Sony Mavica MVC-CD1000 Instrucciones de funcionamiento

model name1[MVC-CD1000]

[3-062-474-11(1)]

masterpage:Right

filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\01COV-DirectC-

DUC\010cov.fm]

3-062-474-11(1)

DirectCD

™

Software Operating Instructions

MVC-CD1000

010cov.fm Page 1 Tuesday, May 23, 2000 4:27 PM

masterpage:Left

filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-

DirectCDUC\02war.fm]

model name1[MVC-CD1000]

[3-062-474-11(1)]

Notice for users

Corporation

software described herein, in whole or

in part, may not be reproduced,

translated or reduced to any machine

readable form without prior written

approval from Sony Corporation.

IN NO EVENT SHALL SONY

CORPORATION BE LIABLE FOR

ANY INCIDENTAL,

CONSEQUENTIAL OR SPECIAL

DAMAGES, WHETHER BASED ON

TORT, CONTRACT, OR

OTHERWISE, ARISING OUT OF OR

IN CONNECTION WITH THIS

MANUAL, THE SOFTWARE OR

OTHER INFORMATION

CONTAINED HEREIN OR THE USE

THEREOF.

Sony Corporation reserves the right to

make any modification to this manual

or the information contained herein at

any time without notice.

The software described herein may

also be governed by the terms of a

separate user license agreement.

Trademarks

•Adaptec is a registered trademark of

Adaptec, Inc.

•Easy CD Creator and DirectCD are

trademarks of Adaptec, Inc.

•Microsoft and Windows are

trademarksofMicrosoftCorporation,

registered in the U.S.A. and other

countries.

•Macintosh and Power PC are

trademarks of Apple Computer, Inc.

registered in the U.S.A. and other

countries.

•All other product names mentioned

herein may be the trademarks or

registered trademarks of their

respective companies. Furthermore,

“™” and “®” are not mentioned in

each case in this manual.

01cov.book Page 2 Tuesday, May 23, 2000 4:28 PM

masterpage:Right

filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-

DirectCDUC\01covTOC.fm]

model name1[MVC-CD1000]

[3-062-474-11(1)]

Table of contents

Notice for users ...............................2

Introduction .....................................4

Installing DirectCD .........................5

Using DirectCD ...............................8

Removing the disc .........................12

Modifying data in a disc ................13

01cov.book Page 3 Tuesday, May 23, 2000 4:28 PM

masterpage:Left

filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-

DirectCDUC\03pre.fm]

model name1[MVC-CD1000]

[3-062-474-11(1)]

Introduction

This manual describes how to install the application software, DirectCD supplied

with the MVC-CD1000, and how to use it. If explanations described in this manual

are different from the PDF file in the CD-ROM, follow explanations described in this

manual.

Note

You cannot install DirectCD into a Macintosh computer. To read the disc that has been

finalized, copy Adaptec UDF Volume Access included in the CD-ROM (SPVD-001) supplied

with the MVC-CD1000 to System folder of your personal computer and restart your personal

computer.

Once you install the USB driver into your personal computer (for details on

installation, refer tothe operating instructions of the MVC-CD1000), and connect the

MVC-CD1000 and your personal computer with the USB cable, you can do the

following operations:

•You can send images shot with the MVC-CD1000 to your personal computer and

play them back on your personal computer. (The finalization is not required.)

•You can write images that are captured by your personal computer onto a disc and

make the picture album.

•You can directly read and write images shot with the MVC-CD1000 in the CD-R/

CD-RW drive, without executing the finalization.

Recommended Windows environment for DirectCD

•MMX Pentium 166 MHz or greater (When using DirectCD with the MVC-

CD1000: MMX Pentium 200 MHz or greater)

•32 MB or more of RAM

•45 MB or more of free hard-disk space

•Monitor with 800×600-resolution and 256-color

•Microsoft Internet Explorer 4.01 or later

01cov.book Page 4 Tuesday, May 23, 2000 4:28 PM

masterpage:Right

filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-

DirectCDUC\03pre.fm]

model name1[MVC-CD1000]

[3-062-474-11(1)]

Installing DirectCD

•When using a CD-ROM drive

DirectCD is not required to only view images on the finalized disc in a CD-ROM

drive. If you read or write images on the disc which is not finalized, you have to

connect the MVC-CD1000 to your personal computer with the USB cable and

install DirectCD into your personal computer. For details on USB connection, refer

to the operating instructions of the MVC-CD1000.

•When using a CD-R or CD-RW drive

Select one of the following ways according to the configuration of your personal

computer.

— When a writing software has not been installed into your personal computer, you

can install DirectCD into your personal computer.

— When DirectCD other than this version has been installed into your personal

computer, you can install DirectCD included in the supplied CD-ROM. You

cannot use any other versions of DirectCD with the MVC-CD1000. If you

install the supplied DirectCD, DirectCD that has been installed in your personal

computer will be upgraded to the new version.

— When a writing software other than DirectCD has been installed into your

personal computer, uninstall the writing software from your personal computer,

then install DirectCD. If you want to use the writing software, do not install

DirectCD. You cannot use the MVC-CD1000 with DirectCD.

Note

You may not be able to use DirectCD depending on your CD-R drive or CD-RW drive.

01cov.book Page 5 Tuesday, May 23, 2000 4:28 PM

masterpage:Left

filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-

DirectCDUC\03pre.fm]

model name1[MVC-CD1000]

[3-062-474-11(1)]

For Windows 98 users

Follow these steps below to install DirectCD. English version illustrations are used in

this manual.

1Turn on your personal computer and insert the supplied CD-ROM

(SPVD-001) into the CD-ROM drive of your personal computer.

The following window appears on the screen.

If the window above is not displayed, start up “SETUP. EXE” in the CD-ROM.

2Select the language.

3Click [DirectCD].

The “Welcome” window appears on the screen.

4Click [Next].

5Read the text on the window carefully, and if you accept it, click

[Yes].

01cov.book Page 6 Tuesday, May 23, 2000 4:28 PM

masterpage:Right

filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-

DirectCDUC\03pre.fm]

model name1[MVC-CD1000]

[3-062-474-11(1)]

DirectCD will be available after you restart your personal computer. Check the option

[Yes ...,] then click [Finish].

Notes on Easy CD Creator included in the supplied CD-ROM

•You cannot use Easy CD Creator with the MVC-CD1000 connected to your personal computer

with the USB cable.

•Be sure to install Easy CD Creator of the same version as included in the supplied CD-ROM,

with DirectCD. If one of other versions of Easy CD Creator is installed, DirectCD that is

installed from the supplied CD-ROM may not function.

6Check the directory in which DirectCD will be installed.

When you install DirectCD into another directory other than the default one,

click [Browse...], and select the directory.

7Click [Next].

The setup of the program starts. When the installation is complete, the screen

returns to the window displayed in step 1.

8Click [Exit].

The “Setup Complete” window appears on the screen.

01cov.book Page 7 Tuesday, May 23, 2000 4:28 PM

masterpage:Left

filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-

DirectCDUC\03pre.fm]

model name1[MVC-CD1000]

[3-062-474-11(1)]

Using DirectCD

You have to install the USB driver into your personal computer to connect the MVC-

CD1000 to your personal computer with the USB cable. For details on the

installation of the USB driver and on the directory, refer to the operating instructions

of the MVC-CD1000.

When you use a new disc or record a new image onto the disc that was finalized, you

have to format the disc (page 9).

Note

When you write new data onto the disc, before removing

the disc from the MVC-CD1000, be sure to follow the

procedure for removing the disc (page 12). If you remove

the disc or disconnect the USB cable, without following

the procedure, data on the disc may be broken.

Starting DirectCD

1After starting up your computer, insert a disc into the MVC-

CD1000, and connect to your personal computer with the USB

cable.

2Turn on the MVC-CD1000 and your personal computer.

“DirectCD Disc Ready” appears on the screen.

If this screen does not appear, double-click the CD icon on the Windows

taskbar, in the lower corner of your screen.

to the USB connector

Personal computer USB cable

to the DIGITAL I/O jack

Push in until the

plug clicks into

place

01cov.book Page 8 Tuesday, May 23, 2000 4:28 PM

masterpage:Right

filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-

DirectCDUC\03pre.fm]

model name1[MVC-CD1000]

[3-062-474-11(1)]

You have to format (initialize) a disc before recording images onto the disc.

If you format a new Sony Mavica disc, you can store about 156 MB data on it.

Formatting a disc

1Start DirectCD as described in the previous section.

After a few seconds, a screen should appear asking you to “Please select the

type of disc you wish to create.”

2Select the first option, [Click here to create a data disc that will be

accessible through a drive letter].

The Adaptec DirectCD Wizard starts.

Note

Do not select the other options. If you do, you cannot use the disc with the MVC-CD1000.

3Read the text in the “Welcome” window and click [Next].

The [Drive Information] window appears.

4Read the text in the “Recorder Information” window and click

[Next].

The “Format Disc” window appears.

01cov.book Page 9 Tuesday, May 23, 2000 4:28 PM

masterpage:Left

filename[D:\Mavica1000\3062474111\3062474111DirectCDUC\02GB-

DirectCDUC\03pre.fm]

model name1[MVC-CD1000]

[3-062-474-11(1)]

5In the “Format Disc” window, click [Next] to continue.

The “Name Your Disc” window appears.

6Type a disc name of up to 11 characters.

7Click [Finish].

Disc formatting begins. The “DirectCD Disc Ready” window appears when

the formatting is complete.

8Click [OK].

01cov.book Page 10 Tuesday, May 23, 2000 4:28 PM

Otros manuales para Mavica MVC-CD1000

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Sony

Sony

Sony Cyber-shot DSC-S2100 Manual de usuario

Sony

Sony NEX-F3 Manual de usuario

Sony

Sony DSLR-A700H User’s Guide Manual de usuario

Sony

Sony Cyber-shot DSC-F77A Manual de usuario

Sony

Sony Cyber-shot DSC-F55V Manual de usuario

Sony

Sony DSC-G1 - Cyber-shot Digital Camera Manual de usuario

Sony

Sony Cyber-shot DSC-W510 Manual de usuario

Sony

Sony SLT-A57K Manual de usuario

Sony

Sony Cyber-shot DSC-HX30 Manual de usuario

Sony

Sony Cyber-shot DSC-W730 Manual de usuario

Sony

Sony CD Mavica MVC-CD500 Manual de usuario

Sony

Sony Cyber-shot DSC-H70 Manual de instrucciones de instalación

Sony

Sony Alpha 6600 Guía del usuario

Sony

Sony DSC-H2 User’s Guide Manual de usuario

Sony

Sony ILCE-9M3 Guía de referencia

Sony

Sony DSC-V1 Operating Instructions (English) Manual de usuario

Sony

Sony Mavica FD87 Guía del usuario

Sony

Sony Cyber-shot DSC-TX20 Manual de usuario

Sony

Sony Cyber-shot 3-294-896-12(1) Manual de usuario

Sony

Sony ILCE-5100 Guía de referencia

Sony

Sony DSC-H5 User’s Guide Manual de usuario

Sony

Sony MVC-CD350 - Digital Still Camera Mavica Cd... Manual de usuario

Sony

Sony Cyber-shot DSC-RX10 Guía de referencia

Sony

Sony DSC-HX400 Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Canon

Canon EOS ELAN7 Manual de usuario

Nikon

Nikon Coolpix 100 Manual de usuario

Samsung

Samsung SCC-C4253 Manual de usuario

JVC

JVC GT-HM890 Manual de usuario
