Sitecom DC-229 Manual de usuario
DC-229
ADSL2+ Modem/Router
-Annex B-
User Manual
Version: 1.0
2
TABLE OF CONTENTS
1PACKAGE CONTENTS .........................................................................................................3
2PRODUCT LAYOUT...............................................................................................................4
3NETWORK + SYSTEM REQUIREMENTS ...................................................................6
4DC-22 PLACEMENT...........................................................................................................6
5SETUP LAN, WAN.................................................................................................................7
6PC NETWORK ADAPTER SETUP (WINDOWS XP)..............................................8
7BRINGING UP THE DC-22 ..........................................................................................10
8INITIAL SETUP DC-22 .................................................................................................10
CONFIGURATION WIZARD ..........................................................................................19
10 FIREWALL SETTINGS ......................................................................................................20
11 ADVANCED SETTINGS.....................................................................................................26
12 TOOLBOX SETTINGS ........................................................................................................37
1Package Contents
Open the package care ully, and make sure that none o the items listed
below are missing. Do not discard the packing materials, in case o return;
the unit must be shipped back in its original package.
1. DC-229 modem/router
2. 220V ~ 240V Power Adapter
3. Quick Install Guide
4. CD (User’s Manual)
5. Warranty card
6. UTP cable
2Product Layout
Port Description
ADSL Connect your telephone/ADSL cable this port
LAN Connect the cable rom your PC or network to this port
Power
connector Blinks on tra ic or speci ic LAN PORT
Reset button
Power connector
LAN / computer connection
ADSL
connection
Front panel
The ront panel describes the corresponding LED indications and port
unctionality.
LED Description
POWER
(Orange)
Lights up when powered ON. Blinks
on TEST/RESET
ADSL
(Green)
Lights up when an ADSL cable is
connected.
Internet
(Green)
Lights up when internet connection is
UP.
LAN
(Blue)
When a network cable is connected,
the corresponding light lights up.
3Network + System Requirements
To begin using the DC-229, make sure you meet the ollowing as
minimum requirements:
•PC/Notebook.
•Operating System – Microso t Windows XP/2000/VISTA
•1 Free Ethernet port.
•Annex B, ADSL internet connection.
•PC with a Web-Browser (Internet Explorer, Sa ari, Fire ox,
Opera)
•Ethernet compatible CAT5 cables.
4DC-22 Placement
You can place the DC-229 on a desk or other lat sur ace, or you can
mount it on a wall. This location must be close to a power connection
and the ADSL/phone line should not be over 2 meters long.
5Setup LAN, WAN
LAN / computer connection
ADSL
connection
6PC Network Adapter setup
(Windows XP)
•Enter [Start Menu] select [Control panel] select [Network].
•Select [Local Area Connection]) icon=>select [properties]
•Select [Internet Protocol (TCP/IP)] =>Click [Properties].
•Select the [General] tab.
a. DC-229 supports [DHCP] unction, please select both [Obtain an IP
address automatically] and [Obtain DNS server address automatically].
7Bringing up the DC-22
Connect the supplied power-adapter to the power inlet port and connect it to
a wall outlet. The DC-229 automatically enters the sel -test phase. During
sel -test phase, the Power LED will blink brie ly, and then will be lit
continuously to indicate that this product is in normal operation.
8Initial Setup DC-22
LOGIN procedure
2. OPEN your browser (e.g. Internet Explorer).
3. Type http://10.0.0.1 in address bar and press [Enter]
