MVC-FD91
Digital Still Camera
Operating Instructions
Manual de instrucciones
GB
ES
2-GB
WARNING
To prevent fire or shock hazard,
do not expose the unit to rain or moisture.
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
Owner’s Record
The model and serial numbers are located on the bottom. Record the serial
number in the space provided below. Refer to these numbers whenever you
call upon your Sony dealer regarding this product.
Model No. MVC-FD91
Serial No.
English
Operating instructions
Before operating the unit, please read this manual thoroughly,
and retain it for future reference.
As you read through this manual, buttons and settings on the
camera are shown in capital letters.
e.g., Press FLASH.
3-GB
CAUTION
Never expose the battery pack to temperatures above 140°F (60°C), such as in
a car parked in the sun or under direct sunlight.
TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED AC
PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET
UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE
EXPOSURE.
You are cautioned that any changes or modifications not expressly approved
in this manual could void your authority to operate this equipment.
Note:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
For the Customers in the United States and CANADA
DISPOSAL OF LITHIUM ION BATTERY.
LITHIUM ION BATTERY.
DISPOSE OF PROPERLY.
You can return you unwanted lithium ion batteries to your nearest Sony
Service Center or Factory Service Center.
Note: In some areas the disposal of lithium ion batteries in household or
business trash may be prohibited.
For the Sony Service Center nearest you call
1-800-222-SONY (United States only)
For the Factory Service Center nearest you call
416-499-SONY (Canada only)
Caution: Do not handle damaged or leaking lithium ion batteries.
4-GB
NOTICE FOR THE CUSTOMERS IN THE UNITED
KINGDOM
A moulded plug complying with BS 1363 is fitted to this equipment for your
safety and convenience.
Should the fuse in the plug supplied need to be replaced, a 5 AMP fuse
approved by ASTA or BSI to BS 1362, (i.e., marked with 2or @mark)
must be used.
If the plug supplied with this equipment has a detachable fuse cover, be
sure to attach the fuse cover after you change the fuse. Never use the plug
without the fuse cover. If you should lose the fuse cover, please contact
your nearest Sony service station.
ATTENTION
The electromagnetic fields at the specific frequencies may influence the
picture and sound of this camera.
5-GB
Table of contents
Before using your camera....................................................................... 7
Parts identification .................................................................................. 8
Basic operations
Preparation ...................................................................................... 12
1: Charging the battery pack........................................... 12
2: Installing the battery pack........................................... 13
3: Setting the date and time ............................................ 14
Recording and playing back images............................................ 17
1: Recording still images ................................................. 17
2: Recording moving images .......................................... 18
3: Playing back still images ............................................. 21
4: Playing back moving images ...................................... 21
Battery life/No. of images that can be recorded/
played back ....................................................................... 24
Viewing images using a personal computer ....................... 25
Advanced operations
Changing the mode settings ......................................................... 27
Using various functions for recording ........................................ 36
Focusing manually .................................................................. 36
Releasing the Steady Shot function ...................................... 36
Adjusting the white balance .................................................. 37
Using the PROGRAM AE function....................................... 38
Additional information
Changing the lithium battery in the camera .............................. 39
Precautions ...................................................................................... 40
Troubleshooting.............................................................................. 42
Self-diagnosis display .................................................................... 44
Specifications................................................................................... 45
Warning messages................................................................... 46
Function guide ................................................................................ 47
Index ................................................................................................. 51
6-GB
Be sure to read before using your camera
Trial recording
Before you record one-time events, you may want to make a trial
recording to make sure that the camera is working correctly.
No compensation for contents of the recording
Contents of the recording cannot be compensated for if recording or
playback cannot be made due to a malfunction of the camera, floppy
disk, etc.
Precaution on copyright
Floppy disks, television programs, films, video tapes, and other
materials may be copyrighted. Unauthorized recording of such
materials may be contrary to the provisions of the copyright laws.
• IBM PC/AT is a registered trademark of International Business Machines
Corporation of the U.S.A.
• MS-DOS and Windows are registered trademarks licensed to Microsoft
Corporation, registered in the U.S.A. and other countries.
• Netscape Navigator is a trademark of Netscape Communications
Corporation.
• Macintosh is a trademark licensed to Apple Computer, Inc., registered in the
U.S.A. and other countries.
• All other product names mentioned herein may be the trademarks or
registered trademarks of their respective companies.
Furthermore, “TM” and “” are not mentioned in each case in this manual.
7-GB
This digital still camera uses a floppy disk as a medium for
recording images.
Use the following floppy disk type:
•Size: 3.5 inch
•Type: 2HD
•Capacity: 1.44 MB
•Format: MS-DOS format (512 bytes ×18 sectors)
When using 3.5 inch, 2HD floppy disk other than described above,
format it using the camera or personal computer.
Do not shake or strike the unit
Malfunctions, inability to record images as well as inability to use
floppy disks or image and memory data breakdown, damage or loss
may occur.
Do not get the unit wet
When taking pictures outdoors in the rain or under similar
conditions, be careful not to get the unit wet.
If moisture condensation occurs, refer to page 41 and follow
instructions on how to remove it before using.
Do not point the viewfinder toward the sun
Do not place the unit so as to point the viewfinder or the LCD screen
toward the sun. The inside of the viewfinder or the LCD screen may
be damaged. Be careful when placing the unit under sunlight or by a
window.
Back up recommendations
To avoid the potential risk of data loss always copy (back up) data to
disk.
Supplied accessories
Digital still camera (1) Battery charger (1)
Power cord (1 set) NP-F330 battery pack (1)
Shoulder strap (1) Lens cap (1)
Before using your camera
8-GB
Parts identification
See pages in ( ) for more details.
To insert the floppy disk
Insert the floppy disk until it clicks.
Before inserting, check that the
write protect tab set to the
recording position.
To remove the floppy disk
While sliding EJECT lock down, slide DISK EJECT in the direction of the
arrow.
DISK EJECT lever
Shutter button
(17, 18)
Self-timer lamp
The lamp keeps on
blinking until
recording starts after
the shutter button is
depressed.
Flash emitter (11)
Lens Tripod receptacle
Make sure that the length of
the tripod screw is less than
7/32 inch (6.5 mm).
Focus ring (36)
Slot for AC
power adaptor
cord
Photocell window
for flash
Do not block when
recording. Microphone
Do not touch when
recording.
EJECT lock
9-GB
OPEN (FLASH) switch
To pop up the flash and
use it, slide this switch in
the direction of the arrow.
Zoom lever
“T” side: for telephoto (sub-
ject appears
closer)
“W” side: for wide-angle
(subject appears
farther away)
Move the zoom lever to the
“W” side until the focus is
sharp.
You can shoot a subject that
is at least about 2 2/3 feet
(about 80 cm) away from the
lens surface in the telephoto
position, or about 1/2 inch
(about 1 cm) away in the
wide-angle position.
FOCUS AUTO/
MANUAL switch (36, 47)
STEADYSHOT
ON/OFF switch (36, 48)
PROGRAM AE –/+
button (38, 49) PROGRAM AE
button (38, 49)
∑(One-push
white balance)
button (37, 48)
BRIGHT +/–
button
Press to adjust the
brightness of the
LCD screen.
VOLUME +/–
button
Press to adjust the
volume of the
speaker.
WHITE BALANCE
button (37, 48)
Hook for strap
Lens cap (37)
10-GB
Control button
Upper side
Left
side
Press to
execute.
Lower side
Right
side
Function of the control button
You can execute the functions by
pressing the upper, lower, left or right
side of the control button. When an
item is selected in the menu, the color
of the item changes from blue to
yellow. To enter your selection, press
the center of the control button.
PLAY/STILL/MOVIE
switch (17, 18, 21)
Lithium battery
compartment (39)
Control button
Battery cover/
OPEN (BATT)
button (13)
DISK EJECT lever (8)
POWER switch
Slide down to turn
on/off the power.
LCD panel
Viewfinder
Speaker
Adjusting the LCD panel
DISPLAY button
Press to display or turn off the
indicators on the LCD screen.
The indicators do not go off in the
following modes:
Program AE, White balance, Manual
focus, Zoom, AE Lock, Self-timer,
Flash and Adjusting the exposure.
90°
180°
Viewfinder
adjustment lever
– side
(near) (far)
+ side
÷Parts identification
Otros manuales para Mavica MVC-FD91
3
Tabla de contenidos
Idiomas:
Otros manuales de Cámara digital de Sony
Sony
Sony DSC T500 - Cyber-shot Digital Camera Manual de usuario
Sony
Sony ILCE-7K Manual de usuario
Sony
Sony DSC-S930 Cyber-shot® Manual de usuario
Sony
Sony ILCE-5100 Manual de usuario
Sony
Sony DSC-W370/B Manual de usuario
Sony
Sony Cyber-shot DSC-S75 Manual de usuario
Sony
Sony DSC-W290/L Manual de usuario
Sony
Sony Cyber-shot DSC-S600 Instrucciones de funcionamiento
Sony
Sony DSLR-A700 Manual de usuario
Sony
Sony a350 Manual de usuario
Sony
Sony Cybershot,cyber-shot dsc-tx100v Manual de usuario
Sony
Sony Cyber-shot DSC-HX200 Manual de usuario
Sony
Sony DSC-W55/L Manual de usuario
Sony
Sony FD Mavica MVC-FD75 Manual de usuario
Sony
Sony DSLR-A100K - alpha; Digital Single Lens Reflex... Manual de usuario
Sony
Sony DSC-W230/B Manual de usuario
Sony
Sony DSC-P41 - Cyber-shot Digital Still Camera Manual de usuario
Sony
Sony Alpha 7 IV Guía del usuario
Sony
Sony Cyber-shot DSC-W370 Manual de usuario
Sony
Sony Cyber-shot DSC-RX0 Manual de usuario
