Sony Alpha 7S II Guía del usuario

Page 1 of 4

Navigation

- Navigate up and down by scrolling or pressing the control wheel or using the front dial.

- Navigate left and right by pressing the sides of the control wheel or using the rear dial.

SONY

7S II STARTUP GUIDE

Reset All

Format Memory Card

- Press the MENU button, located to the left of the viewﬁ nder.

- Go to the Setup menu ( ) > page 5 > Format > Enter.

Reset Camera Settings

- Press the MENU button.

- Go to the Setup menu ( ) > page 6 > Reset > Camera Settings Reset.

- Go to the Setup menu ( ) > page 5 > Format > Enter.

CONTROL WHEEL

REAR DIAL

FRONT DIAL

RESOLUTION

File Format

- Press the MENU button.

- Go to the Camera menu ( ) > page 2 > File Format.

- The ﬁ le formats available are XAVC S 4K, XAVC S HD, AVCHD, and MP4. If shooting in 4K, choose

the XAVC S 4K option for best results.

Record Setting

- Press the MENU button.

- Go to the Camera menu ( ) > page 2 > Record Setting.

- Here, you can choose your framerate and bitrate.

- Go to the Camera menu ( ) > page 2 > Record Setting.

- Go to the Setup menu ( ) > page 6 > Reset > Camera Settings Reset.

- Go to the Camera menu ( ) > page 2 > File Format.

Page 2 of 4

SONY

7s II STARTUP GUIDE

White Balance

Set Custom White Balance

- Press the MENU button. Navigate to Camera > page 5 > White

Balance > Custom Setup.

- Capture your custom white within the ring, and select your

EXPOSURE

Make sure you are in Manual movie mode. Press the “Fn” button

above the control wheel. Navigate to Movie/HFR > Manual

Exposure.

Gain (ISO)

There are several ways to adjust your ISO:

1. Press the MENU button. Navigate to the Camera menu >

page 4 > ISO.

2. Press the Fn button above the control wheel, and navigate

to the ISO option.

3. Press the right side of the control wheel where ISO is

indicated.

Iris

By using your front dial, the f-stop values will appear at the

bottom of the screen.

High Frame Rate (HFR)

To set your HFR preferences, you can either:

1. Press the MENU button. Navigate to the Camera menu >

page 2 > HFR Settings.

2. Press the Fn button. Go to the Movie/HFR Settings > HFR

Manual Exposure. Adjust aperture/shutter speed manually

using front and rear dials (front - aperture, rear - shutter).

Page 3 of 4

SONY

7s II STARTUP GUIDE

Viewfinder guides

Zebra (Exposure)

- Press the MENU button.

- Navigate to the Setup menu > page 1 > Zebra, and select

your level.

Focus Peaking

- Press the MENU button.

- Navigate to the Setup menu > page 2 > Peaking Level, and

select your level.

- You can also adjust your color by adjusting the Peaking Color

on page 2 as well.

Audio

The left side of the camera body has a headphone jack as well

as a microphone jack.

To display your audio levels in video mode:

- Press the MENU button.

- Navigate to the Setup menu > page 2 > Audio Level Display

> On.

- When you are in shooting mode and you press the up button

on the control wheel (DISP), your audio levels (CH1 and CH2)

will appear on the screen.

MEDIA

Playback

To view your media, press the playback button ( ) located

under the control wheel.

Deleting

- To delete clips/images individually, press the trash bin button

located under the control wheel while in playback mode.

- To delete multiple images, go into your MENU. Navigate to

the Playback tab > Delete > Multiple Img.

Page 4 of 4

SONY

7s II STARTUP GUIDE

METABONES ADAPTER

Your kit includes a Metabones adapter that allows you to use

Canon EF lenses with the Sony A7S II.

How to Mount Your Lens

1. Dismount the base lens that comes with the kit, and set it

aside.

2. Before mounting your Canon lens, make sure there is a

battery in your camera.

3. Turn the camera body ON. It is important to do this before

mounting anything.

4. Attach the Metabones adapter to the Canon lens (align the

dots).

5. Locate this button on the side of the Metabones adapter.

6. Hold the button down as you mount it to your Sony camera

body (align the dots).

The camera should display an F-stop value on the bottom of

the screen if properly mounted. If improperly mounted, you will

see “F--.”

Troubleshooting

If the camera is not reading the new lens, and you cannot adjust

your iris (use the front dial), try dismounting and remounting

the Canon lens from the Metabones adapter (which should

stay attached to the camera body).
