Skope ActiveCore TME-N Series Manual de usuario

TME-N ActiveCore

SKOPE Top Mount Chiller

Hydrocarbon

Service Manual

MAN80128 Rev. 1.6 Jan. 2023

TME-N ActiveCore

SKOPE Top Mount Fridge

Hydrocarbon

Service Manual

MAN80128

Rev. 1.6 Jan. 2023

SKOPE Industries Limited reserves the right to alter specifications without notice.

is a registered trademark of SKOPE Industries Limited.

SKOPE INDUSTRIES LIMITED

Head Office

PO Box 1091, Christchurch

New Zealand

A.B.N. 73 374 418 306

AU: 1800 121 535

NZ: 0800 947 5673

E-mail: [email protected]

Website: www.skope.com

Trademark Infringement

The SKOPE trademark on this product is infringed if the owner, for the time being, does

any of the following:

• Applies the trade mark to the product after its state, condition, get-up or packaging

has been altered in any manner

• Alters, removes (including part removal) or obliterates (including part obliteration) the

trade mark on the product

• Applies any other trade mark to the product

• Adds to the product any written material that is likely to damage the reputation of the

trade mark

Notice of the above contractual obligations passes to:

• Successors or assignees of the buyer

• Future owners of the product

SKOPE TME-N ActiveCore

Service Manual iii

Contents

1 Servicing Hydrocarbon

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

SKOPE HC Service Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 Specifications

Models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

3 Installation

Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Ventilation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Fitting Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Removing Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Shelf Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Repositioning a Shelf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

4 Electronic Controller

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

SCS Connect Field App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

SCS Connect Track App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

SKOPE-Connect App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Controller Faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Buttons and Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Service Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

SCS Connect Field App. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

App Menu Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Faults and Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

5 Wiring

Model: TME650/1000N-A Series . . . . . . . . . . . . . . . . . . . . . . . . .20

6 Replacement Procedures

Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Sign Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Alignment Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Height Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Replacing the Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Removing and Refitting the Door . . . . . . . . . . . . . . . . . . . . . . . . .26

Adjusting Door Tension. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Replacing the Torsion Bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Hinge Reversal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Refrigeration System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Before Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

On-site Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Off-site Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Refrigeration Cartridge Assembly . . . . . . . . . . . . . . . . . . . . . . . . .30

Not Cooling Fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Removing the Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Replacing the Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Cartridge Electrics Box Assembly . . . . . . . . . . . . . . . . . . . . . . . . . 33

Cartridge Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Condenser Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

SKOPE TME-N ActiveCore

Service Manual

Evaporator Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Compressor Electrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Refrigeration Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Cartridge Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Controller Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

QC Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Replacing the Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Door Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Control Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Evaporator Probe. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Condenser Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Ambient Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Condenser Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

7 Spare Parts

Main Assembly – TME650N-A Series . . . . . . . . . . . . . . . . . . . . . . . . 46

Main Assembly – TME1000N-A Series . . . . . . . . . . . . . . . . . . . . . . . 47

Cabinet Assembly – TME650N-A Series. . . . . . . . . . . . . . . . . . . . . . 48

Cabinet Assembly – TME1000N-A Series. . . . . . . . . . . . . . . . . . . . . 49

Glass Door Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Sign Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Cartridge Assembly – UTHCNI-0010 . . . . . . . . . . . . . . . . . . . . . . . . 52

8 Troubleshooting

Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Cabinet and Refrigeration Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . 54

Diagnostic Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

On-site Work Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

SKOPE TME-N ActiveCore

Servicing Hydrocarbon

Service Manual

1 Servicing Hydrocarbon

Overview

This cooler uses hydrocarbon (HC) R290 propane as its refrigerant. Hydrocarbon is a natural

refrigerant that has a very low environmental impact.

Special service requirements are needed as hydrocarbon is a flammable refrigerant.

Safety hazards

The main hydrocarbon safety hazards are:

• Flammable refrigerant.

• Venting of hydrocarbon and compressor oil.

• Asphyxiation.

SKOPE does not recommend performing hazardous activities on the refrigeration system.

See “Refrigeration Cartridge” on page 38 for more information including examples of

hazardous activities.

6Servicing Hydrocarbon

Service Manual

SKOPE TME-N ActiveCore

SKOPE HC Service Requirements

Servicing must only be performed by Approved SKOPE Service Technicians, and must meet all requirements in the

SKOPE HC Service Policy (available from SKOPE), including the following:

It is the responsibility of the service technician to follow SKOPE’s Hydrocarbon equipment service policy

and by accepting a service work order they agree to the following (where applicable):

xMUST – Ensure all workers are trained in the SAFETY of hydrocarbon products to the appropriate

level for the work required.

xMUST – Follow all Local Safety Regulations relevant to flammable refrigerant gases.

oAustralia should reference - AIRAH Flammable Refrigerants – Safety Guide

oNew Zealand should reference – Flammable Refrigerant Safety Documentation

(Refrigerant License NZ)

xMUST – Adhere to all on-site (workplace) Health and Safety requirements

xMUST – Not modify or alter the design of SKOPE equipment in any way

xMUST – In cases where the refrigeration system is not readily removable from the cabinet; then the

entire cabinet MUST be sent to the Hydrocarbon workshop for repair.

xMUST – ONLY use SKOPE OEM Spare Parts; or identical replacement parts. Any variation in

replacement part may render the system non-compliant and unsafe.

xMUST – Follow all best practice work activities for servicing hydrocarbon refrigerants (SKOPE

recommend attending specific hydrocarbon refrigeration handling training courses). Nitrogen must

be used for purging system before commencing “Hot Work” – brazing.

xMUST – Adhere to relevant SKOPE Service Manual. If any contradiction, the local Regulations take

precedence over SKOPE requirements

xMUST – Work only in suitable, safe and compliant work spaces. Personal Protective Equipment

must always be used when working on Hydrocarbon equipment.

xMUST – Service people diagnosing refrigeration faults must always carry and utilise Flammable Gas

detectors when working on Hydrocarbon equipment.

xMUST – Prior to any service work; know where and how to safely and quickly isolate power supply

to cabinet

xMUST – Not perform any Hot Work (brazing etc.) in the field. These are to be completed in a suitable

service depot / workshop (in a dedicated specific Hazardous Work Area compliant to local

flammable gas regulations)

xMUST – Not transport a refrigeration system with a known active leak. If there is an active leak the

refrigerant must be safely removed (with use of Bullet Piercing Valve or Line Tap valves) before

transporting. Valves must be removed at the hydrocarbon service depot once repair is completed.

xMUST – All hydrocarbon workshop areas must have emergency plans; that includes suitable

evacuation and fire control plans and equipment.

xMUST – Only use refrigerant grade hydrocarbon, to precise mass specified on removable

refrigeration system serial label.

xMUST – Be accurate refrigerant charge; The refrigerant mass is ultra-low charge and must only be

measured in by accurate scales to +/- 1.0gram. Refrigerant MUST not be overcharged; or added to

an already charged system.

xMUST – Use identical drier replacement; as any change will affect gas charge volume; and effect

reliability compliance and safety.

xMUST – Any pipework replacement, must be identical to genuine SKOPE parts.

xMUST – Not introduce a sparking device inside a cabinet or inside a removable refrigeration system.

Battery drills should not be used.

xMUST – Not perform any activity that could stress a refrigeration pipe (unless in a workshop).

xMUST – Get customer authorisation to permanently swap a removable refrigeration system.

xMUST – Have the Wellington Drive SCS Field app installed on a Bluetooth enabled device carried by

the service technician (exception is for cabinets that do not utilise the Wellington Drive Controller).

The app should be utilised for safe, accurate diagnosis of the system and it is required to complete

a controller replacement in the field.

xRECOMMENDED – Have the Wellington Drive SCS Track app installed on a Bluetooth enabled device

carried by the service technician. This passive app collects system data from the Wellington Drive

SCS Connect Controller and transmit it to the cloud.

xLogistics companies may be used to transport a complete refrigerator where no separation of the

refrigeration system occurs. Logistics companies are not required to be contracted to this SKOPE

Service Policy.

SKOPE TME-N ActiveCore

Specifications

Service Manual

2 Specifications

Models

This service manual is applicable to the SKOPE TME ActiveCore top mount cabinets detailed

in the table below. Refer to the relevant product specification sheet (available on the SKOPE

website: www.skope.com) for specifications

Table 1: Model specifications

Series Model SKOPE ID

TME650N-A ActiveCore TME650N-A SM65GYN

TME650N-AC SM65BYN

TME1000N-A ActiveCore TME1000N-A SM10GYN

TME1000N-AC SM10BYN

8Installation

Service Manual

SKOPE TME-N ActiveCore

3 Installation

Installation Guidelines

When installing this cabinet, ensure the installation guidelines below are considered and met.

Ventilation Requirements

This cabinet must have the following ventilation clearances at all times.

Ventilation

Ensure all ventilation

requirements below are

met.

Door Opening

Allow adequate space for

the door/s to open and

close properly.

Sunlight

Do not install the fridge in

direct sunlight.

Uneven Surface

Do not install the fridge on

an uneven surface.

Surface

The installation surface

must be capable of

supporting the loaded

cabinet.

Power Supply

Do not overload the power

supply.

Blocking Ventilation

Do not store boxes or items in

front or on top of the fridge.

Climate Class

The fridge must be installed in

an environment within its

climate class.

The climate class is stated on

the cabinet rating label inside

the fridge.

No below clearance required

Min. 300mm above

No side

clearance

required

No behind

clearance

required

SKOPE TME-N ActiveCore

Installation

Service Manual

Door Handles

Fitting Door

Handles

For transit purposes the door handles may be packed separately inside the cabinet. If the door

handles are packed separately, follow the steps below to fit them to the door/s.

Procedure 1: To fit a door handle

1. Remove the handle/s from inside the cabinet by carefully cutting the cable ties securing the

handle, and remove the packaging.

A metal spring clip is fitted inside the handle mounts

at each end of the handle.

2. Ensure that the spring clips point up.

3. Place BOTH handle mounts simultaneously

onto both door brackets.

4. Then push the handle down onto the brackets,

until the handle locks into place.

Troubleshooting

• If the handle does not lock into place, check that the spring clips are pointing up and try again.

• If only one end of the handle locks into place, unscrew the door handle (see over page), and refit

ensuring both of the handle mounts are located onto the brackets before pushing the handle down

and locking into place.

Handle mount

Spring clip

(pointing up)

Handle

Bracket

Front of

door

Bracket

CAUTION

Ensure BOTH handle mounts are in position before pushing

down.

10 Installation

Service Manual

SKOPE TME-N ActiveCore

Removing

Door Handles

The door handles can be removed for transporting and moving the cabinet through doorways,

or for refitting.

Shelves

The cabinet is fitted with five layers of wire shelves which may be positioned at different heights

to suit various products.

Shelf Clips Each wire shelf is held in place with four shelf clips, which clip in the shelf support strips and

slide up and down to the required shelf position.

The support strips are numbered to help place the shelf clips. You can see the numbers in the

bottom left hand corner of the shelf clip.

Procedure 2: To remove a door handle

1. Open the door, and peel back the door gasket from behind the handle mounts on the inside of the

door frame.

2. Unscrew the handle mounts through the holes on the inside of the door frame (top and bottom

screws only), and remove the handle.

3. Remove the bracket/s from the handle mount

by pressing the bracket in and down until it

unclips from the handle mount.

4. Fit and screw the bracket/s back onto the door.

Ensure the catches are pointing up as

pictured.

5. Refit the door gasket by clipping it back into place on the inside of the door frame. If the gasket is

out of shape after refitting it, a hair drier can be used to heat and reshape it.

Bracket

Handle mount

Handle

Bracket

Catch

Procedure 3: To fit a shelf clip

The shelf clip twists onto the shelf support strip.

1. Position the shelf clip with the flat side up

against the shelf support strip and the two

prongs pointing up.

2. Twist the top of the clip anticlockwise onto the

shelf support strip until it locks in place.

Shelf

support

strip

Prongs

Shelf clip

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Enfriador de Skope

Skope

Skope B550-2 Manual de servicio

Skope

Skope Pegasus PG100HC-2 Manual de usuario

Skope

Skope SK Series Manual de usuario

Skope

Skope GC110r Manual de usuario

Skope

Skope TME ActiveCore Series Manual de usuario

Skope

Skope ActiveCore BME-N Series Manual de usuario

Skope

Skope SC112N-AC Manual de usuario

Skope

Skope SK700 Manual de servicio

Skope

Skope TME Series Manual de usuario

Skope

Skope B550-2 Manual de usuario

Skope

Skope BB Series Manual de usuario

Skope

Skope PEGASUS PG600VC Manual de usuario

Skope

Skope TME650N-3C Manual de usuario

Skope

Skope SK650-2 Manual de servicio

Skope

Skope SERENE SC112G Manual de usuario

Skope

Skope OD260 Manual de usuario

Skope

Skope Serene SC112N-A Manual de usuario

Skope

Skope B1200-2 Manual de usuario

Skope

Skope SC112N-AC Manual de usuario

Skope

Skope BME1200-AC Manual de usuario

Skope

Skope TME1000 Manual de usuario

Skope

Skope TME1000 Manual de usuario

Skope

Skope BackBar X Series Manual de usuario

Skope

Skope BB Series Manual de usuario

Manuales populares de Enfriador de otras marcas

Aqua Optima

Aqua Optima Corona Manual de usuario

York

York YGWH 115 Guía

Galletti

Galletti PERFORMA MPE Series Manual de usuario

SMC Networks

SMC Networks HRR Series Manual de usuario

Daikin

Daikin EWAQ016CAW Manual de usuario

Trane

Trane CVHE Instrucciones de funcionamiento

Moffat

Moffat Friginox TSR-11SC Manual de usuario

Gree

Gree GWH07AGA-K6DNA1C Manual de usuario

Denali

Denali M1 Manual de usuario

MP Systems

MP Systems PURGE Series Manual de usuario

AEC

AEC PCA SERIES Hoja de especificaciones

Carrier

Carrier AquaEdge 19XRV series Instrucciones de funcionamiento

Telemark

Telemark TVP-2000 Manual

TICA

TICA MINI VRF CHR Series Manual de usuario

Penguin

Penguin COLD THERAPY CHILLER Manual de usuario

MAXA

MAXA A68 Manual de usuario

SABROE

SABROE ChillPAC Manual de usuario

Daikin

Daikin EWWQ-AJYNN Manual de usuario
