CMS-30100
Table of Contents
English ..................................................................................................................... iii
Nederlands .............................................................................................................. xx
Deutsch.................................................................................................................... xxxvii
Français.................................................................................................................... liv
Italiano..................................................................................................................... lxxi
Polski ....................................................................................................................... lxxxviii
Table of Contents
CMS-30100_IM iii
Table of Contents
1 Safety ................................................................................................................................................................... 4
1.1 Installation Safety ................................................................................................................................................. 4
1.2 Operation Safety................................................................................................................................................... 4
2 Parts Description .................................................................................................................................................. 5
3 Installation ........................................................................................................................................................... 6
3.1 Install the monitor ................................................................................................................................................ 6
3.1.1 Mounting.................................................................................................................................................. 6
3.1.2 Wiring....................................................................................................................................................... 6
3.1.3 Insert the MicroSD card (not included).................................................................................................... 6
3.2 Install the camera ................................................................................................................................................. 6
3.2.1 Mounting.................................................................................................................................................. 6
3.2.2 Wiring....................................................................................................................................................... 7
4 On-screen menu ................................................................................................................................................... 8
5 Setting up your device .......................................................................................................................................... 9
5.1 Add a camera........................................................................................................................................................ 9
5.2 Select WIFI channel (if required) .......................................................................................................................... 9
6 System operation ................................................................................................................................................. 10
6.1 Video Playback...................................................................................................................................................... 10
6.2 System Setup ........................................................................................................................................................ 11
6.2.1 Language .................................................................................................................................................. 11
6.2.2 Time Setup ............................................................................................................................................... 11
6.2.3 Wireless Internet...................................................................................................................................... 12
6.2.4 Wireless Channel...................................................................................................................................... 12
6.2.5 Camera Audio Enable............................................................................................................................... 13
6.2.6 Volume setup ........................................................................................................................................... 13
6.2.7 Auto Close ................................................................................................................................................ 14
6.3 Add a camera........................................................................................................................................................ 14
6.4 Record setup......................................................................................................................................................... 15
6.4.1 Record Schedule....................................................................................................................................... 15
6.5 Alarm setup........................................................................................................................................................... 16
6.6 System manage..................................................................................................................................................... 16
6.6.1 System Info............................................................................................................................................... 16
6.6.2 Factory Setting ......................................................................................................................................... 17
6.6.3 Upgrade.................................................................................................................................................... 17
6.6.4 IPC Upgrade.............................................................................................................................................. 17
7 Setting up the mobile app..................................................................................................................................... 18
8 Declaration of Conformity .................................................................................................................................... 19
1 | Safety
4 CMS-30100_IM
1 Safety
1. Please read these instructions carefully before installing and using the product.
2. Do not cut the power supply cable to extend it; the device (transformer) will not
work with a longer cable. Do not plug in the device until all the wiring has been fin-
ished.
1.1 Installation Safety
1. Keep children and bystanders away while installing the products. Distractions can
cause you to lose control.
2. Do not overreach when installing this product. Keep proper footing and balance at
all times. This enables better control in unexpected situations.
3. This product is not a toy. Mount it out of reach of children.
1.2 Operation Safety
1. Do not operate electrically powered products in explosive atmospheres, such as in
the presence of flammable liquids , gases, or dust. Electrically powered products
create sparks which may ignite the dust or fumes.
2. The warnings, precautions, and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must be un-
derstood by the operator that common sense and caution are factors which can-
not be built into this product, but must be supplied by the operator.
3. Do not expose the Power Adapter of this product to rain or wet conditions. Water
entering the Power Adapter will increase the risk of electric shock.
4. Do not abuse the Power Cord. Never use the cord for unplugging the plug from the
outlet. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
5. The adapter must match the outlet. Never modify the plug in any way. Unmodified
plugs and matching outlets will reduce risk of electric shock.
Parts Description | 2
CMS-30100_IM 5
2 Parts Description
Camera
1. Antenna
2. LED light
3. Lens
4. Day/night sensor
5. Microphone
6. Speaker
Monitor
1. Antenna
2. Touch screen
3. Microphone
4. LED battery indicator
5. LED recording indicator
6. USB slot
7. MicroSD slot
8. On/Off switch for battery use
9. AC adaptor input
10. Stand
Frequency: 2.4GHz
Maximum transmission power: 17.63dBm
3 | Installation
6 CMS-30100_IM
3 Installation
Before doing the fixed installation, it is recommended that you consider the following:
Connect everything to familiarize yourself with the units.
Check the wireless coverage at the intended mounting locations by temporarily placing
the units.
3.1 Install the monitor
3.1.1 Mounting
The monitor is designed to stand on a table or any flat surface.
a) Pull out the stand leg on the back of the monitor.
b) Pull the two antennas on the back of the monitor to an upright position.
c) Place on any flat surface.
3.1.2 Wiring
The monitor is portable and can be used on battery power, AC power or both. When
the AC adapter is connected the battery charges until full and then operates directly
from the AC adapter.
Batteries must be purchased separately.
Battery type: 18650
3.1.3 Insert the MicroSD card (not included)
To record video, a MicroSD card is required.
a) Locate the MicroSD card slot on the right side of the monitor.
b) Insert the MicroSD card (It will only fit when in the correct position).
c) A class 10 MicroSD card with a maximum storage of 128gb is recommended.
3.2 Install the camera
3.2.1 Mounting
The camera can be mounted in any direction and on any surface that can hold its
weight. The camera must be mounted near access to mains power or an extension
may be needed.
To mount the camera, you will need the following tools:
üA suitable screwdriver for the included screws.
üA drill and suitable drill bit for the included screw plugs.
a) Position the camera where desired.
b) Mark the screw positions with a pen.
c) Drill the necessary holes.
Installation | 3
CMS-30100_IM 7
d) Insert the plugs.
e) Drill a sufficiently sized hole to pull the cables.
f) Pull the required cables through the hole.
g) Mount the included antenna onto the camera.
h) Fasten the camera with the screws.
In case that you wish to run the cable on the outside of the wall, a weatherproof con-
nection box is required.
3.2.2 Wiring
The camera is wireless and only requires an electrical connection.
Things to consider when wiring the camera:
– The cable connection must be done indoors or inside a weather proof connection
box, mounted on the outside.
– The hole should be sealed with filler to avoid water ingress.
– It is recommended to pull all cables through the hole. The re-set button can be left
outside but it is not recommended.
4 | On-screen menu
8 CMS-30100_IM
4 On-screen menu
Illustration1: On screen menu
The on screen menu appears when you tap in the video feed.
Button Description
Microphone Press and hold to enable communication with the currently
watched camera. (Make sure camera microphone is enabled, See
section “Camera Audio Enable”.)
Mute Select to mute/unmute the monitor speakers
Main menu Select to enter the main menu
Zoom Select to Zoom the video feed.
Tap once to select the zoom mode.
Tap again in the image to zoom.
Select the (-) icon to exit the zoom mode.
Playback Select to enter the Playback menu.
This will allow you to view recordings.
Setting up your device | 5
CMS-30100_IM 9
5 Setting up your device
5.1 Add a camera
Illustration2: Main menu - Add
Camera
Illustration3: Add Camera
The monitor can pair up to 4 cameras. To add a camera do the following procedure:
a) Turn the camera on by connecting it to the mains supply.
b) Wait for 30 seconds.
c) You will now hear “Start configuration mode”.
ðNOTE: If you do not hear the voice, press the re-set button on the camera for
6 seconds until you hear “Restore factory settings”.
d) On the monitor from the main menu: Select “Add Camera”.
e) Select “Add Camera”. (This must be done within x minutes from resetting the cam-
era.)
f) On the camera: If the above steps are done correctly, you will hear:
- “Wireless settings, please wait”
- “Wireless connection successful”
g) On the monitor: Wait for the pairing to complete.
5.2 Select WIFI channel (if required)
Illustration4: Wifi channel
Illustration5: Select wifi channel
If there are many Wi-Fi networks in your area and you are experiencing bad reception,
change the Wi-Fi channel by doing the procedure below:
a) From the main menu: Select “Add Camera”.
b) Select “Wifi Channel”
c) Select “Wifi Channel”
d) Select a channel from the list. (Try different channels if the reception problem per-
sists.)
6 | System operation
10 CMS-30100_IM
6 System operation
6.1 Video Playback
Illustration6: Video playback icon
Illustration7: Main directory
Illustration8: Date direcotory
Illustration9: Time directory
The monitor will start recording video depending on the settings in “Record Setup”. To
view the recordings do the procedure below:
a) From the main menu: Select “Video Playback”.
b) Select the camera folder (1-4) you wish to view recordings from. (Up to 4 cameras
are supported).
c) Select the folder with the desired date.
d) Select the folder with the desired time.
e) Select the desired file to view the recording.
