Sound Sation TTM-30 Manual de usuario
2
Dear customer,
First of all thanks far purchasing a SOUNDSATION® product. Our mis-
sion is to satisfy all possible needs of musical instrument and profes-
sional audio and lighting users oering a wide range of products using
the latest technologies.
We hope you will be satised with this item and, if you want to collab-
orate, we are looking for a feedback from you about the operation of
the product and possible improvements to introduce in the next future.
Go to our website www.soundsationmusic.com and send an e-mail
with your opinion, this will help us to build instruments ever closer to
customer’s real requirements.
One last thing: read this manual before using the instrument, an incor-
rect operation can cause damages to you and to the unit. Take care!
The SOUNDSATION Team
Gentile cliente,
Grazie per aver scelto un prodotto SOUNDSATION®. La nostra missione
è quella di orire ai nostri utenti una vasta gamma di strumenti musicali
ed apparecchiature audio con tecnologie di ultima generazione.
Speriamo di aver soddisfatto le vostre aspettative e, se voleste collabo-
rare, saremmo lieti di ricevere un vostro feedback sulla qualità del pro-
dotto al ne di migliorare costantemente la nostra produzione. Visitate
il nostro sito www.soundsationmusic.com ed inviateci una mail con la
vostra opinione, questo ci aiuterà a sviluppare nuovi prodotti quanto più
vicini alle vostre esigenze.
Un’ultima cosa, leggete il presente manuale al ne di evitare danni alla
persona ed al prodotto, derivanti da un utilizzo non corretto
Il Team SOUNDSATION
3
TABLE OF CONTENTS
1. INTRODUCTION......................................................... page 4
2. FEATURES ................................................................... page 4
3. PACKAGE CONTENTS ................................................ page 4
4. CONNECTION AND SETUP ....................................... page 4
5. STORAGE .................................................................... page 5
6. TTM-30TechnicalSpecication............................... page 5
6.1. TTM-30 Frequency Response Graph ............................. page 6
6.2. TTM-30 Polar Pattern Chart............................................... page 6
7. WARRANTY AND SERVICE ....................................... page 7
8. WARNING................................................................... page 8
4
1. INTRODUCTION
TTM-30 Microphone is well designed for low and mid frequen-
cies. It is ideal for snare drums and tom drums.
2. FEATURES
fIdeal for Snare drums and Tom drums in live performances
and studio recording applications
fHigh Quality Head-grille microphone
fHigh Sensitivity and Low Self-Noise
fSatin Black
fRugged Body construction
3. PACKAGE CONTENTS
Your TTM-30 was carefully packed to ensure safe transport. De-
spite this, we recommend you to carefully examine the package
and its contents for any signs of physical damage, which can
occur during transport. In the package there are the following
items:
f1 x TTM-30 microphone
f1 x Owner’s manual
4. CONNECTION AND SETUP
Connect TTM-30 to the mixer(or other preamp board) using
a 3-pin XLR audio cable. After having placed the microphone,
start adjusting sound on your mixer by setting to ‘OFF’ or ‘FLAT’
the relative channel EQ rst. Then use EQ, reverb, echo or any
signal processing to create special eects, according to your
creative idea.
5
5. STORAGE
After use, wipe the TTM-30 with a clean cloth. To protect the
microphone from moisture, we strongly suggest you to cover it
with a protective cloth.
6. TTM-30 Technical Specification
Transducer Principle: Dynamic
Directivity Characteristic Cardiod
Frequency Response: 60Hz – 18kHz
Sensitivity: -53dB ± 3db
Output Impedance: 500 Ohm±30%
Mic. Size ( Ø ; Length ): 38 mm ; 99 mm
Mic. Weight: 192 g
Packing Size (WDH) 166 x 105 x 61 mm
Packing Weight 277 g
Technical specications and appearance subject to change without notice.
The information contained herein is correct at the time of printing
6
6.1. TTM-30 Frequency Response Graph
6.2. TTM-30 Polar Pattern Chart
7
7. WARRANTY AND SERVICE
All SOUNDSATION products feature a limited two-year warran-
ty. This two-year warranty is specic to the date of purchase as
shown on your purchase receipt.
The following cases/components are not covered from the
above warranty:
• Any accessories supplied with the product
• Improper use
• Fault due to wear and tear
• Any modication of the product eected by the user or a
third party
SOUNDSATION shall satisfy the warranty obligations by rem-
edying any material or manufacturing faults free of charge at
SOUNDSATION’s discretion either by repair or by exchanging
individual parts or the entire appliance. Any defective parts
removed from a product during the course of a warranty claim
shall become the property of SOUNDSATION.
While under warranty period, defective products may be
returned to your local SOUNDSATION dealer together with
original proof of purchase. To avoid any damages in transit,
please use the original packaging if available. Alternatively you
can send the product to SOUNDSATION SERVICE CENTER – Via
Enzo Ferrari , 10 – 62017 Porto Recanati - Italy . In order to send
a product to service center you need an RMA number. Shipping
charges have to be covered by the owner of the product.
For further information please visit www.soundsationmusic.com
8
8. WARNING
PLEASE READ CAREFULLY – EU and EEA (Norway, Iceland and
Liechtenstein) only
This symbol indicates that this product is not to be disposed
of with your household waste, according to the WEEE Directive
(2202/96/EC) and your national law.
This product should be handed over to a designated collection
point, e.g., on an authorized one-for-one basis when you buy a
new similar product or to an authorized collection site for recy-
cling waste electrical and electronic equipment (WEEE).
Improper handling of this type of waste could have a possible
negative impact on the environment and human health due to
potentially hazardous substances that are generally associat-
ed with EEE. At the same time, your cooperation in the correct
disposal of this product will contribute to the eective usage of
natural resources.
For more information about where you can drop o your waste
equipment for recycling, please contact your local city oce,
waste authority, approved WEEE scheme or your household
waste disposal service.
9
SOMMARIO
1. INTRODUZIONE...................................................... pagina 10
2. CARATTERISTICHE ................................................. pagina 10
3. CONTENUTO DELLA CONFEZIONE....................... pagina 10
4. CONNESSIONE E SETTAGGIO................................ pagina 11
5. CUSTODIA ............................................................... pagina 11
6.TTM-30-Specichetecniche ............................... pagina 11
6.1. TTM-30-Graco risposta in frequenza ..................................... pagina 12
6.2. TTM-30-Graco risposta Polare.................................................. pagina 12
7. GARANZIA ED ASSISTENZA.................................. pagina 13
8. AVVISO .................................................................... pagina 14
10
1. INTRODUZIONE
Il microfono TTM-30 è progettato per le frequenze basse e me-
die. È ideale per rullanti e tom.
2. CARATTERISTICHE
fIdeale per rullanti e tom durante esibizioni dal vivo e appli-
cazioni di registrazione in studio.
fAlta qualità della capsula e della griglia
fAlta sensibilità e basso rumore di fondo
fColore: Nero Satinato
fCorpo del microfono robusto
3. CONTENUTO DELLA CONFEZIONE
Il tuo TTM-30 è stato accuratamente imballato per garantire un
trasporto sicuro. Nonostante questo, si consiglia di esaminare
attentamente la confezione e il suo contenuto per eventuali
segni di danni sici, che possono vericarsi durante il trasporto.
Nella confezione ci sono i seguenti elementi:
f1 x microfono TTM-30
f1 x Manuale utente
