Installation

guide

WLM-1000_QIG_201311219.indd 1-2 5/14/14 11:22 AM

Package content

Mobile

Fi Router

1x 3G Mobile Wi-Fi Router

1x Pouch SIM adapters

1x Battery

1x Micro USB cable

Package content

1x Pouch

1x Micro USB cable

WLM-1000_QIG_201311219.indd 3-4 5/14/14 11:22 AM

3G Signal LED Power LED

Micro USB Port

Power

On/Oﬀ

Wi-Fi Signal LED

Device overview 3G Signal LED

Blue ashing: Dial-up to a 3G network

Blue ashing slowly: Register to a 3G network

Blue solid: Successful 3G data connection

LED oﬀ: 3G data connection not successful:

e.g. SIM card is not activated, Pin is activated or router is in

sleep-mode

Power LED

Blue solid for 30 seconds, then oﬀ: Power on

Red ashing: Low power

Red solid: Low power and will be powered oﬀ soon

Green ashing: Battery is charging

Green solid: Charging completed

LED oﬀ: Router is in sleep-mode

Wi-Fi Signal LED

Blue solid: Wi-Fi is active

Blue ashing twice: Connected to Wi-Fi network

LED oﬀ: Wi-Fi is in sleep-mode

Power on/oﬀ button

Press and hold for 3 seconds to power on/oﬀ

Press briey to deactivate sleep-mode

WLM-1000_QIG_201311219.indd 5-6 5/14/14 11:22 AM

Setup

a. Take oﬀ the back cover

WLM-1000_QIG_201311219.indd 7-8 5/14/14 11:22 AM

c. Insert the battery and put on the back coverb. Insert your SIM-card (and optional micro-SD card)

SIM

micro

(optional)

WLM-1000_QIG_201311219.indd 9-10 5/14/14 11:22 AM

d. Charge the 3G Mobile Wi-Fi Router

• Use the supplied micro-USB cable and connect to a notebook

or a USB wall charger.

• A full charge will take about an hour.

e. When the battery LED turns solid green the

3G Mobile Wi-Fi Router is fully charged

WLM-1000_QIG_201311219.indd 11-12 5/14/14 11:22 AM

f. Press and hold the on/oﬀ button for 3 seconds to turn

the 3G Mobile Wi-Fi Router on

g. Check the status of the 3G Signal LED to determine

the status of your 3G connection

press

3 sec.

• If the LED turns solid blue, your SIM-card is not secured

with a pin code and you have a successful connection.

Continue with Step 2 only.

• If the LED stays oﬀ , your SIM-card is probably secured with

a pin code. Continue with Step 2 and 3.

WLM-1000_QIG_201311219.indd 13-14 5/14/14 11:23 AM

Connect your

device to the

3G Mobile

Wi-Fi Router

a. Scan for Wi-Fi networks in your area

Click

MAC

Click

WLM-1000_QIG_201311219.indd 15-16 5/14/14 11:23 AM

c. Type the WPA2 codeb. Select the network name of your 3G Mobile Wi-Fi Router

PC PC

MAC

• You can  nd the network name in the Network Detail Flyer or

on the inside of the back lid of your 3G Mobile Wi-Fi Router.

• You can  nd the WPA2 code in the Network Detail Flyer or

on the inside of the back lid of your 3G Mobile Wi-Fi Router.

Click

Click Click

Click

WLM-1000_QIG_201311219.indd 17-18 5/14/14 11:23 AM

Unlock your

SIM-card

a. Open your web browser and go to:

http://sitecom.modem
