Picsel Viewer

for Sony CLIÉ

User Guide

: : a d e m o c r a c y o f a c c e s s : :

Picsel Viewer for

CLIÉ

User Manual

Neither the whole nor any part of the information contained in, or the product described

in, this document may be used, sold, transferred, adapted or reproduced in whole or in

part in any manner or form or in any media except with the prior written permission of the

The product described in this document is subject to continuous development and

improvement. All particulars of the product and its use contained in this document are

given by Picsel in good faith. However, the content of this document is provided “as is”,

without warranties of any kind with regard to its accuracy or reliability, and specifically

excluding all implied warranties, for example of merchantability, fitness for purpose, title

and non-infringement. In no event shall Picsel be liable for any special, indirect or

consequential damages whatsoever resulting from loss of use, data or profits, arising out of

or in connection with the use of this document. Picsel reserves the right to revise the

document or withdraw it at any time without prior notice.

No licence is granted (nor any rights of whatsoever nature granted), express or implied, to

any intellectual property by this document. Picsel, the Picsel cube device, IFV, Picsel

Browser and ePAGE are trademarks or registered trademarks of Picsel Technologies Ltd.

Throughout this document, the trade names and trademarks of some companies and

products have been used. No such uses are intended to convey endorsement of or other

affiliations with the document.

This document is proprietary to Picsel.

Document number PICSEL-EUG-0020B for landscape format PalmOS 5.2 Sony CLIÉs.

June 2003

Picsel EMEA Office

Picsel Technologies Ltd

Titanium House

Braehead Business Park

Kings Inch Road

Glasgow, G51 4BP,

Tel: +44 (0) 141 885 5588

Fax: +44 (0) 141 885 5599

http://www.picsel.com/

Picsel USA Office

Picsel Technologies Inc.

228 Hamilton Ave.

Suite 319

Palo Alto

CA 94301

USA

Tel: +1 (650) 798 5177

Fax: +1 (650) 798 5001

http://www.picsel.com/

Picsel Japan Office

Picsel Technologies K.K

Burex Kyobashi 5F

2-7-14, Kyobashi Cyuo-ku

Tokyo 104 – 0031

Japan

Tel: +81 (0) 3 5159 2111

Fax: +81 (0) 3 5159 2112

http://www.picsel.com/

Picsel Viewer for

CLIÉ

User Manual

Contents

Introduction 4

Getting Started 5

Panning and Zooming a document 5

Opening Documents 7

Using Picsel Viewer 8

Document View 8

Folder View 10

Document Format Restrictions 12

History View 14

Bookmark View 14

Other Options 15

Configuring Picsel Viewer 16

Acknowledgements 18

Questions and Answers 19

Picsel Viewer for

CLIÉ

User Manual

Introduction

Picsel Viewer is a revolutionary product for document browsing on thin-

client computing platforms. Its leading edge technology allows you to

view documents on your CLIÉ without any file-conversion or loss of

content. Powerful real-time zooming and panning of documents using

intuitive gestures allows close examination and broad overviews with

equal ease.

Picsel’s patented ePAGETM document display environment is the core

technology which brings new levels of satisfaction to your experience.

It allows you to view almost all documents in almost all permutations.

Central to its appeal is ePAGE’s ability to read files from desktop

environments in their native form. No conversion from the original

format or compromise is required.

Picsel Viewer’s intuitive user interface makes navigating documents

easier than ever. Simply by touching the pen to the device’s screen, you

can pan (scroll) your document sideways or vertically to view larger

pages on a smaller screen. With a gesture of the pen you can zoom in

or out to view intricate details or overviews. Moving to the next page is

as simple as turning a leaf in a book and a sophisticated yet attractive

menu is available with a tap on the icon in the corner of the screen.

Picsel Viewer supports HTML and all significant image formats (JPEG,

GIF, PNG, BMP, etc.), as well as most popular document types

including PDF, Word, Excel and PowerPoint. These prove the package

as a leading-edge multimedia and document environment

Picsel Viewer for

CLIÉ

User Manual

Getting

Started

Now that you have a Sony CLIÉ handheld powered by Picsel Viewer,

you’re ready to see it in action! It is available from the CLIÉ Application

Launcher screen, so to begin, tap the Home icon at the bottom of your

CLIÉ’s screen. Your device may differ slightly from the pictures shown

here. Please consult the “Read This First” operating instructions for

details of your model.

Home icon

CLIÉ application launcher showing Picsel

Viewer

Tap the ‘Picsel Viewer’ icon in the application launcher. This will

launch the application, briefly showing its starting screen. After

launching, you should open a document using the Folder View,

described later in this user guide.

Panning and Zooming a

document

The document you wish to see is normally larger than the screen space

available. There are two ways to see more of it.

To pan (or ‘scroll’) to a different part of the document, simply stroke

your pen across the screen in the direction you would like the page to

move. To pan the page up, touch and hold your pen somewhere near

the middle of the screen and draw a line towards the top, then take your

Pan (Scroll):

Zoom:

1. 2.

Picsel Viewer for

CLIÉ

User Manual

pen off the screen. You can do this repeatedly so that you can view any

size of document. Further, you can ‘throw’ the document across the

screen, and it will continue moving after you have released the pen.

This gives you time to start another stroke. This inertia can be used to

save time while you pan around the document.

You can also zoom the size of the document, so that more or less of it is

visible at a different size. The tap-and-stroke gesture for this is to tap

your pen briefly near the middle of the screen then tap and hold it again

in the same place. Now stroke your pen up to zoom in or down to

zoom out. Release your pen when you reach the scale you like. Using

this, you can view small print details on diagrams or get an overview of

a whole page.

The zoom box, showing in pink the area that will be

expanded using the horizontal tap-and-stroke gesture.

A further method for zooming into a specific area of the document is

available in Picsel Viewer, called ‘Zoom Box’. Use the same tap-and-

stroke gesture as above, starting at the top-left corner of the area you

would like to fill the screen. However, you should then stroke your pen

to the right instead of vertically. A coloured box will appear showing

the area that will be enlarged. Move your pen to make this cover the

area of interest, and release it.

While you hold your pen down on the screen, the quality of the image

may be poorer. This is to make the zooming more responsive to your

movement. When you release your pen, the quality will improve.

You can also pan the document up and down using the Jog Dial

Navigator on your CLIÉ. If you briefly press and release the Jog Dial, you

will then be able to pan horizontally by turning it again. Press it once

more to return to vertical panning. You can also zoom in and out by

pressing and holding the Jog Dial in and turning it at the same time.

Picsel Viewer for

CLIÉ

User Manual

Opening Documents

You can create documents on your desktop PC and copy them to

Memory Stick media. Picsel Viewer can read your favourite document

formats such as HTML, PDF, Word, Excel and PowerPoint without any

re-processing.

To look at files on your Memory Stick media or internal media, tap the

Picsel Viewer carousel icon and then tap the Folder View icon, from

where you can select documents to view. Tap your pen on any of the

files and after a moment it will appear on screen. You can move it

around, and zoom in or out, using the pen gestures you learnt earlier.

Picsel Viewer

carousel icon

Folder View ico

Picsel Viewer for

CLIÉ

User Manual

Using Picsel

Viewer

The main place for controlling Viewer is the carousel, which you can

open by tapping the Picsel logo in the bottom right corner of the screen

or by pressing the ‘Back’ button on your CLIÉ twice (the table on page

10 lists keys to press). From here you can go to the Folder View, the

History View or return to your document. You can also change your

preferences for the way the system operates. If you tap and hold your

pen on any of the options, a tool-tip will appear to explain its purpose.

The carousel will close after an option has been selected.

Document View

Rotate Screen

Add Bookmark

Pre fer en ces

Refresh page

History View

Folder View

Bookmark View

Help

The carousel

Document View

Most of the time, you are looking at the ‘Document View’, in which

you see the content of your chosen document. There are, however, four

different views in Picsel Viewer. If you want to return to the document

view when you are in a different mode, you can choose the document

view icon on the carousel, as shown.

While in this view, you can pan (scroll) around the page simply by

stroking your pen over the page in the direction you want it to move.

For example, to see what is lower down, press and hold your pen near

the middle of the screen and stroke it upwards.

To zoom in, briefly tap the screen near the middle then press and hold it

in the same place. Now, stroking upwards will zoom in and stroking

downwards will zoom out.

Document

View icon

Picsel Viewer for

CLIÉ

User Manual

While you are zooming or panning, the document will appear less

clearly and will then ‘sharpen up’ when you release the pen. This is

perfectly normal, and the clarity and speed with which the document

moves are part of the unique power of Picsel’s ePAGE technology.

There are three ways to move to a different page in a document. You

can draw a ‘page flick’ stroke across the bottom of the screen, as if you

were holding a page of a book (start in the middle at the bottom, then

stroke to the left to reach the next page, or the right to return to the

previous page). Alternatively, you can click on the carousel and use the

thumbnail copies of pages or the scroll bar along the bottom to find the

page you want. You can also press the “page up” and “page down”

buttons, as described in the “Keys” section, below.

document

Previous page Current

page

document

page

Visible part of

current page

Zoom

scroll

bar

Fit page

Fit width

First page Last page

Page scroll bar

The navigation controls which appear around the carousel

The tools around the side of the carousel offer more features. The scroll

bar along the bottom of the screen moves between pages and can be

moved by stroking your pen over the box to move through the

thumbnails for all of the pages of the current document. The arrows at

the end of the scroll bar move directly to the first and last pages of the

document, respectively. The page scroll bar is only useful for multi-page

documents, which do not include HTML pages or pictures.

You can also return to the previous document you viewed by tapping on

the ‘previous document’ thumbnail or page icon on the left of the

carousel, and after that, can move forward again to the ‘next document’

if you wish. You can go back several steps by tapping on the ‘previous

document’ repeatedly as it changes, although you may find the History

View more helpful. These thumbnails are displayed as page icons if you

move very quickly between documents.

The zoom scroll bar, to the left of the carousel, allows you to enlarge or

reduce the document without using the tap-and-drag gesture. Simply

stroke your pen up or down over the box in the scroll bar. Picsel Viewer

can also scale the document automatically to fit on the screen with the

‘fit page’ icon, or to fit the width of the document into the width of the

screen using the ‘fit width’ icon.

The visible part of the current page is shown on the current page

thumbnail as a red area which you can also move around with your

pen, should you wish to.

Picsel Viewer for

CLIÉ

User Manual

e 1

Keys

As well as tapping icons on the screen to perform actions in Picsel

Viewer, you can also press certain physical buttons, as follows:

Context Button Action

Page Up Previous pageAll views including

Document, History,

Bookmark and

Folder Views

Page Down Next page

Turn Jog Dial Pan vertically or horizontally

Push Jog Dial Change between horizontal

and vertical panning

Push and

Turn Jog Dial

Zoom in or out

Document View

Back

(multiple

presses)

1. Zoom to fit width

2. Open Carousel

3. Exit Picsel Viewer

Back

(multiple

presses)

1. Open Carousel

2. Exit Picsel Viewer

Turn Jog Dial Change selected document

History, Bookmarks,

Folder Views

Push Jog Dial Open document

Folder View

You can look at documents stored on Memory Stick media or internal

media using the ‘Folder View’. To see it, click on the Folder View icon

as shown.

Initially, you will see a choice of Memory Stick media or internal media,

according to which you have inserted. Simply tap with your pen on the

icons to explore the files stored on each card.

The name of the current folder’s path location is shown at the top of the

screen and you can go to the folder above that in the folder structure by

tapping the ‘Up-Folder’ icon in the corner. You can also move to a

higher folder by clicking on the name at the top of the screen.

Folder View

The folders, which contain further documents, are shown in yellow with

tabs in the corners. Documents look like sheets of paper in various other

Folder View ico

Up-Folder icon

Otros manuales para CLIE PEG-UX40

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Software de Sony

Sony

Sony MEX 1GP - Giga Panel Radio Manual de usuario

Sony

Sony SRW5800/2 Manual de usuario

Sony

Sony ICD-CX50 - Visual Voice Recorder Manual de usuario

Sony

Sony CLIE PEGA-SA500 Manual de usuario

Sony

Sony Memory Stick Autorun Manual de usuario

Sony

Sony NWZ-A815BLK - 2gb Digital Music Player Manual de usuario

Sony

Sony DSC-RX100M2 Guía de referencia

Sony

Sony BDP-BX57 - Blu-ray Disc™ Player Manual técnico

Sony

Sony ICD-R100 Operating Instructions (primary... Manual de usuario

Sony

Sony PEG-N610C Memory Stick Autorun v1.3 Manual de usuario

Sony

Sony DPP-MS300E Manual de usuario

Sony

Sony Sound Forge - Sound Forge Audio Studio 8 Manual de usuario

Sony

Sony VAIO VGN-TXN15P - VAIO - Core Solo 1.2 GHz Manual

Sony

Sony MSSW-IC2P Manual de usuario

Sony

Sony PlayStation 3 (Uncharted: Drake's Fortune Limited Edition... Manual de instrucciones

Sony

Sony DCR-TRV260 - Digital Handycam Camcorder Guía del usuario

Sony

Sony MZ-N10 Manual de usuario

Sony

Sony MZ-DH10P Hi-MD Music Transfer Version 1 for Mac (User... Manual de usuario

Sony

Sony VAIO VGN-CR440F Manual

Sony

Sony SonicStage Simple Burner Manual de usuario

Sony

Sony ERS-311 AIBO Life Manual de usuario

Sony

Sony DCR-IP5 MovieShaker v3.1 Manual de usuario

Sony

Sony Pro 10 Manual de usuario

Sony

Sony DSC-F55 Manual de usuario

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

Avaya

Avaya NULL One-X for RIM Blackberry Manual de usuario

HP ProLiant BL420c Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Avaya

Avaya Interaction Center Manual de usuario

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Canon

Canon Vixia HF21 Manual de usuario

Canon

Canon ZR950 Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario
