Wireless SMCBT-EDR

EZ ConnectTM Wireless Bluetooth USB Adapter

www.smc.com

The EZ Connect™ Wireless Bluetooth USB Adapter (SMCBT-

EDR) is another cutting edge wireless technology brought

to you by SMC. The SMC Wireless Bluetooth USB Adapter

allows your USB PC or notebook to work with all Bluetooth

devices.

Simply plug in your SMCBT-EDR Wireless Bluetooth USB

Adapter into the USB port on your laptop or desktop.

Bluetooth technology allows you to communicate with

other Bluetooth devices to wirelessly share files, transfer

data, print, synchronize your PDA information, send and

receive email, browse the web, and use a mobile phone to

access the Internet. The SMC Wireless Bluetooth USB

Adapter supports Class 2 Bluetooth and has a operating

range of up to 300 feet.

Connect with up to seven other Bluetooth devices at the

same time, the SMC Wireless Bluetooth USB Adapter sup-

ports encryption and authentication to ensure secure data

transmission across the network. t does support multitask-

ing for 3 devices connected at the same time. The EZ

Connect™ Wireless Bluetooth USB Adapter includes an EZ

Installation Wizard that enables quick and easy setup.

Simply put the EZ Installation Wizard CD into your CD drive,

and click on the Install Driver/Utility Link. The wizard will

perform the installation automatically. Then plug in your

SMCBT-EDR into the USB slot of your laptop or PC, and you

will be ready to enjoy the freedom of wireless Bluetooth

networking. The new product instantly creates a Personal

Area Network (PAN) connecting your PC or laptop to near-

by Bluetooth-enabled devices. The SMC Wireless Bluetooth

USB Adapter brings you a new level of experience in avail-

able, reliable, and cost-effective wireless networking!

FEATURES

EZ Installation Wizard

Bluetooth v2 compliance

Class 2 Bluetooth Support

Sleek and compact

Connect up to 7 different Bluetooth-enabled devices

Encryption and authentication ensure safe, secure communications

Supports Windows 98SE, ME, 2000, XP and Mac OS 10.2.x and above

Multitasking

Setup is simple and easy with EZ Installation Wizard

Adds latest Bluetooth technology to your existing PC or notebook.

Works with all Bluetooth-enabled devices to wirelessly share files,

print, synchronize your PDA information, and use a mobile phone to

access the Internet

Allows for operating range at up to 300 feet

Compact, easy to carry form factor

Instantly create your Personal Area Network (PAN)

Encryption link and authentication protect your information and

ensure secure data transmissions

Works with major operating systems

add up to 3 devices and use them at the same time

BENEFITS

OVERVIEW

TECHNICAL SPECIFICATIONS SMCBT-EDR

STANDARDS

• Bluetooth™ specification v2

• USB v1.1, 2.0

INTERFACE

• USB (Type A)

RADIO

• Class 2 Bluetooth

LINK MODE

• ACL, eSCO (Extended Synchronous Connection-Oriented)

FREQUENCY BAND

• 2.4GHz

MODULATION

• GFSK (Gaussian Frequency Shift Keying)

SPECTRUM

• AFH (Adaptive Frequency Hopping)

ANTENNA TYPE

• Internal

RECEIVER SIGNAL RANGE

• Better than -76dBm @0.1%BER

RF OUTPUT POWER

• -6~+4dBm (Max +6 dBm)

OPERATION CURRENT

• < 80mA(max)

OPERATING DISTANCE

• Up to 300 feet

• Up to 100 m

SECURITY

• Pairing, Encryption, Authentication

COMPATIBLE OS

• Microsoft Windows 98 SE/2000//ME/XP,

Mac OS v10.2 and higher

BLUETOOTH SOFTWARE SUPPORT

• PAN, DUN, SPP, LAN, FTP, Synchronization,

OBEX, HCRP, HID, FAX, BIP, AV, HS

OPERATION TEMPERATURE

• -40 - 850C

STORAGE TEMPERATURE

• -40 - 1050C

REGULATORY COMPLIANCE

•FCC

• ETSI

• Industry Canada

DIMENSION

• 46 x 19 x 10 mm

• 1.8 x .75 x .40 in

WEIGHT

• 0.02 lbs

•9 g

North America

38 Tesla

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/ Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local

country contact information

www.smc.com
