Soundcore Spirit Dot 2
USER MANUAL
01 EN
Charging
• Slide to open or close the charging case to activate the LED battery indicator.
• Fully charge both the earbuds and the charging case before the rst use.
• To prevent damage, use the provided USB-C cable.
• Fully dry off the earbuds and the USB port before charging.
< 30%
30% - 70%
> 70%
100%
LED indicators (Earbuds)
Flashing red once every 1 minute Low battery
Steady white Being charged
Light off Fully charged
Powering On/Off
The earbuds will automatically power on when taken out of the charging case and power off
when placed back into the charging case.
ON
OFF
EN 02
• To manually power on, press and hold the multi-function button on both earbuds for 2
seconds until the LED indicators turn white for 1 second.
• To manually power off, press and hold the multi-function button on both earbuds for 8
seconds until the LED indicators turn red for 1 second.
Pairing
True Wireless Stereo Connection
The right earbud will automatically connect with the left earbud when taken out of the
charging case.
LED indicators (Earbuds)
Flashing white TWS connecting
Rapidly ashing white (Primary earbud)
Slowly ashing white (Secondary earbud) TWS connected
• The right earbud is the primary earbud by default. In TWS mode, place either one of the
earbuds into the charging case, the other one will switch to be the primary earbud.
• When powered on and connected, if either one of the earbuds is out of battery and
powered off, you can keep using the other one.
Bluetooth Pairing with your Device
1. Take earbuds out of the charging case or manually power on the earbuds, wait for 1 to 3
seconds until the LED indicator on one of the earbuds ashes white, then earbuds enter the
Bluetooth pairing mode successfully.
2. Turn on Bluetooth on your device and click “Soundcore Spirit Dot 2”. The LED indicators
on both earbuds will turn white for 1 second when Bluetooth connected.
03 EN
1
2
Soundcore
Spirit Dot 2
Soundcore
Spirit Dot 2
PAIRING
CONNECTED
LED indicators (Earbuds)
Flashing white Bluetooth pairing
Steady white for 1 second Bluetooth connected
• To pair with another Bluetooth device, turn off Bluetooth on the currently connected device
rst.
• When earbuds are out of the charging case and powered off, to manually enter Bluetooth
pairing mode, press and hold the multi-function button on both earbuds for 5 seconds.
• Each time you power on your Soundcore earphones, it will automatically connect to your
last successfully connected device if available within the Bluetooth range.
Wearing
1. Choose the EarTips and EarWings that t your ears best.
2. Insert the earbuds into the inner canal of your ears.
3. Turn and nd the most comfortable position.
EN 04
1
2 3
Controls
Play / Pause Press twice (R)
Next track Press twice (L)
Volume up / down Control volume via the connected device
Answer / End a call
Press twice (L or R)
Put the current call on hold and answer
an incoming call
Reject a call
Press and hold for 2 seconds (L or R)
Transfer a call between earphones and
mobile phone
Switch between held call and active call
05 EN
Activate Siri or other voice assistant software Press and hold for 2 seconds (L or R)
Mono mode
Play / Pause
Press twice (L or R)
Answer / End a call
Reject a call
Press and hold for 2 seconds (L or R)
Activate Siri or other voice assistant software
Reset
You might need to reset the earbuds if any issues with earbuds such as connectivity problems
or function issues.
1. Place the earbuds into the charging case and make sure they are being charged for at least
10 seconds.
2. Keep the charging case open and continuously press the button on both earbuds 5 times
until the LED indicators ash red 3 times.
All the memory data will be cleared.
1
2
5
3
10”
EN 06
Specifications
Specications are subject to change without notice.
Input 5 V 500 mA
Rated output power 5 mW @ 1% THD
Battery capacity 55 mA x 2 (earbuds); 340 mA (charging case)
Charging time 1.5 hours
Playtime
(varies by volume level and content) 5.5 hours (Totally 16 hours with the charging case)
Driver size 8 mm x 2
Frequency response 20 Hz - 20 kHz
Impedance 16 Ω
Bluetooth version V 5.0
Bluetooth range 10 m / 33 ft
