INSTRUCTION MANUAL

Contents



1. Description of the controls________________________________12

Thank you for choosing one of our products.

You are advised to read this manual carefully; it contains all the

information you need about the right conditions for the proper, safe use

of your dishwasher.

The individual sections are laid out to provide you with a step-by-step

guide to all your appliance's functions; the texts are easy to understand

and are complete with detailed illustrations.

This user-friendly manual will provide answers to all your questions

about use of the dishwasher.

For any other information about use and maintenance of the dishwasher,

read the enclosed manual carefully.

USER INSTRUCTIONS: useful information is provided for the use of the

washing programs and all the dishwasher's functions.

User instructions



1. Description of the controls

1.1 Front panel

All the dishwasher controls are grouped on the front panel, which is of

different shape depending on the model.

1WASHING PROGRAM SELECTOR

2ON/OFF BUTTON

3ECO 55°C PROGRAM BUTTON (depending on models)

4POWER ON LIGHT

5SALT WARNING LIGHT (certain models only)

6RINSE AID WARNING LIGHT (certain models only)

7RECESSED DOOR HANDLE

SETTING THE WASHING PROGRAM

To select the most suitable washing program, refer to the table below

which indicates the recommended washing according to dish type and

the degree of soiling.

User instructions



After using the table to identify the most appropriate washing program,

turn the PROGRAM SELECTION knob (1) to set the program of choice

by aligning the pointer with the program number. If the appliance is fitted

with the selected program indicator disc, this will show the number of the

program set.

AMOUNT OF

DETERGENT DURATION CONSUMPTION

SWITCH,

CYCLE AND

BUTTON

TYPE AND

DEGREE

OF DIRT

ON DISHES

PROGRAM

SEQUENCE GRAMS MINUTES

(2)

WATER

LITRES (1)

POWER

KWh (2)

SOAK

Pans and dishes

pending

completion

of the load

Cold prewash _6' 50,03

NORMAL

65°C

Very dirty pans

and dishes, even

with dried-on dirt

Cold prewash

Wash at 65°C

Cold rinse

Rinse at 65°C

Dry

30 105' 201,45

DAILY

60°C

Pans and dishes

with normal dirt

Wash at 60°C

Cold rinse

Rinse at 65°C

Dry

30 100' 16 1,40

ECO 55°C

(*) EN 50242

ECO

Dishes

with normal dirt

Wash at 55°C

Cold rinse

Rinse at 65°C

Dry

30 95' 15 1,24

ECONOMY

55°C

ECO

Dishes

with light dirt

Wash at 55°C

Cold rinse

Rinse at 65°C

Dry

30 70' 15 1,20

RINSE

Dishes for rinsing

and drying

Cold rinse

Rinse at 65°C

Dry

_55' 11 0,90

Only run the soak program with half loads.

(*) Reference program as per EN 50242 standard.

(–) Not present.

(1) Average power consumption with the softener set on level 2.

(2) The cycle duration and power consumption may vary according to the water and room

temperatures, and the type and amount of dishes.

The washing cycle will not take place if the dishwasher door is left open

or not properly closed.

User instructions



TABLE FOR CERTIFICATION BODIES

Reference standard EN 50242

Reference program (*) Selector on 3+ECO 55°C

Load 12 place-settings

Type of detergent B

Amount of detergent 30 g

Rinse aid setting Depending on the model 3/4 or 4/6

EN 50242

1.2 Washing programs

Before starting a washing program make sure that:

•The water supply tap is open.

•The correct amount of detergent has been added to the

dispenser.

•The baskets have been correctly loaded.

•The spray arms are able to rotate freely and without

obstruction.

•The dishwasher door is securely closed.

CANCELLING THE CURRENT PROGRAM

To cancel the program in progress the dishwasher must be switched off

by pressing the ON/OFF key (2).

Turn the program selector to SOAK and wait for the dishwasher to start.

On completion of the program, switch off the dishwasher by pressing the

ON/OFF key (2).

User instructions



CHANGING THE PROGRAM

To change the program in progress the dishwasher must be switched off

by pressing the ON/OFF key (2).

Turn the program selector to the program required and then switch the

dishwasher on again by pressing ON/OFF key (2). The dishwasher will

carry out the new program automatically.

TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT

•Always try to run the dishwasher fully loaded.

•Do not wash the dishes in running water.

•Use the washing program that is most appropriate for each type of

load.

•Do not carry out any preliminary rinsing.

•If available, connect the dishwasher to a hot water supply up to 60°C.

•When possible, disable the drying cycle and leave the door open at

the end of the washing cycle: the residual air and heat will dry the

dishes perfectly.

TO CUT DOWN ON DETERGENT CONSUMPTION! … AND PROTECT

THE ENVIRONMENT

The phosphates contained in dishwasher detergents are harmful to the

environment. To avoid using excessive amounts of detergent and to save

on electricity, observe the following:

•separate the more delicate items from dishes that are more resistant

to aggressive detergents and high temperatures;

•do not pour the detergent directly on the dishes.

User instructions



If it is necessary to open dishwasher door during the washing cycle,

there will be a 1-minute delay before the program can be resumed.

After correctly closing the door, the washing program will start again from

where it was interrupted. This operation may negatively affective the

progress of the washing cycle.

END OF CYCLE

At the end of the washing program the selector will be on one of the

STOP markers, depending on the program carried out. Switch off the

dishwasher by pressing the ON/OFF key (2).

REMOVING THE DISHES

At the end of the washing program, wait at least 20 minutes before

removing the dishes, to allow them to cool down. To prevent any water

droplets on the upper basket from falling on the dishes in the lower

basket, it is advisable to unload the lower basket first, and then the

upper basket.

User instructions



ADJUSTING THE WATER SOFTENING SYSTEM

The dishwasher is equipped with an device for the user to adjust the

water softening system according to the hardness of the water supply.

According to the machine model, the selector which acts on the

adjustment may be located:

•inside the plastic locking ring located on the right-hand side, inside

the dishwasher;

•inside the water softener, just below the cap.

Both allow for adjustment to 5settings:

WATER HARDNESS TABLE

WATER HARDNESS

German Degrees (°dH) French Degrees (°dF) SETTING

0 - 4 0 - 7 Setting N. 1 NO SALT

5 - 15 8 - 25 Setting N. 1

16 - 23 26 - 40 Setting N. 2

24 - 31 41 - 60 Setting N. 3

32 - 47 61 - 80 Setting N. 4

48 - 58 81 - 100 Setting N. 5

Contact your local water board for information on the hardness of your

water supply.

INSTRUCTION MANUAL

Contents



1. Safety and operating instructions __________________________28

2. Installation and hook-up _________________________________ 31

3. Operating instructions ___________________________________33

4. Cleaning and maintenance _______________________________46

Thank you for choosing one of our products.

You are advised to read this manual carefully; it contains all the

information you need about the right conditions for the proper, safe use

of your dishwasher.

The individual sections are laid out to provide you with a step-by-step

guide to all your appliance's functions; the texts are easy to understand

and are complete with detailed illustrations.

Following the cleaning instructions provided here will keep your

dishwasher's performance at peak levels in the long term.

This user-friendly manual will provide answers to all your questions

about use of the dishwasher.

INSTALLATION INSTRUCTIONS: these are intended for the qualified

technician who must carry out the installation, hook-up and testing of

the appliance.

USER INSTRUCTIONS: useful advice is provided for the use of baskets,

spray arms, containers and filters.
