SMART-AVI HKM-PRO Manual de usuario

HDMI KVM SWITCH

with USB 3.0 HUB

THE NEXT GENERATION HDMI

KVM SWITCH, FEATURING

THREE USB 3.0 PORTS

AND AN MHL PORT

Quick Start Guide

VIDEO

Format HDMI 1.3b [Deep Color, xvYcc color

space supported]

DVI Compliance Single-link DVI-D 1.1

HDCP Compliance 1.0/1.1

Video Bandwidth Single-link 340MHz [10.2Gbps]

Resolution 480i,480p,720i,720p,1080i,1080p

Input Interface (4) HDMI [7.1ch audio & video]

Output Interface (1) HDMI [7.1ch audio & video]

Connector Type A[19-pin female]

Maximum Distance 25 ft.

AUDIO

Frequency Response 20 Hz to 20 KHz

Impedance 600 ohm

Nominal Level 0-1.0 V

Common Mode Rejection at 60dB

Input Interface (4) 3.5 mm Stereo Audio;

(3) Microphone Jack Female

Output Interface (1) 3.5 mm Stereo Audio;

(1) Microphone Jack Female

USB

Input Interface (3) USB Type B

Output Interface (2) USB Type A

CONTROL

Front Panel Tact Switch

OTHER

Power External 100-240 VAC/5VDC4A

@10W

Dimensions 8.7”W X 3.2”D X 1.9”H

Weight 1.55 lbs

Approvals UL, CE, ROHS Compliant

Operating Temp. 32-131°F (0-55 °C)

Storage Temp. -4-185 °F (-20-85 °C)

Humidity Up to 95%

NOTICE

The information contained in this document is

subject to change without notice. SmartAVI makes

no warranty of any kind with regard to this material,

including but not limited to, implied warranties of

merchantability and tness for particular purpose.

SmartAVI will not be liable for errors contained

herein or for incidental or consequential damages in

connection with the furnishing, performance or use of

this material.

No part of this document may be photocopied,

reproduced, or translated into another language

without prior written consent from SmartAVI

Technologies, Inc.

800.AVI.2131, 702.800.0005

2455 W Cheyenne Ave, Suite 112

North Las Vegas, NV 89032

SmartAVI.com

TECHNICAL SPECIFICATION

HKM-PRO

WHAT’S IN THE BOX

PART NO. Q-TY DESCRIPTION

HKM-PRO-S 1 4 Port KVM HDMI, USB3.0,

Audio switch

PS5VD4A 1 PS5VD4A Power Supply

Quick Start Guide 1

OVERVIEW

The HKM-PRO is a cutting edge HDMI KVM (Keyboard,

Video and Mouse) switch perfectly catered for the latest AV

technology. Three HDMI slots, two USB 3.0 Type A ports,

three USB 3.0 Type B ports, audio input/output, one MHL/

Android port, and two USB 2.0 Type A ports make the HKM-

PRO the ultimate in KVM switch on the market. With the

growing popularity of USB 3.0 devices, as well, the HKM-

PRO is the ideal way for users to stay up to date with all of

their KVM needs.

The HKM-PRO supports hot-key switching, which makes

it easier than ever to switch between computers. The

HKM-PRO also fully emulates USB keyboard and mouse

functions, allowing connected computers to boot normally

without keyboard error.

FEATURES

• Supports HDMI KVM Operation, with USB 3.0 Hub

• Supports HDMI 1.4a with 1080p HD Video

• Supports MHL 1.1 for Compatible Android Phones

• Supports DDC/DDC2B, Hot-Plug Detection (HPD) and

HDCP Functions

• Supports Default EDID and Selected EDID Modes

• Supports Hot-Key Switching

• Full USB Keyboard and Mouse Emulation

• Firmware Upgradeable

• Easy to Install, No Software Required

1. Connect a USB keyboard & USB mouse to the USB ports with keyboard and mouse symbols.

2. Connect an HDMI display to the HDMI port labeled CONSOLE.

3. Optionally connect speakers or headphones to the Audio port above the CONSOLE port.

4. Optionally connect a microphone to the microphone port above the CONSOLE port.

5. Optionally connect USB peripherals to the USB 3.0 ports.

6. Connect each computer’s HDMI output to the HKM-PRO HDMI input port.

7. Connect each computer’s USB output to the HKM-PRO USB input with a USB type A to type B cable.

8. Optionally connect each computers audio output to the HKM-Pro’s audio input.

9. Optionally connect each computers microphone output to the HKM-Pro’s microphone input.

10. Connect a Smartphone to the MHL HDMI port on the HKM-PRO.

11. Connect a Smartphone to the audio port on the HKM-PRO.

12. Power on the HKM-PRO and all connected devices.

HKM-PRO FRONT HKM-PRO BACK

HARDWARE INSTALLATION
