current recording ﬁle will be saved to the internal storage and the device

will power oﬀ.

2.3 Video Recording

Once fully charged, the device can continuously record video for 7-8 hours at

1080P resolution with night vision turned oﬀ.

To stop recording video, push the slider down to the Oﬀ state. The recording will

stop, and the Status LED will return to a solid blue, indicating that the camera

has returned to Standby Mode.

To begin recording video, (No. 01) . As a push the video slider up to the On state

result, the Status LED will begin ﬂashing blue slowly, and the recording seconds

will be displayed on the screen. This indicates that the camera is now recording

video.

2.4 Audio Recording

To exit audio recording mode, push the Video Slider up and then down again.

To start recording audio, push the Audio Slider (No. 11) up to the On state. The

camera will emit a beep prompt, and the LCD screen will show a microphone

icon and recording seconds to indicate that the audio recording is ongoing. To

stop recording audio, push the Audio Slider down to the Oﬀ state. The recording

seconds will stop counting down and return to 00:00:00.

SPIKECAM

2.5 Take Photo

While in Standby Mode, press the Photo Button (No.06) once to activate the

Photo Capture mode. Press the button again to capture a photo. The camera will

emit a photo-taking sound, and the Status LED will ﬂash blue once.

2.6 Night Vision

While in Standby Mode, perform a long press on the Photo Button for 3 seconds

to activate the night vision mode. The camera will switch to night vision mode,

and the screen will display images in black and white. To exit the night vision

mode, perform another long press on the button.

2.7 Lens Rotation

If you need to record a video in a diﬀerent direction, you can achieve this by

rotating the camera lens (No.07). After ﬂipping the lens, you will need to press

the Flip Button (No.05) to correct the recording image direction.

2.8 File Playback

In Standby Mode, press the (No.13) once to activate the Playback Button

Playback Review Mode. Use the Up and Down buttons to browse through the

ﬁles, and use the Power Button to playback or pause video/audio ﬁle. If you wish

to delete a speciﬁc ﬁle, press the Menu button once, and a submenu will appear.

Use the Power Button to conﬁrm the deletion and the Menu Button to cancel the

operation.

To enter the Playback Filelist Mode, press the Playback Button, and the ﬁle list

will be displayed, allowing you to easily locate a speciﬁc ﬁle.

Press the Playback Button again to exit the Playback Mode.

2.8 Charge The Camera

To charge the camera (No.19 Type C Port), use a USB charger with a 5-volt

output, such as a mobile phone charger or a computer USB port. During

charging, the Charging LED(No.16) will light up in red. It takes approximately 3

hours to fully charge the camera.

For the ﬁrst time use, we recommend charging the camera for 3 hours to ensure

a full charge. Please note that in order to protect the environment and reduce

electronic waste, we do not provide a charger with the camera. If you really need

one, please contact our customer support.

SPIKECAM

To enter the Menu Setting Mode, simply press the Menu Button (No.12) with a

short press. You can use the Up and Down buttons to navigate through the menu

items. Press the Power Button(Conﬁrm Button) to make modiﬁcations to the

selected setting. To go back or exit the Menu Setting Mode, use the Menu

Button(Return Button).

3. Camera Setting

Submenu Details are as Below:

5)EV: Exposure Value, ranging from -2 to +2.

8)Date Tag: If you set it to "Oﬀ," the time stamp will not be displayed in the video

footage.

These options represent the resolution at which the video will be recorded,

along with the frames per second (30FPS) for smooth playback.

6) Motion Detection: Oﬀ/On. Enabling the Motion Detection setting allows the

camera to automatically initiate 20-second video recording when it detects

signiﬁcant movement or shaking. To exit the motion detection mode, cover the

lens to ensure no movement is detected. Wait for the 20-second video

recording to ﬁnish, then press the Menu Button to access the menu and turn oﬀ

the motion detection setting.

9)Beep Sound: If you set it to "Oﬀ," the camera will not emit beep sounds when

keys are pressed.

10)Time Setting: Use the Up and Down buttons to adjust the digits, and use the

Power Button to conﬁrm and proceed with setting the Year, Month, Day, Hour,

Minute, and Seconds.

3)Cyclic Record: Oﬀ/3/5/10mins. This setting determines the maximum duration

of each video recording. Once the speciﬁed time limit is reached, the camera will

automatically stop recording and start a new video ﬁle. Selecting a shorter video

length may be useful if you prefer to have smaller video ﬁles or if you want to

ensure a more manageable duration for each recording.

4) White Balance: Auto/Sunlight/Cloudy/Tungsten.

7) Audio: Oﬀ/On. If you set it to "Oﬀ," the camera will not capture audio during

video recording mode, only pictures.

1 Resolution）: 1920x1080P/1280x720P(2K Not Available on this version)

2)Image Quality: 1/2/3MP. These options represent the number of megapixels

(MP) that will be captured in each photo. Higher resolutions generally result in

larger photo sizes and potentially higher levels of detail, but it will occupy more

storage and RAM. 2MP resolution is recommended.

SPIKECAM

24)Reset System: Restore to factory settings

23) Format: Format SD Card. Caution: Formatting the SD card will result in the

loss of all data stored on it. Please ensure that you have backed up any

important ﬁles before proceeding with the formatting process.

25) Version: Current ﬁrmware version.

21) Siren Announcement: Not Available in the English version.

22) Modify Device No.: Oﬀ/On. Change the Device ID (4 digits). Utilize the Up

and Down buttons to select the numbers and press the Menu Button to proceed

next digit. Finally, use the Power Button to conﬁrm the new Device ID.

20) File View Mode: Not Available.

13) Flicker: 50/60Hz. Display Refresh Rate.

14) Screen Saver: Oﬀ/3/5/10mins. If there is no interaction with the camera for

a while, the screen will automatically turn oﬀ to protect it and conserve power.

Press any button to reactivate the screen.

15) Resolution Switching: Not Available.

17) Picture Quality: Economic/Normal/Fine. It allows you to adjust the quality

of the photos taken. It is recommended to choose "Fine" for the highest quality.

While there may not be a signiﬁcant diﬀerence between the options, selecting

"Fine" ensures the best possible image quality.

18) Video Pre-Recording: Enabling the Pre-record feature allows the camera

to start recording a speciﬁed duration of video footage before the actual

recording is triggered. This feature can be useful for capturing important

moments that might have occurred just before you initiated the recording. While

in Pre-record mode, the counting seconds will be displayed in blue color.

16) Volume: Speaker volume, ranging from 0 to 7.

11)Auto Power Oﬀ: Oﬀ/1Minutes/3 Minutes. In standby mode, the camera will

automatically power oﬀ after the speciﬁed duration.

19) Time Lapse Video: Also known as post-record. Enabling the Post-record

feature allows the camera to continue recording for a speciﬁed duration of time

after you stop the recording. For example, if you select "10s," the camera will

record an additional 10 seconds of video after you have pushed the stop

recording slider. This feature is useful for capturing any important moments that

may occur right after you have ﬁnished recording.

12)Language: English, Chinese, Japanese, Korean, Russian, French, German,

Czech, Portuguese, Polish, Dutch, Turkish, Thai

SPIKECAM

To connect the camera to a PC, use a Type C USB cable to connect the camera

to the PC via the Type C Port (No.19). Once connected, the camera's LCD

screen will display three options: Memory, PC camera, and Video. Use the

Power Button to conﬁrm your selection for each option.

Memory: Selecting this option will turn the camera into a USB drive on your

computer, allowing you to copy ﬁles between the camera and the PC.

PC Camera: Choosing this option will turn the camera into a USB PC camera.

You can utilize VLC player or similar software to capture the video streaming

from the camera.

Video: If you select this option, the camera will not perform any additional

action and will only charge while connected to the PC.

4. Connect to PC

06:00:00 FHD

2023/10/04 18:20:50

DSJ-0000

5. LCD Information

Recording

Information

Device ID Date/Time

TF Card Inserted

Microphone On

Remaining Battery

SPIKECAM

6. Trouble Shooting

1) If your camera is unable to boot, please ensure that the camera battery is fully

charged for at least 2 hours. Once charged, try turning on the camera again.

2) If you're experiencing diﬃculties connecting the device to your computer,

please attempt the following solutions:

3) If your camera is not responding or experiencing issues, you can try rebooting

it by using a pin to press the RST (Reset) Hole.

If the issues persist even after trying these solutions, please contact our

customer service via email at for further assistance.info@spikecam.com

ŸTry using a diﬀerent USB port on another computer.

ŸUse a diﬀerent USB cable for the connection.

For more detailed information about this body camera, please visit our website

at https://www.spikecam.com/z11

SPIKECAM

Scan to watch training video

https://www.spikecam.com/z11

Tabla de contenidos

Otros manuales de Cámara digital de SPIKECAM

SPIKECAM

SPIKECAM Z10 Manual de usuario

SPIKECAM

SPIKECAM SC02 Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
