4
85ERV2 / 85ERV2-L
Contents
Chapter 1 Specification ............................................. 9
1-1 85ERV2 / 85ERV2-L Components and Options............... 10
1-2 Mainboard Specifications ..................................................... 11
1-2.1 CPU Socket ................................................................................... 11
1-2.2 System Chipsets ........................................................................... 11
1-2.3 Memory ......................................................................................... 11
1-2.4 AMI BIOS ..................................................................................... 11
1-2.5 Accelerated Graphics Port (AGP) Interface........................... 11
1-2.6 Advanced System Power Management:................................... 12
1-2.7 Multi-I/O Functions :.................................................................. 12
1-2.8 Expansion Slots ............................................................................ 12
1-2.9 AC’97 Audio Codec on board .................................................... 13
1-2.10 LAN on board (85ERV2-L only) ............................................. 13
1-2.11 Hardware Monitor on board ................................................... 13
1-2.12 6-channel Sound Output Support (optional) ........................ 13
1-2.13 Form Factor................................................................................ 13
1-3 Mainboard Specification Table ........................................... 14
1-4 Chipset System Block iagram........................................... 15
Chapter 2 Hardware Setup..................................... 16
2-1 Pentium 4 CPU and Installation ......................................... 17
2-1.1 To Identify a Pentium 4 CPU..................................................... 17
2-1.2 CPU Installation with Socket 478B .......................................... 18
2-2 Pentium 4 CPU Fan Installation ......................................... 19
2-3 Memory Installation with Warning LE .......................... 20
2-3.1 To Install R RAM Module ................................................. 20
2-3.2 To Remove a IMM .................................................................... 20
5
Contents
2-4 AGP 4X/8X Slot Installation ................................................ 21
2-5 I E Connector Installation ................................................. 22
2-6 Floppy rive Connector ( F C ) Installation ................. 23
2-7 ATX V 2.03 Power Supply Installation .............................. 24
2-8 Jumper Settings ..................................................................... 25
2-8.1 Jp1: CPU Clock/Overclock Select ............................................ 26
2-8.2 JBAT1: Clear CMOS .................................................................. 27
2-8.3 Jp2: Flash ROM Write Protection ........................................... 28
2-9 Other Connectors Configuration........................................ 29
2-9.1 On-board FAN Connectors ........................................................ 29
2-9.2 Connector WOL1: Wake On LAN............................................ 30
2-9.3 C -ROM Audio Connector (C 1) ........................................... 30
2-9.4 Audio 1: 6-channel Sound Output Connector (optional) ..... 31
2-9.5 Chassis Panel Connectors .......................................................... 31
2-9.6 RJ45: LAN Connector ( 85ERV2-L only) ............................... 32
2-9.7 PS/2 Mouse And PS/2 Keyboard ............................................... 32
2-9.8 Thermal Sensor Connectors RT1 and RT2 ............................. 33
2-9.9 Complex Pin-header.................................................................... 34
2-9.10 USB Ports and USB Pin Headers............................................ 36
2-10 IRQ escription................................................................... 37
Chapter 3 Software Setup ....................................... 38
3-1 Open Up Support C : .......................................................... 39
3-2 Proceed to VIA 4-IN-1 rivers Installation ...................... 40
3-3 AC’97 Audio river Installation......................................... 42
3-3.1 Verify 6-channel Audio ............................................................... 42
3-3.2 Verify 6-channel Audio ............................................................... 43
3-4 Install USB 2.0 river for Win98 / Me / 2000 / XP.......... 46
3-5 Install Hardware Monitor Utility ....................................... 48
6
85ERV2 / 85ERV2-L
3-5.1 Installation ................................................................................... 48
3-5.2 Verification .................................................................................. 49
3-6 Install VIA LAN rivers (for 85ERV2-L only) ............... 50
3-6-1. VIA6183 LAN driver on Windows 9X .................................... 50
3-6-2. VIA6183 LAN driver on Windows NT4.0 .............................. 52
3-6-3. VIA6183 LAN driver on Win ME / 2000 / XP ....................... 53
Chapter 4 AMI BIOS Setup.................................... 55
4-1 About BIOS Setup ................................................................. 56
4-2 To Run BIOS Setup ............................................................... 56
4-3 About CMOS .......................................................................... 56
4-4 The POST ( Power On Self Test ) ....................................... 56
4-5 To Update BIOS ..................................................................... 57
4-6 BIOS SETUP --- CMOS Setup Utility................................ 59
4-6.1 CMOS Setup Utility .................................................................... 59
4-6.2 Standard CMOS Setup ............................................................... 60
4-6.3 Advanced BIOS Features ........................................................... 63
4-6.4 Advanced Chipset Features ....................................................... 66
4-6.5 Power Management Features .................................................... 69
4-6.6 PNP / PCI Configurations .......................................................... 72
4-6.7 Integrated Peripherals................................................................ 74
4-6.8 Hardware Monitor Status .......................................................... 77
4-6.9 Frequency/Voltage Control ....................................................... 79
4-6.10 Set Supervisor Password .......................................................... 81
4-6.11 Load Optimized efaults ........................................................ 83
4-6.12 Save & Exit Setup...................................................................... 83
4-6.13 Exit Without Saving .................................................................. 83
APPEN ICES.......................................................... 85
Appendix-1 Identify Mainboard Model Number ................... 86
Appendix-2 Technical Terms ...................................................... 87
8
85ERV2 / 85ERV2-L
Mainboard
Support CD
Bundled Bonus Pack CD
Bundled Bonus Pack Manual
Thermal Sensor Cable (Optional)
ATA66/100/133 IDE Cable
FDD Cable
User’s Manual
Multi-lingual Quick Installation Guide
RS232 Cable (optional)
USB Cable (Optional)
ITEM CHECKUP
9
Chapter 1 Specification
Topics incl ded in this chapter are:
1-1 Mainboard Components Locations
1-2 Mainboard Specifications
1-3 Mainboard Specification Table
1-4 Chipset Diagram
Introd ction
Chapter 1 Specification
This series of mainboards features an integration of the powerful
processor Intel Pentium 4 and the single-chip North Bridge VIA Apollo
P4X400A (P4X400 CE Version) plus South Bridge VT8235, by which
the whole system performance can be upgraded to 533 MHz system
bus.
The Intel P4 processor is a rapid execution engine providing 4X100/
4X133MHz quadpumped system bus to allow 3.2GB data transfer rates
possible, while VIA Apollo P4X400A is an enhancement of P4X400 to
support the *DDR 400 DRAM which should have passed Soltek
validation. In addition P4X400A plus VT8235 supports P4 CPUs to
implement the 4X133 Front Side Bus, AGP 8X/4X bus, the LPC Super
I/O and UATA 133/100/66 data transfer rate. This chapter is to intro-
duce to users every advanced function of this high performance
integration.
10
85ERV2 / 85ERV2-L
DIMM 3
DIMM 1
DIMM 2
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
PCI 6
FLASH BIOS
Li
Battery
Peripheral Power
Conne tor
+12 Power
Conne tor
41
Main Power
Conne tor
VIA
P4x400A
VIA
VT8235
1
mPGA478B
IDE2
IDE1
FDC1
1 3
FAN2
FAN1
1
FAN3
1
1
FAN4
IT8705F
LPC I/O
LPT1
COM1
MIC
GAME/MIDI PORT
LINE
OUT
LINE
IN
PS/2 K/B¤
(underside)
PS/2 Mouse
(on top)
USB1 (underside)
USB0 (middle)
Rj 45
(on top)
AC'97
Code
JUSB2
1
10
JUSB1
1
10 SCR1
1
14
Audio 1
1
14
AGP 4X/8X
WOL1
1
RT1
RT2
1
JP1
1
JBAT1
1
JP2
SAPK RST PLED SLED
HDD/LED IR PWR SMI
++
--
+-
1
30
VIA VT6103
PHY (LAN Controller)
CD1
1
3
2
COM2
Audio Code
DDR 266/333/(400 is subje t to validation)
1-1 85ERV2 / 85ERV2-L Components and Options
RJ45
PHY LAN Controller
for 85ERV2-L only
}
Optional 6-channel A dio-O t Connector
11
Chapter 1 Specification
1-2.1 CPU Socket
CPU Socket 478B on board, supporting Intel® Pentium 4 processors
(including Intel Hyper-threading CPUs) in 478-pin package for :
-- 533/400MHz System Bus;
-- Hyper-pipelined technology;
-- Advanced dynamic execution;
-- Advanced transfer cache;
1-2.2 System Chipsets
• North Bridge VIA P4X400A (P4X400 CE Version) for supporting 4X133
4X100MHz system Bus, Hub interface, AGP4X/8X interface and DDR
333/266/200 DRAM memory interface, with an enhancement of
support of *DDR 400 DRAMs which should have passed the Soltek
DDR 400 Memory Module Validation.
• South Bridge VIA VT8235 working with North Bridge supporting the
double speed V-Link, LPC Super I/O, upstream Hub interface, PCI
interface, IDE interface, LAN interface, USB V2.0 interface, as well
as AC’97 Audio 6-channel interface.
1-2.3 Memory
3 DDR DIMM 184-pin slots on board for DDR *400/333/266/200 DRAMs:
• Supporting unregistered, non-ECC DDR *400/333/266/200 DRAM up
to 3 GBs
• Supporting installation of mixed volumes yet same type of DDR DRAM
modules
*Soltek Computer Inc. typically runs a DDR 400 Memory Module
Validation Program for Chipset VIA P4X400A. Detailed information
is available in Soltek Web Site: WWW.soltek.com.tw
1-2.4 AMI BIOS
• Supporting Plug & Play V1.0
• Flash Memory for easy upgrade
• Supporting BIOS Writing Protection and Year 2000 compliant
• Supporting BIOS Setup (See Chapter 4 BIOS Setup)
1-2 Mainboard Specifications
1-2.5 Accelerated Graphics Port (AGP) Interface
AGP Controller embedded on board, supporting:
• 1.5V(4X/8X) power mode only, 1 AGP Slot supported
• 4x AD and SBA signaling, AGP pipelined split-transection longburst
transfers up to 2GB/sec.
• AGP 4X/8X only, AGP V3.0 compliant
12
85ERV2 / 85ERV2-L
1-2.7 M lti-I/O F nctions :
• PCI EIDE Controller, supporting:
-- 2x Ultra ATA133 / 100 / 66 IDE connectors supporting up to 4 IDE
devices
• Dedicated IR Functions:
-- Third serial port dedicated to IR function either through the two
complete serial ports or the third dedicated port Infrared-IrDA (HPSIR)
and ASK (Amplitude Shift Keyed) IR
• Multi-mode parallel data transfer:
-- Standard mode, high speed mode ECP and enhanced mode EPP
• Floppy Disk connector:
-- One FDD connector supporting 2 floppy drives with drive swap support
• Universal Serial Bus Transfer Mode:
-- USB V2.0 compliant, 480 Mb/s USB Bus, supporting Win 2000 and later
operating system; USB drivers provided in Support CD for installation
-- 2 built-in USB connectors and 2 USB pin-headers which require 2 op-
tional USB cables to provide 4 more optional USB ports
• PS/2 Keyboard and PS/2 Mouse
• UARTs (Universal Asynchronous Receiver / Transmitter):
-- Two complete serial ports (COM1 & COM2) on board
1-2.8 Expansion Slots
• 6 PCI bus Master slots
• 1 AGP 4X/8X slot
• 3 DDR DIMM slots
1-2.6 Advanced System Power Management:
• ACPI 1.0B compliant (Advanced Configuration and Power Interface)
• APM V1.2 compliant (Legacy Power Management)
• ACPI POS (Power On Suspend)
• PS/2 Keyboard & Mouse Power On
• Supporting Ring Power Up Control for Wake-on-Modem (external)
and Wake-on-LAN (via Connector WOL1)
• Real Time Clock (RTC) with date alarm, month alarm, and century
field
13
Chapter 1 Specification
1-2.9 AC’97 A dio Codec on board
AC’97 Audio Codec 2.2 compliant on board
1-2.10 LAN on board (85ERV2-L only)
Fast Ethernet Controller integrated in VT8235 and PHY VIA VT6103:
• Supporting 10/100Mb Fast Ethernet Base T LAN
• Supporting Wake On LAN through on-board WOL1 connector
• LAN Driver enclosed in Support CD for user’s installation.
• Supporting up to 6 channels of PCM audio output
• 6 channel audio consists of Front Left, Front Right, Back Left, Back
Right, Center and Woofer for complete surrround sound effect
• AC’97 Audio Codec Driver enclosed in Support CD for user’s
installation.
1-2.11 Hardware Monitor on board
• Hardware Monitor integrated in Super I/O IT8705F, providing moni-
toring and alarm for flexible desktop management of hardware voltage,
temperatures and fan speeds.
• Utility Software SmartGuardian for displaying Monitoring status is
enclosed in Support CD for user’s installation.
1-2.13 Form Factor
• ATX form factor, ATX power supply, version 2.03 compliant, supported
by one Main Power Connector, one +12V Power Connector and one
Peripheral Power Connector
• Mainboard size: 305mm x 220mm
1-2.12 6-channel So nd O tp t S pport (optional)
• This series is designed with an optional 6-channel Audio-out connec-
tor Audio1”. If this option is chosen, it will provide 3 additional audio-
out ports for the 6-channel sound.
14
85ERV2 / 85ERV2-L
1-3 Mainboard Specification Table
CPU
North Bridge
South Bridge
BIOS
Memory
I/O Chip
AGP interface
Audio
IDE Interface
Networking
PCI Slots
I/O Connectors
VGA Display
Other Features
Socket 478B for Intel P4 (HTincluded) CPUs
VIA P4X400A, supporting 533/400MHz FSB
VIA VT8235
AMI BIOS
Supporting DDR 333/266/200 DRM, up to 3GB
(DDR 400 Memory Module subject to validation)
IT8705F
1.5V AGP4X/8X mode only
AC’97 Audio V2.2 compliant, 6-channel interface
2 UATA 66/100/133 IDE ports
VIA LAN Controller, 1xRj45 (85ERV2-L only)
6 PCI Master slots on board
6xUSB ports (V2.0), 1xFDD port, 2xCOM ports,
1xLPT, 1xIrDA, 1xPS/2 K/B, 1xPS/2 Mouse,
VGA not integrated on board
BIOS Writing Protection;
Hardware Monitoring in IT8705F
Keyboard/Mouse Power On;
ATX 2.03 Power Supply;
ATX form factor
SL-85ERV2/ 85ERV2-L Specifications and Feat res
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Placa madre de SOLTEK
SOLTEK
SOLTEK SL-85DR-C Manual de usuario
SOLTEK
SOLTEK SL-85MIR3 Manual de usuario
SOLTEK
SOLTEK 75FRN2 Series Manual de usuario
SOLTEK
SOLTEK 65kv Manual de usuario
SOLTEK
SOLTEK SL-67FV1 Manual de usuario
SOLTEK
SOLTEK SL-75MIV Manual de usuario
SOLTEK
SOLTEK SL-65ME Manual de usuario
SOLTEK
SOLTEK SL-75DRV2 Manual de usuario
SOLTEK
SOLTEK SL-67EV1 Manual de uso y cuidado
SOLTEK
SOLTEK SL-63AV Manual de usuario
SOLTEK
SOLTEK SL-85ERV4-R Manual de usuario
SOLTEK
SOLTEK SL-PM800I-R Manual de usuario
SOLTEK
SOLTEK 82440FX Manual de usuario
SOLTEK
SOLTEK SL-K8T-939FL Manual de usuario
SOLTEK
SOLTEK SL-85LIR3 Manual de usuario
SOLTEK
SOLTEK SL-85DRV3 Manual de usuario
SOLTEK
SOLTEK 75FRN Series Manual de usuario
SOLTEK
SOLTEK SL-55F5 Manual de usuario
SOLTEK
SOLTEK SL-53D2 Manual de uso y cuidado
SOLTEK
SOLTEK SL-85DIV Manual de usuario
Manuales populares de Placa madre de otras marcas
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manual de usuario
Gigabyte
Gigabyte GA-9IVDT Manual de usuario
Texas Instruments
Texas Instruments ADS8372EVM Manual de usuario
Commell
Commell MS-C73 Manual de usuario
IBT Technologies
IBT Technologies MB860 Manual de usuario
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manual de usuario
