SonicWALL TZ 190 Manual de usuario

COMPREHENSIVE INTERNET SECURITY

™

SonicWALL Internet Security Appliances

SonicWALL TZ 190 Wireless

Getting Started Guide

SonicWALL TZ 190 Wireless Getting Started Guide Page 1

SonicWALL TZ 190 Wireless

Getting Started Guide

Thank you for your purchase of the SonicWALL TZ 190 Wireless, the ultimate

security platform for home and small office deployments.

With integrated support for SonicWALL's Gateway Anti-Virus, the SonicWALL

TZ 190 Wireless delivers powerful, yet easy-to-use protection against malicious

users and viruses. The SonicWALL TZ 190 Wireless security appliance also

supports SonicWALL's Content Filtering Service to provide enhanced

productivity and network utilization.

This Getting Started Guide contains installation procedures and configuration

guidelines for deploying a SonicWALL TZ 190 Wireless on your network. For

detailed configuration information, refer to the SonicOS Enhanced

Administrator’s Guide on the SonicWALL Resource CD or on the Web at:

<http://www.sonicwall.com/us/support.html>.

Page 2 READ BEFORE CONTINUING - Important Information Regarding WWAN Service Providers

READ BEFORE CONTINUING -

Important Information

Regarding WWAN Service Providers

It is important to understand that not all WWAN service providers operate in the

same way or support all the same feature sets. Because of this, there exists

some inherent “service provider-specific” variances in service area and more

importantly, in supported features. Along with feature limitations may also come

certain restrictions such as bandwidth constraints and networking limitations.

Before purchasing a WWAN PC card and service plan, check to make sure that

the WWAN service provider offers support for the features you need.

Before committing to a service contract with a WWAN service provider, it may

be helpful to ask these questions:

• What types of traffic are allowed over the WWAN network?

• Do they offer “static” or “dynamic” IP addressing?

• Are there any inbound connection limitations?

• Are single or multiple hosts allowed?

• Do they support VPN traffic?

• What are the data transfer limits (inbound and outbound)?

• What are common data transfer speeds and how much of the

coverage area supports 3G or faster technology?

SonicWALL TZ 190 Wireless Getting Started Guide Page 3

Document Contents

This document contains the following sections:

Completing Pre-Configuration Tasks - page 5

Preparing Your WWAN PC Card - page 11

Registering Your SonicWALL - page 29

Connecting for Initial Setup - page 31

Running the Setup Wizard - page 37

Verifying Your WWAN Connection - page 43

Connecting to Your Network - page 47

Appendix

Appendix A: Configuring DHCP IP Addressing - page 51

Appendix B: Troubleshooting Internet Connectivity - page 52

Appendix C: Safety Instructions and Regulatory Information - page 53

Page 4 READ BEFORE CONTINUING - Important Information Regarding WWAN Service Providers

SonicWALL TZ 190 Wireless Getting Started Guide Page 5

Completing Pre-Configuration Tasks

In this Section:

This section provides pre-configuration information. It is necessary to review

this section before setting up your SonicWALL TZ 190 Wireless.

•System Requirements , on page 6

•Check Package Contents , on page 7

•Obtain Configuration Information , on page 8

•Obtain Internet Service Provider (ISP) Information , on page 9

•Obtain WWAN Service Provider Information , on page 10

Page 6 System Requirements

System Requirements

Before you begin the setup process, check to ensure that you have a computer

that meets the following requirements. This computer is used to manage your

SonicWALL TZ 190 Wireless during the setup process.

• Windows Vista, Windows XP, Windows 2000 or Windows NT

• 40MB of disk space available

• One available 10/100 Ethernet (LAN) port

• A Web browser supporting Java and HTTP uploads. Internet Explorer 6.0

or higher, Netscape Navigator 4.7 or higher, Mozilla 1.7 or higher are

recommended

• LAN interface set to obtain an IP address automatically (DHCP addressing

enabled)

Note: In order to connect to the SonicWALL TZ 190 Wireless, your

computer must be set to obtain an IP address automatically

using DHCP. For more information on configuring DHCP on

your computer, turn to Appendix A: Configuring DHCP IP

Addressing , on page 51.

SonicWALL TZ 190 Wireless Getting Started Guide Page 7

Check Package Contents

SonicWALL TZ 190 Wireless

Standard power adapter

DB9 -> RJ45 (CLI) Cable

Wireless antenna pair

Ethernet cable

SonicWALL Resource CD

Getting Started Guide

Release Notes document

Any Items Missing?

If any items are missing from your

package, please contact SonicWALL

support.

A listing of the most current support

options is available online at:

<http://www.sonicwall.com/us/support.html>

*The included power cord is intended for use

in North America only. For European Union

(EU) customers, a power cord is not

included.

SonicOS Release Notes

Contents

SonicWALL

Getting Started Guide

COMPREHENSIVE INTERNET SECURITY

SonicWALL

Resource CD

link/act

10/100

wan opt

signal

link/act

wwan

WiFiSec

on/act

wlan

TZ 190

wireless

Page 8 Obtain Configuration Information

Obtain Configuration Information

Please record and keep for future reference the following setup information:

Registration Information

Networking Information

Administrator Information

Serial Number:

Record the serial number found on the bottom panel of

your SonicWALL appliance.

Authentication Code:

Record the authentication code found on the bottom panel

of your SonicWALL appliance.

LAN IP Address:

. . .

Select a static IP address for your SonicWALL appliance

that is within the range of your local subnet. If you are

unsure, you can use the default IP address

(192.168.168.168).

Subnet Mask:

. . .

Record the subnet mask for the local subnet where you are

installing your SonicWALL appliance.

Ethernet WAN IP Address:

. . .

Select a static IP address for your Ethernet WAN. This

setting only applies if you are already using an ISP that

assigns a static IP address.

Admin Name:

Select an administrator account name.

(default is admin)

Admin Password:

Select an administrator password.

(default is password)

SonicWALL TZ 190 Wireless Getting Started Guide Page 9

Obtain Internet Service Provider (ISP) Information

Record the following information about your current Internet service:

If you connect via You likely use Please record

Cable modem,

DSL with a router DHCP No Internet connection information is usually

required, although some service providers

require a host name.

Host Name:

Home DSL PPPoE User Name:

Password:

Note: Your ISP may require your user name in

the format: name@ISP.com

T1/E1,

Static broadband,

Cable or DSL with

a static IP

Static IP IP Address: . . .

Subnet Mask: . . .

Default Gateway

(Router IP Address): . . .

Primary DNS: . . .

Secondary DNS

(optional): . . .

Dial-in to a server PPTP Server Address:

User Name:

Password:
