Sony ERS-1000 Guía de referencia

Help Guide

ENTERTAINMENT ROBOT

ERS-1000

This Help Guide is provided to help you when you have issues or questions in the course of your life with aibo.

The information contained in this Help Guide is provided based on the assumption that aibo's system software and the

My aibo app are updated to their latest versions.

Locating parts and controls

aibo

Movable body parts

Sensing features on aibo's body (Sensors, Cameras, Microphones)

Features on aibo's body surface (Button, LEDs, Pins)

Features inside aibo's body (Button, Switch, SIM card slot)

Charging station

Accessories

Getting ready for your life with aibo

Getting the charging station ready

Where to place the charging station

Setting up the charging station
Turning on/off aibo
Turning on aibo
Putting aibo into sleep mode/turning off aibo
Turning off aibo forcibly in the event of emergency
Setting up aibo
Adding a second and subsequent aibo products
Viewing how to play with aibo (Tutorial)
Raising aibo
Getting to know aibo
Getting to know aibo better
aibo's desires and emotions
aibo's growth and change
aibo's personality
Checking the status LED for the state of aibo
Interacting with aibo
Picking up and taking aibo to somewhere else
Showing an object to aibo
Touching aibo
Talking to aibo
Having aibo take photos
Enabling/disabling aibo's photo-taking feature
Telling aibo to take a photo
Having aibo automatically take photos
Viewing the photos taken by aibo
Saving/sharing the photos taken by aibo
Teaching aibo a trick by moving the front paws
Charging aibo's built-in battery
Charging aibo's built-in battery with the charging station
Charging aibo's built-in battery with the charging stand
2

Letting aibo charge the built-in battery on its own (Self-charging)
Using the My aibo app
What you can do with the My aibo app
Getting to know the My aibo home screen
Home screen of the My aibo app for smartphones
Home screen of the My aibo app for computers
Setting up aibo
Setting up aibo
Adding a second and subsequent aibo products
Selecting aibo for viewing information on the My aibo app
Changing aibo's settings
Renaming aibo
Changing the language to talk to aibo
Changing the volume of aibo's voice
Changing the time zone setting
Connecting aibo through a Wi-Fi network
Connecting aibo to the Wi-Fi network for Internet access
Using the Wi-Fi Protected Setup™ (WPS) button for Wi-Fi network connection
Using the SSID (network name) for Wi-Fi network connection
Deleting the Wi-Fi settings
Enjoying aibo's views
Viewing what aibo is seeing
Viewing the photos taken by aibo
Saving/sharing the photos taken by aibo
Having aibo take patrols (My aibo app for smartphones only)
Having aibo memorize people to visit and patrol destinations
Viewing the results of aibo’s patrols
Managing aibo's tricks
Having aibo show tricks
Editing the label of the trick you taught aibo
3

Publishing the tricks you taught aibo
Having aibo memorize the tricks published by other owners
Changing aibo's eye color and voice
Changing aibo's eye color
Changing the sound of aibo's voice
Playing with the virtual aibo (My aibo app for smartphones only)
Updating aibo's system software
Checking for latest updates to the system software
Updating the system software automatically
Updating the system software manually
Restoring aibo to the default state (Initialization)
Viewing additional information
Viewing notifications
Viewing the contract information
Viewing the owner information
Viewing the support information
Enabling/disabling the sound effects or the background music
Notes on use/specifications
Notes on use
About Software
Specifications
Trademarks and copyrights
Transferring/disposing of aibo
Transferring aibo
Disposing of aibo
Frequently asked questions/contact information
Frequently asked questions
What if aibo seems to have an issue?
What if the status LED flashes in red?
What if the ear comes off from the body?
4

What if the tail comes off from the body?

Contact information

Help Guide

ENTERTAINMENT ROBOT

ERS-1000

Movable body parts

aibo has a total of 22 joints (technically called 22 degrees of freedom) and these joints allow aibo to show a wide variety

of actions to express how it feels or what it wants.

Head1.

Mouth2.

Neck3.

Front paws4.

Back paws5.

Tail6.

Waist7.

Ear8.

Help Guide

ENTERTAINMENT ROBOT

ERS-1000

Sensing features on aibo's body (Sensors, Cameras, Microphones)

aibo has the features to determine what is going on around it. These features are equivalent to some of the senses of

humans and animals.

Touch

You can interact with aibo by petting it on the head or back or under the chin, or by touching its paw pads. See Touching

aibo for more information.

Audition/vision

aibo picks up ambient sounds, including human voices, through its microphones and learns what is going on around it

through cameras and sensors.

Head sensor1.

Jaw sensor2.

Paw pads3.

Back sensor4.

Front camera

Fish-eye view (wide-angle) camera located at the tip of aibo's nose. aibo uses this camera to identify the colors,

shapes, and motions of objects in a wide range as well as to take photos.

ToF sensor

Detects the distance to an object in front of aibo to prevent aibo from colliding with obstacles.

Note

Depending on the ambient conditions or the state of aibo, the sensors may fail to detect objects. Do not use aibo on a place from

which aibo may fall off or on an uneven surface.

Motion sensor

Detects if there is a moving object, such as a person or an animal, in front of aibo.

Ranging sensors

Detect the distance to an object in front of aibo. When a difference in surface level, for example a drop, is detected,

aibo backs away or turns away to prevent itself from falling off.

Microphones

Picks up ambient sounds including human voices. It also helps aibo identify the direction of sounds.

SLAM camera

SLAM camera located at aibo's waist. aibo uses this camera to identify interior features of a room and understand its

daily life territory.

The SLAM camera is not capable of taking photos.

Light sensor

Detects the degree of ambient brightness. aibo changes the brightness of its eyes or behaves differently in

accordance with the detected brightness.

Help Guide

ENTERTAINMENT ROBOT

ERS-1000

Features on aibo's body surface (Button, LEDs, Pins)

Indications of the network LEDs

Wi-Fi network LED

Status LED

Indicates the state of aibo. See Checking the status LED for the state of aibo for more information.

Power button

Turns on aibo or puts aibo in sleep mode.

Charging pins

Pass through power for charging aibo's built-in battery while in contact with the charge connector on the charging

stand.

Wi-Fi network LED

Indicates the state of the connection between aibo and a Wi-Fi network. See the following table for the LED

indications.

Mobile network LED

Indicates the state of the connection between aibo and your mobile network. See the following table for the LED

indications.

Indication State

Lit in green aibo is connected to the Internet through a Wi-Fi network.

Flashing in green

aibo fails to establish a connection to a Wi-Fi network.

The settings for connecting to the Wi-Fi router/access point may not be properly configured.

Check the Wi-Fi router/access point for power supply or LAN cable connection.

Flashing in red

The attempt to connect to a Wi-Fi network with Wi-Fi Protected Setup™ button failed.

Check the Wi-Fi router/access point for its state and repeat the connection procedure with

the Wi-Fi Protected Setup™ button all over again.

Flashing alternately in

green and red aibo is waiting for a connection to a Wi-Fi network to be established.

Mobile network LED

Hint

For information about troubleshooting the issue that aibo fails to connect to a Wi-Fi network, visit the online support page at

https://www.sony.com/electronics/support.

Related Topic

Features inside aibo's body (Button, Switch, SIM card slot)

Putting aibo into sleep mode/turning off aibo

Charging aibo's built-in battery with the charging station

Viewing how to play with aibo (Tutorial)

Connecting aibo to the Wi-Fi network for Internet access

Using the Wi-Fi Protected Setup™ (WPS) button for Wi-Fi network connection

Using the SSID (network name) for Wi-Fi network connection

Indication State

Unlit

The Wi-Fi feature is not active due to one of the following reasons:

The Wi-Fi network settings are not configured on aibo.

aibo is out of the communication range of the connected Wi-Fi router/access point.

The network switch on aibo is in the “OFF” position.

Indication State

Lit in orange aibo is connected to a mobile network.

Flashing in

orange

aibo fails to connect to a mobile network due to one of the following reasons:

aibo is out of the service area of the mobile network or the mobile signal is weak.

Take aibo to a location with good signal reception or use a Wi-Fi connection.

The SIM card slot on aibo has no SIM card inserted.

Check if there is a SIM card inserted in the slot.

Unlit Access to a mobile network is disabled because the network switch on aibo is in the “OFF” or “1”

position.
