Sony Odyssey7Q+ Manual de usuario

Updated February 23, 2015 | Firmware Release v5.10.100

ProRes 422 (HQ)

ProRes 422

ProRes 422 (LT)

4K Apple ProRes

23.98, 25, 29.97 (Odyssey7Q+)

HD Apple ProRes

1080p23.98,24,25,29.97,50*,60*

720p50/60

SONY α7S

Odyssey7Q+

Odyssey7Q

SETUP GUIDE

SONY α7S

NOTES ABOUT USING THE ODYSSEY WITH THE A7S

The Odyssey7/7Q do not support 1080p59.94 or 4K over HDMI due to a hardware constraint. If Auto

HDMI output is used, the camera will output 1080i. (Odyssey7Q+ it will accept 4K or 1080p59.94)

PRORES RECORD TIMES

24 25 30 50 60

422(HQ)

4K to 4K ProRes 168 161 134

4K to HD ProRes 670 643 536 322 268

HD ProRes 670 643 536 322 268

422

4K to 4K ProRes 220 221 176

4K to HD ProRes 1060 1016 848 508 424

HD ProRes 1060 1016 848 508 424

422(LT)

4K to 4K ProRes 328 316 264

4K to HD ProRes 1516 1456 1212 728 604

HD ProRes 1516 1456 1212 728 604

Note: 4K and 1080p50/60 over HDMI is only supported on the 7Q+, to record 1080p50/60 on an Odyssey7 or

Odyssey7Q you must use a HDMI to SDI converter, as 7/7Q are limited to 1080p30 over HDMI due to a hardware

constraint.

Note: Odyssey 7 only has 1 SSD slot

FORMAT DETAILS

4K Apple ProRes 3840x2160 10-bit log video, originated from HD 8-bit camera signal, recorded as Apple

ProRes compressed 4K video .MOV

4K to HD ProRes 1920x1080, 10-bit log video, originated from 4K RAW 12-bit camera signal, transformed

and recorded as Apple ProRes compressed HD video

HD Apple ProRes 1920x1080,1280x720 10-bit log video, originated from HD 8-bit camera signal, recorded

as Apple ProRes compressed HD video .MOV

FRAME RATE SUPPORT

The Following A7s frame rates are supported on the Odyssey:

• 4K 23.98-30 (HDMI - Odyssey7Q+ Only)

• 1080p59.94/50 (HDMI - Odyssey7Q+ / HDMI to SDI Converter - Odyssey7Q)

• 1080i50/59.94

• 1080p25/29.97

• 1080p23.98 (24p output and 3:2 pulldown)

TYPICAL DOWNLOAD TIME IN MINUTES

Media USB3.0 Thunderbolt

256G SSD 20 10

512G SSD 40 20

1TB SSD 80 40

Actual transfer rates are dependent on computer system and desnaon media.

USB 3.0 or Thunderbolt connecons are recommended by Convergent Design for ecient data rates.

CONTINUED »

CAMERA SETTINGS

1. SWITCH CAMERA TO VIDEO MODE

ROTATE THE MODE DIAL TO THE POSITION.

2. SET INTERNAL RECORDING

MENU » » PAGE 2 » RECORD SETTING » (59.94/50/29.97/25/24)

XAVC-S for 30p / AVCHD fo 60i

3. SET CLEAN HDMI OUTPUT

MENU » » PAGE 3 » HDMI SETTINGS » HDMI INFO DISPLAY » OFF

4. SET HDMI OUTPUT

MENU » » PAGE 3 » HDMI SETTINGS » (AUTO/1080P/1080I)

NOTE: You may need to change 24p/60p output depending on your frame rate.

The A7s can output 23.98 over HDMI so this can be used or 1080i and 3:2 pulldown can

be used to achieve 1080p23.98 recording to the Odyssey.

4K (ODYSSEY7Q+)

Be sure that your Odyssey7Q+ is connected to your A7S via HDMI in order to enable

HDMI 4K output from the camera.

MENU » » PAGE 3 » HDMI 4K OUTPUT » (24P/25P/30P)

A notication will appear: When outputting 4K movies, you cannot record movies to

recording media. Click OK.

SONY α7S

5. SET HDMI TIMECODE/CAMERA TRIGGER

MENU » » PAGE 3 » HDMI SETTINGS » TC OUTPUT » ON

This will output timecode to the Odyssey, which will be recorded with your video signal.

MENU » » PAGE » HDMI SETTINGS » REC CONTROL » ON

This allows you to start/stop recording on the Odyssey with the record button on the A7S.

HDMI Info Display must be set to OFF before you can select HDMI 4K Output.

6. SET PICTURE PROFILE (SLOG-2)

MENU » » PAGE 5 » PICTURE PROFILE » PP7

Note: You may use any of the picture prole settings, however, The PP7 setting (SLOG-2)

gives you the full range of the sensor.

Note: If you use SLOG-2 you will need to congure the LUT control on the Odyssey by

tapping LUT on the lower menu and selecting Sony F5/F55 (SLOG-2). This LUT setting

matches the SLOG-2 on the A7S.

SONY α7S

ODYSSEY CONFIGURATION

1. SET ODYSSEY TO HD->HD APPLE PRORES MODE

HD RECORDING

☼

» SETUP » CAMERA » SONY » HD->HD PRORES(.MOV)

UHD TO HD RECORDING (ODYSSEY7Q+)

☼

» SETUP » CAMERA » SONY » 4K/UHD PRORES(.MOV)

4K RECORDING (ODYSSEY7Q+)

☼

» SETUP » CAMERA » SONY » UHD HDMI TO HD PRORES(.MOV)

2. MAKE A7S THE RECORD TRIGGER

☼

» SETUP » RECORD TRIGGER » CAMERA

3. SET TIMECODE SOURCE

☼

» SETUP » TIMECODE SOURCE » SDI/HDMI

The HDMI input is automatically detected when connected to the Odyssey.

** Note the HDMI input is on the right side of the unit, on the Odyssey7Q+ but is at the

bottom of the unit for Odyssey7 and 7Q.

4. SET PRORES BITRATE

☼

» SETUP » VIDEO CODEC » (SELECT)

PRORES HQ The Apple ProRes 422 (HQ) codec oers the utmost possible quality for 4:2:2 or 4:2:0 sources

(without an alpha channel) and provides the following:

• Target data rate of approximately 220 Mbps (1920 x 1080 at 60i)

• Higher quality than Apple ProRes 422

PRORES 422 The Apple ProRes 422 codec provides the following:

• Target data rate of approximately 145 Mbps (1920 x 1080 at 60i)

• Higher quality than Apple ProRes 422 (LT)

PRORES LT The Apple ProRes 422 (LT) codec provides the following:

• Roughly 70 percent of the data rate of Apple ProRes 422 (smaller le sizes than ProRes 422)

• Higher quality than Apple ProRes 422 (Proxy)

5. FORMAT SSDs

☼

» ODYSSEY » SSD’S » FORMAT BOTH

(or FORMAT SSD1 if you do not have a second SSD drive installed.)

SONY α7S

6. CONNECT TO CAMERA AND VERIFY STATUS INPUT

CONNECT A7S HDMI OUTPUT TO ODYSSEY HDMI INPUT

The status on your Odyssey will display your camera’s output.

Example:

UHD 23P 4:2:2

SONY

3840 x 2160

PRORES

4K/UHD

7. SET HDMI CADENCE

Connect HDMI input, and verify the camera internal record rate matches the input indicator

on the Odyssey. If it does not a Cadence may be needed to correctly reect the format in

which you wish to record.

☼

» SETUP » VIDEO CADENCE » PROGRESSIVE

PROGRESSIVE

Use this setting for 720p50/60, 1080p24**, 25*,30*

*Note typically the camera will need to be set to record 1080p25/30 internally, and the

output is set to 1080i.

**Note that when wishing to record 1080p24, HDMI output can be set to “Auto” or 1080i or

1080p (7Q+ only), therefore Progressive should be used when auto is selected.

INTERLACED

Use this setting for 1080i50, 1080i59.94 recording

3:2 PULLDOWN*/**

Use this setting for 1080p24 recording when the camera only has a output setting of

1080i, also note the camera must be set to record 1080p24 or 1080p23.98 internally,

**Note that when wishing to record 1080p24, HDMI output can be set to “Auto” or 1080i,

therefore 3:2 pulldown should be used when 1080i is selected.

OFF-LOADING DATA

COPYING FILES TO YOUR COMPUTER

1. CONNECT SSD DRIVE TO ADAPTER

Connect the Convergent Design 2.5” Premium SSD Media to any off-the-shelf 2.5” SATA

adaptor (example: Seagate GoFlex Thunderbolt Adaptor or USB 3.0 Adaptor)

2. CONNECT ADAPTER TO COMPUTER

The SSD will mount within 10-20 Seconds. (You will see this mount on the desktop or

within nder on MAC, or within My Computer on Windows machines).

3. COPY FILES FOR PLAYBACK/EDITING

All Clips or Takes are located within the “Clips” directory, navigate to this and copy all of

your les to a local or external drive or RAID for playback and/or editing.

SOFTWARE UTILITIES (FREE DOWNLOAD FROM WEBSITE)

CD CLIP MERGER (RAW/DPX)

Use the Clip Merger for any Raided Record (ie if your recorded clip required more than

one SSD). See the At A Glance Chart, “No. of SSD’s Req” column, on page 2.

CD APPLE PRORESS TRANSFER TOOL (FREE DOWNLOAD FROM WEBSITE)

Use to combine clips into a single le

Use to copy all les to a single directory without folder structure.

Required in order to transfer markers to your NLE.

CD DATA UNPACKER (DPX)

Use CD Data Unpacker to convert “packed” les to “unpacked” data.

ALL UTILITIES CAN BE DOWNLOADED FROM THE FIRMWARE/DOWNLOADS

AREA OF OUR WEBSITE: Convergent-Design.com/support/rmware-downloads.html

ATTENTION MAC OSX USERS

Before installing Convergent Design Software on Mac OSX You must rst change the

following settings.

1) Navigate to Applications » Utilities » System Preferences

2) Select Security and privacy

3) Under General » Allow applications downloaded from: Select Anywhere.

Apple ProRes

The Odyssey can record in Apple ProRes 422 (HQ), Apple ProRes 422 and Apple ProRes 422 (LT)

compressed codecs. This allows for high quality recording while avoiding high data rates of working with

uncompressed video.

NATIVE APPLE PRORES SUPPORT

Adobe CC 2014

Apple FCP X, Aperture

Cineform Studio

Final Cut Pro 7

Black Magic DaVinci Resolve

The Foundry Nuke

Autodesk Smoke

Sony Vegas

WORKING WITH RECORDED FILES

There are numerous post systems and NLEs that can read natively the various le formats recorded by

the Odyssey. Some NLEs may require plug-ins in order to read certain le formats. Blackmagic Design

Resolve software is available for free and can read all formats recorded by the Odyssey.

FILE STRUCTURE

Note: To combine les into a single directory use our ProRes Utility.

POST PRODUCTION

☎ ++(720)221-3861

✉ CDSupport@convergent-design.com

☁ Convergent-Design.com
