SMART Smart Notebook 3D Tools Manual de usuario

SMARTNotebook™

3DTools

User’s guide

Product registration

If you register your SMART product, we’ll notify you of new features and software upgrades.

Keep the following information available in case you need to contact SMARTSupport.

Serial number:

Date of purchase:

Trademark notice

SMARTNotebook, smarttech, SMARTExchange, the SMART logo and all SMART taglines are trademarks or registered trademarks of SMARTTechnologiesULC in the

U.S. and/or other countries. Google and SketchUp are trademarks of Google Inc. Windows, DirectX and WindowsVista are either registered trademarks or trademarks of

Microsoft Corporation in the U.S. and/or other countries. All other third-party product and company names may be trademarks of their respective owners.

into any language in any form by any means without the prior written consent of SMARTTechnologiesULC. Information in this manual is subject to change without notice

and does not represent a commitment on the part of SMART.

One or more of the following patents: US6320597; US6326954; US6741267; US7151533; US7757001; USD616462; and USD617332. Other patents pending.

01/2012

Contents

Using SMARTNotebook 3DTools 1

Activating SMARTNotebook 3DTools 1

Incorporating 3D content into your lessons 2

Getting started 2

Inserting and manipulating 3Dmodels 5

Inserting 3D models 5

Manipulating 3D models 6

Navigating 3D scenes 9

Disguising 3D models before presenting them 12

Using Google SketchUp and 3D Warehouse with SMARTNotebook 3DTools 15

Using SketchUp with SMARTNotebook 3DTools 15

Using Google 3D Warehouse with SMARTNotebook 3DTools 16

Index 17

Using SMARTNotebook

3DTools

Activating SMARTNotebook 3DTools 1

Incorporating 3D content into your lessons 2

Getting started 2

Windows operating systems 2

MacOSX operating system software 2

SMARTNotebook™ 3DTools software plug-in for SMARTNotebook™ collaborative learning

software provides in-depth visual representations that can be manipulated across three dimensions to

increase student engagement, leading to deeper understanding and appreciation of complex

concepts.

This user’s guide provides the information you need to begin using SMARTNotebook 3DTools as

well as Google™ SketchUp™ sketching software and 3D Warehouse.

Activating SMARTNotebook 3DTools

gTo activate SMARTNotebook 3DTools

1. For Windows® operating systems, select Start > All Programs > SMART Technologies >

SMARTTools > SMART Product Update.

For MacOSX operating system software, select Applications > SMARTTechnologies >

SMARTTools > SMARTProduct Update.

The SMART Product Update window appears.

2. Click Activate in the SMART Notebook row.

The SMART Software Activation dialog box appears.

3. Click Add.

4. Type the product key you received from SMART in the Product Key box, and then click Add.

Chapter 1

5. Click license agreement, review the license agreement, and then click Close.

6. If you accept the license agreement, select the I accept the terms in the license agreement

check box.

7. Click Next.

SMARTNotebook 3DTools activates.

8. Click Finish, and then close the SMART Product Update window.

Incorporating 3D content into your lessons

You can incorporate 3D content into your SMARTNotebook software lessons. The following are

examples of how to do this:

lIf you’re teaching a biology lesson, insert a 3D model of a heart into your .notebook file. Rotate

and change the size of the 3D model to present the different parts of the heart.

lIf you’re teaching an English lesson, insert a 3D model of a city that is referenced in a novel the

class is reading. Enter the 3Dscene to navigate streets and interiors of buildings.

lIf you’re teaching a primary lesson, insert multiple 3D models and use the Disguise feature to

reveal answers as a memory exercise.

Getting started

To get started with SMARTNotebook 3DTools, you need to have SMARTNotebook software on a

computer that meets the following requirements.

Windows operating systems

lPentium® 4 processor or better

l512 MB of RAM (1 GB recommended)

l2 GB of free hard disk space

lWindows XP SP3, WindowsVista® SP2 or Windows 7 operating system

lDirectX® 9 compatible graphics hardware

MacOSX operating system software

l1.5 GHz Intel® processor or better

l1 GB of RAM

C H A P T E R 1

Using SMARTNotebook 3DTools

l1 GB of free hard disk space for minimum installation (2 GB for full installation with Gallery

collections)

lMacOSX 10.6 operating system software or later

C H A P T E R 1

Using SMARTNotebook 3DTools

Inserting and manipulating

3Dmodels

Inserting 3D models 5

Manipulating 3D models 6

Rotating a 3Dmodel 7

Pausing, playing and restarting animation 7

Adding labels 8

Navigating 3D scenes 9

Disguising 3D models before presenting them 12

To use SMARTNotebook 3DTools software, you need to insert a 3D model in your .notebook file.

After you insert a 3D model, you can manipulate it in the same way you manipulate other objects in

SMARTNotebook software.

N N O T E

You can insert 2D images and 3D models on the same page and manipulate them the same way

you manipulate other objects in SMARTNotebook software.

Inserting 3D models

3D models are available from the Gallery Sampler and the SMARTExchange™ website

(exchange.smarttech.com). You can also insert your own 3D models if they are in one of the following

formats:

lCOLLADA (.dae)

l3D Object (.obj)

lFBX (.fbx)

Chapter 2

N N O T E

Textures and other information for some 3D models are stored in separate files and folders. When

you insert these 3D models, ensure the 3D model file is located in the correct folder structure with

the supporting files and folders.

gTo insert a 3D model

1. Select Insert > 3D File.

The Insert 3D File dialog box appears.

2. Browse to and select the 3D model you want to insert.

3. Press Open.

The 3D model appears on the page.

Manipulating 3D models

After inserting a 3D model, you can manipulate it in the same way you manipulate other objects in

SMARTNotebook software. In particular, you can do the following:

lCut, copy and paste

lClone

lMove

lScale

lLock

lAttach links and sounds

lAdd to the Gallery tab

N N O T E S

lFor information on these basic options, see the Help for SMARTNotebook software by

selecting Help > Contents.

lWhen you add a 3D model to the Gallery tab, it appears in the 3D Objects category.

In addition to these basic options, you can do the following:

lRotate the 3D model

lPause, resume, play and restart animation

C H A P T E R 2

Inserting and manipulating 3Dmodels
