Smeg LSPU8643WH Manual de usuario
Contents
1
1. IMPORTANT SAFETY INSTRUCTIONS ____________________ 2
2. INSTALLATION AND HOOK-UP _________________________ 10
3. DESCRIPTION OF THE CONTROLS _____________________ 18
4. OPERATING INSTRUCTIONS ___________________________ 26
5. CLEANING AND MAINTENANCE ________________________ 27
6. TROUBLESHOOTING _________________________________ 28
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use
of your dishwasher.
This manual contains only the basic information required to use the
appliance. The complete manual can be obtained from
www.smeg.com/download-manuals
by entering the product code shown on the plate attached to the inner
right hand edge of the dishwasher door.
The manual can be accessed quickly via the QR code using a device
with a QR reader application.
Installation
2
TRANSLATION OF THE ORIGINAL
INSTRUCTIONS
1. IMPORTANT SAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Before using the appliance, carefully read all the
instructions contained in this manual.
During installation, take care not to injure yourself on
the sharp edges of the appliance: wear safety
gloves.
This manual is an integral part of the appliance; it
must always be kept intact together with the
dishwasher for future reference (even if sold).
Use the dishwasher only for its intended function.
This appliance is intended for indoor use in a
household environment and similar such as staff
kitchens of shops, offices and other workplaces,
institutions, and for the use by guests at hotels,
hostels, bed and breakfast and other residential
facilities. The appliance is designed and
manufactured to perform the following function:
washing and drying of dishes; any other use shall
be considered improper. The manufacturer
declines all responsibility for uses other than
those described above.
Do not use appliances which have been damaged
during transit! If in doubt, contact your dealer.
Installation
3
Do not operate your dishwasher unless all enclosure
panels are properly in place.
Do not tamper with controls.
The appliance must be installed and connected in
accordance with the instructions provided by the
manufacturer. Installation must be performed by
qualified technicians in accordance with
applicable regulations.
The installation and repair or servicing shall be
carried out by qualified and authorised technical
personnel. Interventions by unauthorised personnel
can be dangerous and cause the warranty to lapse.
The installation must comply with all the directives of
the country where the dishwasher is installed, and in
the absence of them, in the United States the
National Electric Code; in Canada the Canadian
Electric Code C22.1 - Latest edition/provincial and
municipal codes and/or local codes
Under certain conditions, hydrogen gas might be
produced in a hot-water system that has not been
used for two weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot-water system has not been
used for such a period, before using the dishwasher
turn on all hot-water faucets and let the water flow
from each for several minutes. This will release any
accumulated hydrogen gas. As the gas is
flammable, do not smoke or use an open flame
during this time.
Installation
4
Never leave waste packaging unattended. Do not
allow children to play with packaging materials.
Separate waste packaging materials by type and
consign them to the nearest recycling centre.
The plate with the technical data, serial number and
marking is in a visible position on the inside edge of
the door. It must not be removed.
The appliance must be earthed in compliance with
electrical safety regulations. The manufacturer
declines all responsibility for damage to persons
or property resulting from failure to earth the
appliance or from a defective earth connection.
During the installation the appliance must be
disconnected from the network.
Do not install the appliance in a place subject to
freezing.
Do not install the appliance near equipment with
high irradiation temperature (e.g. gas burners,
fireplaces, etc.).
If the appliance is installed in a compartment above
or below another equipment (e.g. gas burners,
ovens, etc.), read carefully the instructions provided
by the manufacturer of the equipment. If the
instructions of the equipment do not contain
information, contact the manufacturer of the
equipment to ensure that the appliance can be
installed above or below it.
Installation
5
Building-in the appliance underneath a hob is
absolutely forbidden. Installing a hob on top of free-
standing appliance is absolutely forbidden.
To ensure stability, install the appliance only under
continuous worktop, securely fixed to adjacent
cabinets. If the appliance is installed in a high
cabinet, both the appliance and the cabinet must be
adequately fixed.
If the appliance is not built-in and is therefore
accessible on one side, the door hinge area must be
covered for safety reason (injury hazard). The
covering fixtures are available as an accessory from
specialist dealers or the after-sales.
Check that the voltage and the frequency of the
mains match the ratings on the name plate of the
appliance.
The plug on the supply cord and the corresponding
socket outlet must be of the same type and meet the
regulations in force. Do not use adaptors or shunt
connections in order to avoid the possibility of
overheating or burning.
The plug of the appliance must be accessible after
installation. Never disconnect the plug by pulling on
the power supply lead.
If the appliance is provided with a plugless supply
cord, an omnipolar circuit breaker providing a full
disconnection in overvoltage protection class III
must be installed in an easily accessible position on
the supply lineile.
Installation
6
The appliance must be connected to the water
supply by means of new hoses.
Briefly test the appliance after installation. Run a
wash cycle with a temperature of between 113°F
and 158°F (45°C-70°C) with the dishwasher empty
and using a specific dishwasher detergent. (It is not
sufficient to run a soak cycle). If the dishwasher fails
to operate correctly, disconnect it from the electrical
power supply and call the nearest technical service
centre. Never attempt to repair the appliance
yourself.
The dishwasher should only be used by adults. Use
by children aged from eight years and persons with
reduced physical, sensor or mental capabilities or
lack of experience and knowledge is only permitted
under the supervision of a person responsible for
their safety.
To reduce the risk of injury, do not allow children to
play in or on a dishwasher.
Use only detergents or wetting agents
recommended for use in a dishwasher and keep
them out of the reach of children
Keep children away from the dishwasher when the
door is open. Always check that the detergent
distributor is empty after completion of the wash
cycle.
Cleaning and regular maintenance of the appliance
by children is only permitted under the supervision
of a person responsible for their safety.
Installation
7
Some detergents are strongly alkaline. Avoid
contact with the skin and eyes. Detergents can be
extremely dangerous if swallowed. They contain
substances capable of causing permanent damage
to the mouth and throat, and even leading to
suffocation. Observe all the safety instructions on
the packaging of these products.
Do not drink the water residues which may be
present on the dishes or appliance at the end of the
washing program.
Never place solvents such as alcohol or turpentine,
which are potentially explosive, inside the appliance.
Never load dishes soiled with ash, wax or paint.
Never leave the dishwasher door open; people
might trip over it.
Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
Switch off the dishwasher after use to avoid wasting
electricity.
Locate sharp items so that they are not likely to
damage the door seal.
Load sharp knives with the handles up to reduce the
risk of cut-type injuries.
The appliance satisfies all applicable safety
regulations governing electrical equipment. Any
technical checks should be conducted exclusively by
trained and authorised technicians: repairs
performed by unauthorised persons not only
Installation
8
void the warranty but may also put the user’s
safety at risk.
In the event of a fault, disconnect the dishwasher
from the electrical power supply and shut off the
water tap. In the event of damage to the supply cord,
have it replaced by the manufacturer or an
authorised technical service centre.
Some components are live even with the on/off
button in the off position. Before performing any
maintenance work on the appliance, disconnect it
from the electrical power supply.
Do not clean the machine with a water jet machine,
high-pressure or steam cleaners.
Do not introduce animals into the dishwasher.
Models with “acquastop” device
This device prevents flooding in case of water leak.
When the “acquastop” device is tripped, contact a
qualified technician to identify and repair the fault.
In these models the water intake hose contains a
solenoid valve. Do not cut the hose and do not
allow the solenoid valve to drop into water. In
case of damage to the water intake hose,
disconnect the appliance from the electrical and
water supply.
Warning: The device only works if the
dishwasher is connected to the mains.
Installation
9
1.1 Disposal
The appliance does not contain substances in
quantities sufficient to be considered hazardous to
health and the environment, in accordance with current
European directives:
To dispose of the appliance:
Remove the washing compartment door.
Cut the power cable,
Make the lock unusable.
The manufacturer declines any liability for damage
or injury caused by failure to comply with the
instructions indicated above or as a result of
tampering with even just one part of the applia
nce
and the use of non
-
original spare parts.
Installation
10
2. INSTALLATION AND HOOK-UP
2.1 Technical characteristics
Water supply pressure min. 0,05 - max. 0,9 MPa (min. 0.5
– max. 9 bar)
Water supply temperature
max. 140°F
–
60°C
Capacity
12
-
13 standard place settings
Class of protection against
moisture
IPX0
Protection against electric
shock
class I
Electrical data
see the data
plate
Appliance dimensions
Dimensions
H
P
L
Free standing 850 mm;
33”-15/32
627 mm
24”-11/16
600 mm
23”-5/8
Free standing
maxi
890 mm;
35”-3/64
627 mm
24”-11/16
Integrated 818-888 mm;
32”-13/64-34”-61/64
584 mm
22”-63/64
Integrated
maxi
858-928 mm;
34”-31/32-36”-35/64
584 mm
22”-63/64
Este manual sirve para los siguientes modelos
2
Tabla de contenidos
Otros manuales de Lavavajillas de Smeg
Smeg
Smeg LVS292DX Manual de usuario
Smeg
Smeg DWAFI6214-2 Manual de usuario
Smeg
Smeg GV61224 Manual de usuario
Smeg
Smeg PL964 Manual de usuario
Smeg
Smeg DI612CA Manual de usuario
Smeg
Smeg GW3060 Manual de usuario
Smeg
Smeg DWIFABNE2 Manual de usuario
Smeg
Smeg STX4-3 Manual de usuario
Smeg
Smeg LVSP345BQX Manual de usuario
Smeg
Smeg PL19K Manual de usuario
Smeg
Smeg DC122B Manual de usuario
Smeg
Smeg ST147 Manual de usuario
Smeg
Smeg Dishwasher BLV1R Manual de usuario
Smeg
Smeg DWAUP364X Manual de usuario
Smeg
Smeg CSE66-I2 Manual de usuario
Smeg
Smeg LSE451 Manual de usuario
Smeg
Smeg LVS1251B Manual de usuario
Smeg
Smeg Dishwasher DI612CAH Manual de usuario
Smeg
Smeg Dishwasher PL115NE Manual de usuario
Smeg
Smeg DWAU157XT Guía
