OWNER´S MANUAL

2000.4

Introduction..................................................................................................................................................... 3

Package contents ...................................................................................................................................... 3

Safety instructions ...................................................................................................................................... 4

Assembling and Disassembling the plastic cover.................................................................. 5

Panels description

Audio inputs and controls ............................................................................................ 6

Power inputs and audio outputs............................................................................... 7

Installation sequence................................................................................................................................ 8

Electrical Dimensioning........................................................................................................................... 9

Audio inputs

RCA inputs ............................................................................................................................ 9

Wiring diagram

Four channels wiring diagram................................................................................ 10

Three channels wiring diagram ............................................................................. 10

Two channel wiring diagram ..................................................................................... 11

Procedure for setting the Gain .......................................................................................................... 11

Crossovers set up ................................................................................................................................... 12

Battery connection diagram .............................................................................................................. 13

Technical specifications

Parameters......................................................................................................................... 14

Dimensional data............................................................................................................ 14

Additional Information............................................................................................................................ 14

Document revision code: 1000750266-001/JUN2023

INTRODUCTION

Dear Consumer,

Congratulations, you have just acquired a SounDigital product of the highest

technology and quality, so we thank you for your trust.

SounDigital products are made with raw materials of the highest quality

standards, and the most modern processes, equipment and technology are

used in their production.

PACKAGE CONTENTS

▪ 01 2000.4 EVO5 amplifier

▪ 01 Quick installation guide with warranty certificate

▪ 01 Promotional sticker

IMPORTANT INFORMATION

On this manual you will learn about the product, its features and

characteristics, in order to obtain the best result and to be able to enjoy your

music with SounDigital quality and power.

Read this manual carefully and follow precisely all the information contained

therein, these are very important and allow your amplifier to work optimally. If you

think it is necessary, please do not hesitate to contact our technical support at the

following contact:

info@soundigitalusa.com

*Merely illustrative image.

SAFETY INSTRUCTIONS

THIS "WARNING" SIGN ALERTS THE USER OF IMPORTANT INFO. NOT FOLLOWING

THESE INSTRUCTIONS MAY CAUSE INJURIES TO THE USER OR DAMAGE TO THE

EQUIPMENT.

Warning!

To avoid injury to the user or damage to the amplifier, read all safety instructions

written on this manual.

Before proceeding with the

installation of any electric

equipment on your vehicle,

u n p l u g t h e n e g a t i v e ( - )

terminal of the battery to avoid

fires, injuries or damages;

Use your sound system safely.

The continuous exposure to

sound pressures over 85dB

m a y c a u s e i r r e v e r s i b l e

hearing damage;

This equipment is for use in

a u t o m o t i v e D C v o l t a g e

batteries between 12.6 and

14.4 volts. Before installing the

equipment, check voltage of

the batteries;

Do not install the amplifier in

places exposed to water, dirt

or humidity;

Choose a ventilated place to

install the amplifier and avoid

blocking the side ventilation

windows;

Fix the amplifier properly and

firmly. Avoid fixing to metallic

parts of the vehicle, as this

procedure may cause ground

looping (noise);

When passing cables through

metallic walls, use rubber

O-rings to avoid cable cutting

and short-circuits;

Make sure that the chosen

location for the amplif ier

installation does not affect the

operation of the vehicle;

T his p r o d u c t m ay r e a c h

t e m p e r a t u r e s o v e r 6 0 ° C

(140°F). Make sure it is cold

before touching it;

Clean the amplifier periodically

with brush or dry cloth to

assure the thermal efficiency

of the heatsink;

Be careful when making holes

in the vehicle. Make sure you

are not making holes in the

fue l t ank , brake l ine s o r

electrical cables of the vehicle;

Make sure the cables are

properly secured throughout

the installation;

Wear gloves, safety glasses

and all necessary PPE during

the installation of SounDigital

amplifiers.

The installation of this product

must be done by a qualified

professional. In case of any

doubt, please contact our

technical support;

ASSEMBLING AND DISASSEMBLING THE PLASTIC COVER

The plastic covers have the function of finishing and hiding the amplifier fixing

screws. To disassembling and assembling them, follow the instructions below.

1 2

DISASSEMBLING OF THE PLASTIC COVER

ASSEMBLING THE PLASTIC COVER

1. Carefully pull out the top of the plastic cover to release the upside latches, as shown in picture 1.

2. Slide up the plastic cover in a continuous movement to remove it.

1. To fit the plastic cover back, carefully insert the point A of the plastic cover into point B of the

amplifier, slowly sliding it down.

2. Gently press the sides of the top of the plastic cover towards the bottom of the amplifier until

you hear a clicking noise.

*Merely illustrative images.

PANELS DESCRIPTION

Variable Gain control

Audio input – RCA connectors

1 6 7

Blue "POWER ON" LED indicator

Crossover switch key

High Pass – Full – Low Pass

CH1/CH2

CH /CH3 4

5CH1/CH2

CH /CH3 4

CH3

CH4

CH1

CH2

4 5 3

PANELS DESCRIPTION

+12 VDC

1021

13 14 15 16 17 18 19 20

-Negative power supply connector (GND)

Remote power supply connector (REM)

Positive power supply connector (+12VDC)

Minimum speaker load allowed

in BRIDGE (impedance)

Positive speaker connector (+)

Negative speaker connector (-)

Speakers output

connectors

Speakers output

connectors

Speakers output

connectors

Speakers output

connectors

Negative speaker connector (-)

Positive speaker connector (+)

Negative speaker connector (-)

Positive speaker connector (+)

Negative speaker connector (-)

CH1/CH2

CH /CH3 4

ØMount the amplifier in such a way you have access to the connectors;

ØInstall the power cables in the vehicle properly, starting from the battery to the fuse holder

or circuit breaker, use the cable with the appropriate size. Make all connections, install fuse

holders or circuit breakers, but without placing the fuses or with the circuit breakers in the

"OFF" position;

ØConnect the power cables in to the amplifier, observing the polarity. Connect all the positive

cables from the fuse holder or circuit breaker to the positive conector of the amplifier (+)

and all the negative power cables from the batteries to the negative connector of the

amplifier;

ØThe ground cable must be as short as possible and must be connected to the vehicle

chassis and the battery negative;

ØInstall the signal input cables in a proper way, distant from the power cables;

ØConnect the RCA or the high level signal input cables to the head unit and amplifiers;

ØInstall the audio output cables with the appropriate section, distant from the power and

audio input cables;

ØConnect the audio output cables to the amplifier and speakers respecting the positive (+)

and negative (-) polarities;

ØInstall the remote cable with the power cables, using 1.5mm² (15 AWG) cable or thicker;

ØConnect the remote power cable to the amplifier's "REM" terminal at the main unit's remote

power output (when not using the high level signal inputs);

ØBefore powering the system, verify all the connections and make sure there are no

mistakes or short-circuits on the power and ground cables;

Ø;Reconnect the ground of the batteries

ØCheck if the head unit is turned off and then place the fuses in the fuse holders or switch the

circuit breakers on;

ØTurn on the main unit and the amplifier will turn on the "POWER ON" LED indicating that it is

in operation.

INSTALLATION SEQUENCE

Remove the paint

between the terminal

and chassis

THE MAXIMUM DISTANCE FOR THE INSTALLATION OF THE FUSE/CIRCUIT BREAKER

IS 12 INCHES (30cm) AWAY FROM THE BATTERY.

BEFORE PROCEEDING WITH THE INSTALLATION, UNPLUG THE NEGATIVE TERMINAL

FROM ALL OF THE BATTERIES, TO AVOID FIRE, DAMAGE TO THE AMPLIFIER AND THE

USER HIMSELF.

Minimum recommended

i n s t a l l a t i o n d i s t a n c e

between amplifiers*.

1.18in. (30mm)

*For installations with more than one ampliﬁer, second unit not included. Merely illustrative images.

Warning!

AUDIO INPUTS

RCA inputs

All RCA inputs must be connected for the amplifier to

work properly. If the signal source is mono type, use "Y"

cable at the input.

ELECTRICAL DIMENSIONING AND AUDIO INPUTS

ELECTRICAL DIMENSIONING

For proper operation of your SounDigital amplifier, you need the proper

dimensioning of the electrical system and the cables used.

The table below shows the minimum section of GND cables, +12VDC cables

and speaker output cables according to the power generated by the amplifier.

SPEAKER CABLE

GROUND CABLE (GND)

POWER CABLE (+12VDC)

2000

WRMS

21mm² (4 AWG)

2 x 2mm² (12 AWG)

We recommend the use of only OFC (Oxygen Free Copper) cables on the

installation of our products.

Copper-clad aluminum wire (CCAW) must not be used.

Model Minimum impedance of use according to the model

2000.4 2Ω

2000.4 4Ω

2Ω

Bridge

1Ω

Per channel

4Ω2Ω

+12 VDC

REMOTE

FUSE +12V

+12V

FUSE

+12V

Model Minimum impedance of use according to the model

2000.4 2Ω

2000.4 4Ω

2Ω

Bridge

1Ω

Per channel

4Ω2Ω

REMOTE

FUSE +12V

+12V

FUSE

+12V

(PER CHANNEL)

(BRIDGE)

WIRING DIAGRAM

4 CHANNELS WIRING DIAGRAM (Per channel)

3 CHANNELS WIRING DIAGRAM

In case of connections

with more than one battery,

see the installation diagram

on .page 13

In case of connections

with more than one battery,

see the installation diagram

on .page 13

All RCA inputs must be connected for

the ampliﬁer to work properly. If the

signal source is a mono type, use a

"Y" cable at the input.

All RCA inputs must be connected for

the ampliﬁer to work properly. If the

signal source is a mono type, use a

"Y" cable at the input.

(PER CHANNEL)

Otros manuales para 2000.4 EVO5

Tabla de contenidos

Otros manuales de Amplificador de Soundigital

Soundigital

Soundigital 400.4D EVO Manual de usuario

Soundigital

Soundigital EVOX2 1600.1 Manual de usuario

Soundigital

Soundigital EVOPS 1200.1 Manual de usuario

Soundigital

Soundigital EVOX 800.1 Manual de usuario

Soundigital

Soundigital 400.2 EVO4.0 Manual de usuario

Soundigital

Soundigital 2000.1D EVO Manual de usuario

Soundigital

Soundigital 3000.1 EVO5 Manual de usuario

Soundigital

Soundigital 2000.4 EVO5 Manual de usuario

Soundigital

Soundigital EVOX2 1200.4 Manual de usuario

Soundigital

Soundigital 1600.1 EVO5 Manual de usuario

Soundigital

Soundigital 8000.1D EVO Manual de usuario

Soundigital

Soundigital POWER 20000.1D Manual de usuario

Soundigital

Soundigital 800.4 EVO6 Manual de usuario

Soundigital

Soundigital EVOX2 800.4 Manual de usuario

Soundigital

Soundigital EVOPS POWER SPORTS 2000.4 Manual de usuario

Soundigital

Soundigital 1 200.2 EVO5 Manual de usuario

Soundigital

Soundigital 20000.1 EVOX Manual de usuario

Soundigital

Soundigital SD1600.1D HV EVOLUTION Manual de usuario

Soundigital

Soundigital 20000.1 EVOX Manual de usuario

Soundigital

Soundigital EVOX 800.1 Manual de usuario

Soundigital

Soundigital SD 400.4D Evolution Manual de usuario

Soundigital

Soundigital POWER 5500.1D Manual de usuario

Soundigital

Soundigital 6500.1D EVO Manual de usuario

Soundigital

Soundigital 20000.1 EVOX Manual de usuario

Manuales populares de Amplificador de otras marcas

ASTRO

ASTRO HVO V40 P Manual de usuario

Marantz

Marantz SUPERSCOPE BLA-545 Instrucciones de montaje

NAD

NAD CI980 Manual de usuario

Technics

Technics SE-CH770 Manual de usuario

Harman Kardon

Harman Kardon HK6300 Manual de usuario

NAD

NAD T975 Manual de usuario

McIntosh

McIntosh MA6850 Manual de usuario

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manual de usuario

Viatron

Viatron Autrix Manual de usuario

GME

GME GA9800 Manual de usuario

Atlas

Atlas CP700 Manual de usuario

Roland

Roland KC-1000 Manual de usuario

Pyle

Pyle PFMRA350BW Manual de usuario

Advantage

Advantage S-250 Manual de usuario

IRT Electronics

IRT Electronics DVA-3007 Manual de usuario

Dimavery

Dimavery BA-100 Series Manual de usuario

Sony

Sony XM-S400D Manual de usuario

Schertler

Schertler ROY X Manual de usuario
