SOLTEK SL-65EB Manual de usuario

SL-65EB V1.0 USER MANUAL

USER NOTICE

Product Model : SL-65EB

Manual Revision : V1.0

Release Date : O TOBER 2000

His Users Guide & Technical Reference is for assisting system

manufacturers and end-users in setting up and installing the

motherboard.

Every effort has been made to ensure that the information in this

manual is accurate. Solte Computer Inc. is not responsible for print-

ing or clerical errors. Information in this document is subject to

change without notice and does not represent a commitment on the

part of Solte Computer Inc.

No part of this manual may be reproduced, transmitted, translated

into any language in any form or by any means, electronic or

mechanical, including photocopying and recording, for any purpose

without the express written permission of Solte Computer Inc.

Companies and products mentioned in this manual are for identifi-

cation purpose only. Product names appearing in this manual may

or may not be registered trademar s or copyrights of their respec-

tive companies.

Solte computer inc. Provides this manual “As is “ without warranty

of any ind, either express or implied, including but not limited to

the implied warranties or conditions of merchantability or fitness for

a particular purpose. In no event shall Solte computer inc. Be li-

able for any loss or profits, loss of business, loss of use or data,

interruption of business, or for indirect, special, incidental, or con-

sequential damages of any ind, even if Solte computer inc. Has

been advised of the possibility of such damages arising from any

defect or error in this manual or product.

• Intel, Celeron, Pentium II, Pentium III are trademar s of Intel Corporation.

• Intel 82815 Graphic Memory Controller Hub(GMCH), 82801 I/O Controller Hub(ICH) are trade-

mar s of Intel Corporation.

• VIA Cyrix III is trademar of VIA Corporation.

• Norton AntiVirus, Norton Ghost are trademar s of Symantec Corporation.

SOLTEK AROUND THE WORLD

SOLTEK COMPUTER INC.

Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chin, Taipei-

Hsien, Taiwan, R.O.C.

Telephone : 886-2-2642-9060

Fax : 886-2-2642-9065

E-mail : sashia@solte .com.tw

Web site : http://www.solte .com.tw

SOLTEK KOREA INC.

Address : 1002, Chungjin Bldg. 53-5 Wonhyo-Ro, 3-Ka,

Yongsan-Ku Seoul 140-113, Korea

Telephone : 82-2-32717400

Fax : 82-2-32717405

E-mail : solte @nuri.net

MOKA HOLDING B.V.

Address : De Run 4428 5503 LR Veldhoven, the Netherlands

Telephone : 31-402-556150

Fax : 31-402-546006

E-mail : info@mo a.nl

SOUL TECHNOLOGY EUROPE B.V.

Address : Sydneystraat 52-54 3047 BP Rotterdam, the Nether-

lands

Telephone : 31-10-2457492

Fax : 31-10-2457493

E-mail : [email protected]

Web site : http://www.soultech-europe.com

65EB

C O N T E N T

CHAPTER 1

INTRODUCTION.................................................................. 6

1-1 ITEM LIST CHECK UP .............................................................................. 6

1-2 CHIPSET ................................................................................................... 6

1-3 PROCESSOR ............................................................................................ 6

1-4 ADVANCED HIGH-PERFORMANCE DRAM CONTROLLER ................... 6

1-5 FULL FEATURED ACCELERATED GRAPHICS PORT ............................ 6

1-6 MULTI-I/O FUNCTION ............................................................................... 7

1-7 EXTENSION SLOTS ................................................................................. 7

1-8 BIOS .......................................................................................................... 7

1-9 POWER MANAGEMENT........................................................................... 7

1-10 FORM FACTOR ....................................................................................... 7

1-11 MOTHERBOARD LAYOUT --- 65EB ....................................................... 8

1-12 CHIPSET SYSTEM BLOCK DIAGRAM................................................... 9

CHAPTER 2

HARDWARE SETUP ......................................................... 11

2-1 CPU INSTALLATION ............................................................................... 11

2-2 MEMORY INSTALLATION ....................................................................... 13

2-3 Hdd / fdd installation ................................................................................ 14

2-4 CPU TYPE CONFIGURATION ................................................................ 15

2-5 SYSTEM MEMORY CONFIGURATION .................................................. 16

2-6 JUMPER DEFINITION ............................................................................. 16

2-6.1 ONBOARD (CFAN1/SFAN1/PFAN1) .................................................... 16

2-6.2 KEYBOARD POWER ON (JP2) ........................................................... 17

2-6.3 USB PORT SELECT (JP6/JP7) ............................................................ 17

2-6.4 POWER LOST RESUME (JP12) .......................................................... 17

2-6.5 VGA CARD (JVGA1) ............................................................................ 18

2-6.6 CLEAR CMOS DATA (JBAT1) .............................................................. 18

2-6.7 WAKE ON LAN (WOL) FUNCTION (JWOL1) ...................................... 18

2-7 CONNECTORS ....................................................................................... 19

2-7.1 J1 SWITCH SIGNAL SUMMARY ......................................................... 20

65EB

2-7.2 J2 SWITCH SIGNAL SUMMARY ......................................................... 22

2-7.3 ATX POWER SUPPLY CONNECTOR .................................................. 24

2-7.4 PS/2 MOUSE AND PS/2 KEYBOARD .................................................. 24

2-7.5 IRQ DESCRIPTION .............................................................................. 25

CHAPTER 3

SOFTWARE SETUP .......................................................... 26

3-1 ABOUT THE SUPPORT CD ....................................................... 26

3-2 INTEL CHIPSET DRIVER INSTALLATION (FOR ....................... 26

WINDOWS 95/98/2000) .............................................................. 26

CHAPTER 4

BIOS SETUP ..................................................................... 28

4-1 INTRODUCE THE BIOS .......................................................................... 28

4-2 WHAT IS BIOS SETUP............................................................................ 28

4-3 HOW TO RUN BIOS SETUP ................................................................... 28

4-4 WHAT IS CMOS ...................................................................................... 29

4-5 WHAT IS POST ....................................................................................... 29

4-6 BIOS UPGRADE...................................................................................... 29

4-6.1 BEFORE UPGRADE BIOS ................................................................... 29

4-6.2 UPGRADE PROCESS ......................................................................... 30

4-7 CMOS SETUP UTILITY ........................................................................... 33

4-8 STANDARD CMOS FEATURES .............................................................. 34

4-9 ADVANCED BIOS FEATURES ................................................................ 37

4-10 ADVANCED CHIPSET FEATURES ....................................................... 41

4-11 INTEGRATED PERIPHERALS .............................................................. 45

4-12 POWER MANAGEMENT SETUP.......................................................... 50

4-13 PNP / PCI CONFIGURATION ................................................................ 55

4-14 FREQUENCY CONTROL ...................................................................... 58

4-15 LOAD OPTIMIZED DEFAULTS ............................................................. 58

4-16 SET SUPERVISOR / USER PASSWORD ............................................. 60

4-17 SAVE & EXIT SETUP ............................................................................ 61

4-18 EXIT WITHOUT SAVING ....................................................................... 61

65EB

CHAPTER 1

INTRODUCTION

1-1 ITEM LIST CHECK UP

• Motherboard

• Support CD

• User’s Manual

• Bundle Bonus Pac CD

• Bundle Bonus Pac Manual

• ATA33 IDE Cable

1-2 CHIPSET

• North Bridge - Intel 82443BX.

• South Bridge - 82371EB PCI-To-ISA.

• Supper I/O - Winbond W83977.

1-3 PROCESSOR

• Supports Intel® FC-PGA Pentium IIITM up to 1GHz (100MHz Front Side

Bus on y).

• Supports Intel® FC-PGA 370 Celeron & PGA 370 Celeron up to 700MHz.

• Supports VIA Cyrix III up to 600MHz.

• Supports CPU voltage Auto - Detect circuit.

• Supports CPU using front side Bus 66MHz and 100MHz only.

1-4 ADVANCED HIGH-PERFORMANCE DRAM

CONTROLLER

• Supports SDRAM memory up to 3 DIMMS.

• 64-bit data width and 3.3V DRAM interface.

• Supports up to 768MB memory space.

• Different DRAM types may be used in mixed combinations.

1-5 FULL FEATURED ACCELERATED GRAPHICS PORT

• Supports 66MHz 1x and 2x modes.

• AGP Specification Rev 1.0 compliant.

65EB

1-6 MULTI-I/O FUNCTION

• Two UltraDMA-33 Master Mode PCI EIDE ports.

• Two UARTs for Complete Serial Ports.

• One dedicated IR connector:

Third serial port dedicated to IR function either through the two complete serial ports or the

third dedicated port Infrared-IrDA (SIR) and ASK (Amplitude Shift Keyed) IR.

• Multi-mode parallel connector:

Standard mode, ECP and EPP support.

• Floppy Dis connector:

One FDD with drive swap support.

• Universal Serial Bus connector:

USB V1.0 compatible.

Provides 2 build-in USB ports.

• PS/2 Keyboard connector.

• PS/2 Mouse connector.

1-7 EXTENSION SLOTS

• Five PCI bus Mater slots.

• Three DIMM slots.

• One ISA slot.

• One AGP 2X mode slot.

1-8 BIOS

• Award BIOS V6.0.

• Supports Plug & Play V1.0.

• Flash Memory for easy upgrade.

• Year 2000 compliant.

1-9 POWER MANAGEMENT

• ACPI 1.0 compliant (Advanced Configuration and Power Interface).

• APM V1.2 compliant (Legacy power management).

• System event monitoring with two event classes.

• Supports PS/2 Keyboard & Mouse power on.

• Supports Wa e On LAN (WOL) & Wa e On Modem.

• Supports real time cloc (RTC) with date alarm, month alarm, and century field.

1-10 FORM FACTOR

• ATX from factor, 4 layers PCB.

• Motherboard size 18.0cm x 30.5cm.

65EB

NOTE: FOR 100 / 133MHz CPU ENVIRONMENT, THE SDRAM MUST COMPLY WITH PC-100 / PC-

133 SPEC.

1-11 MOTHERBOARD LAYOUT --- 65EB

• DEFAULT SETTING: Celeron 300/66MHz.

JP2

1 3

JVGA1

JP6

JP7

1 3

JP12

1 3

JBAT1

CFAN1

SFAN1

PFAN1

SPK RST PWR/LED SUSLED

HD/LED IR PWR SMI

JWOL1

AGP

PCI 1

PCI 2

PCI 3

PCI 4

PCI 5

FDC

DIMM1

DIMM2

DIMM3

IDE2

IDE1

SOCKET 370

ATX POWER

ISA

FLASH BIOS

Battery

C ock

Generator

I/O

Contro er

82443BX

Host

Bridge

82371EB

(PIIX4E)

(PCI-to-ISA

Bridge)

USB0

USB1 PS/2

MOUSE

PS/2

K/B

LPT1

COM2 COM1

upper

lower

upper

lower

SW1

ONDIP

8 7 6 5 4 3 2 1

PC100/PC133 SDRAM

65EB

1-12 CHIPSET SYSTEM BLOCK DIAGRAM

82443BX

Host

Bridge

82371EB

(PIIX4E)

(PCI-to-ISA

Bridge)

ISA1

Keyboard

& Mouse

Main

Memory

(DRAM)

AGP S ot or

3D Graphics

Contro er

BIOS

ROM

IDE x 2 Ports

(U tra DMA/33)

USBx2

Super O

Seria Port x 2

Infrared Port x 1

Para e Port x 1

FDD x1

Socket 370

CPU

PCI3

PCI5

PCI4

PCI1

PCI2

Figure 1-11. 82443BX System B ock Diagram Using the

82371EB South Bridge

AGP 2X S ot

65EB

ATTENTION !!!

1. P ease refer to your processor insta ation or other

documentation attached with your CPU for detai ed

insta ing instruction.

2. Insta ing a heat sink and coo ing fan is necessary for

proper heat dissipation from your CPU. Uncorrected

insta ation may resu t in overheating and damage of

your CPU.

3. Before changing the setting of CPU Vcore from BIOS

program, user SHOULD make sure of correct specifi-

cation both of CPU CLOCK and RATIO. Uncorrected

setting may cause damage to your CPU.

Tabla de contenidos

Otros manuales de Placa madre de SOLTEK

SOLTEK

SOLTEK SL-855GEI-FDGR Manual de usuario

SOLTEK

SOLTEK B7A-F Manual de usuario

SOLTEK

SOLTEK SL-56D1 Manual de usuario

SOLTEK

SOLTEK SL-65ME Manual de usuario

SOLTEK

SOLTEK SL-75DRV3/75DRV3+ Manual de usuario

SOLTEK

SOLTEK 85DRV5 Manual de usuario

SOLTEK

SOLTEK 85LIR-C Manual de usuario

SOLTEK

SOLTEK SL-65D Manual de usuario

SOLTEK

SOLTEK SL-67B-W Manual de usuario

SOLTEK

SOLTEK 85DR2-DC Manual de usuario

SOLTEK

SOLTEK SL-85DRS Manual de usuario

SOLTEK

SOLTEK SL-65ME Manual de usuario

SOLTEK

SOLTEK SL-75LIV Manual de usuario

SOLTEK

SOLTEK SL-845GLI Manual de usuario

SOLTEK

SOLTEK SL-65ME-T Manual de usuario

SOLTEK

SOLTEK SL-85LIR Manual de usuario

SOLTEK

SOLTEK SL-B5A-FG Manual de usuario

SOLTEK

SOLTEK SL-54A2 Manual de usuario

SOLTEK

SOLTEK SL-845GVI Manual de usuario

SOLTEK

SOLTEK SL-85MR2 Manual de usuario

SOLTEK

SOLTEK SL-65DVB Manual de usuario

SOLTEK

SOLTEK 86SP2 Manual de usuario

SOLTEK

SOLTEK SL-65FVB Manual de usuario

SOLTEK

SOLTEK SL-75KIV Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
